  • Page 1 OPERATION MANUAL FA-9600 Command Version 2.3 - Higher...

  • Page 2: Table Of Contents

    1-2. Changing Status Report Destination Addresses ................ 5 2. Command Flow Examples........................6 2-1. Checking FA-9600 Start-up......................6 2-2. Requesting FA-9600 Video Status ....................6 2-3. Changing Audio Gain Settings ....................6 2-4. Reporting FA-9600 Status Change ..................... 6 3. Command Format ..........................7 3-1.
  • Page 3 5-18. FA-96MADI MAPPING ......................28 5-19. FA-96MADI Master Gain ......................28 5-20. FA-96MADI Gain ........................28 6. Other Commands ..........................29 6-1. Power On (with Specifying FA-9600 Software Version) ............29 6-2. Event Load ..........................29 6-3. Event Save ..........................29 6-4. Video Status Request .......................29 6-5. Audio 1 Status Request ......................30 6-6.

  • Page 4: Communication Settings

    (See Sec 3 “Command Format” for details on commands and its format) Response to Command (FA-9600) FA-9600 sends “ACK” after properly receiving a command, or an error message in other cases using TCP packets. (See Sec. 3-2 “Command Response.”) Destination Address FA-9600 IP address: 192.168.0.10 (default) (Use the current FA-9600 IP address.))

  • Page 5: Changing Status Report Destination Addresses

    1-2. Changing Status Report Destination Addresses Whenever the FA-9600 status changes, FA-9600 sends a status report to two destinations (UDP). These destination addresses and port number can be changed as shown below, as needed. Refer to FA-9600 Operation Manual to connect to FA-9600 through Web GUI.

  • Page 6: Command Flow Examples

    Command Device issues a status request to FA-9600. (See Sec. 6-4 “Video Status Request.”) FA-9600 sends “ACK” to Command Device. FA-9600 send a status message in response to the command. (See Sec. 7-1 “Video Status “) Command Device sends “ACK” to FA-9600.

  • Page 7: Command Format

    3-1. Setting Commands  Command Example <Command code>,<ID code>,<Item code>,<Value>[CR][LF] Commands sent from Command Devices to FA-9600 are composed of 4 variables, using commas as a separator as shown above. < > Denotes a command variable in which an actual value is entered.

  • Page 8: Id Code

    3-4. Video Setting Command List Add [CR][LF] at the end of commands. See Sec. 4 “Video Setting Commands.” Available commands when FA-9600 is in 3D LUT mode. Available commands when HLG BT.2100 is set for input or output gamma curve. Command statement Refer to Dynamic Range CONV,<ID code>,Gamma Curve Enable,<Value>...

  • Page 9: Audio Setting Command List

    3-5. Audio Setting Command List Add [CR][LF] at the end of commands. See Sec. 5 “Audio Commands. Available commands when FA-9600 is in 3D LUT mode. Commands available with FA-96AES-UBL option. Commands available with FA-96ANA-AUD option. Commands available with FA-96MADI option.

  • Page 10: Video Setting Commands

    Dynamic Range/Color Space processing Only FS1 is enabled when FA-9600 is in 3D-LUT mode. See “INPUT / OUTPUT GAMMA/COLOR (UHD & HD)” in FA-9600 Operation Manual. 4-2. In Gamma Curve Command statement: Dynamic Range CONV,<ID code>,EOTF DeGamma,<Value>[CR][LF]...

  • Page 11: In Color Space

    U02:User2 U03:User3 U04:User4 U05:User5 This command is disabled when FA-9600 is in 3D-LUT mode. See “INPUT / OUTPUT GAMMA/COLOR (UHD & HD)” in FA-9600 Operation Manual. 4-4. Out Gamma Curve Command statement: Dynamic Range CONV,<ID code>,OETF Gamma,<Value>[CR][LF] Value FA-9600 setting ID code U01: SDR 2.2 BT.1886...

  • Page 12: Out Color Space

    U01: S-Gamut/Gamut3 U02:User2 U03:User3 U04:User4 U05:User5 This command is disabled when FA-9600 is in 3D-LUT mode. See “INPUT / OUTPUT GAMMA/COLOR (UHD & HD)” in FA-9600 Operation Manual. 4-6. 3D-LUT Data Command statement: Dynamic Range CONV,<ID code>,DRC 3DLUT,<Value>[CR][LF] Value FA-9600 setting ID code U01: HLG >>...

  • Page 13: In/Out Dynamic Range For 3D-Lut Mode

    FS1 (fixed) SDI >> SDI Narrow >> SDI SDI >> Narrow This command is enabled when FA-9600 is in 3D-LUT mode. See “IN / OUT GAMMA/COLOR」” in FA-9600 Operation Manual. 4-8. Gain Adjustment Command statement: Dynamic Range CONV,<ID code>,Dynamic Range Gain,<Value>[CR][LF]...

  • Page 14: Gain Simultaneous Mode

    Dynamic Range CONV,COM,Simul Mode,<Value>[CR][LF] Value FA-9600 setting Disable Enable This command is disabled when FA-9600 is in 3D-LUT mode. See “DYNAMIC RANGE GAIN CONTROL” in FA-9600 Operation Manual. 4-11. OOTF IN for HLG Command statement: Dynamic Range CONV,<ID code>,OOTF IN Mode,<Value>[CR][LF]...

  • Page 15: Ootf In Display Peak For Hlg

    This command is enabled when “OOTF IN for HLG” is set to “Enable.” (See 4-11. “OOTF IN for HLG.”) This command is disabled when FA-9600 is in 3D-LUT mode. See “OOTF for HLG” in FA-9600 Operation Manual. 4-14. OOTF IN Display Black for HLG Command statement: Dynamic Range CONV,<ID code>,OOTF IN Display Black,<Value>[CR][LF]...

  • Page 16: Ootf Out System Gamma For Hlg

    This command is enabled when “OOTF OUT for HLG” is set to “Inverse OOTF.” (See 4-15. “OOTF OUT for HLG.”) This command is disabled when FA-9600 is in 3D-LUT mode. See “OOTF for HLG” in FA-9600 Operation Manual. 4-17. OOTF OUT Display Peak for HLG Command statement: Dynamic Range CONV,<ID code>,OOTF OUT Display Peak,<Value>[CR][LF]...

  • Page 17: Optional Function (Ootf Rgb)

    Value FA-9600 setting Adjustment SR-Live This command is disabled when FA-9600 is in 3D-LUT mode. This command requires the FA-96AHDR2 option and certain conditions. See “Optional Function (FA-96AHDR2) in FA-9600 Operation Manual for more details. 4-20. Optional Function (Operation) Command statement: Dynamic Range CONV,<ID code>,OOTF FOR SR-Live,<Value>[CR][LF]...

  • Page 18: Optional Function (Sdr Sony)

    FA-9600 setting STANDARD1-7 7-10 HYPER1-4 This command is disabled when FA-9600 is in 3D-LUT mode. This command requires the FA-96AHDR2 option and certain conditions. See “Optional Function (FA-96AHDR2) in FA-9600 Operation Manual for more details. 4-23. KNEE (RGB) CLIP White Clip Command statement: Knee Clip,<ID code>,White Clip Enable,<Value>[CR][LF]...

  • Page 19: Knee (Rgb) Clip White Output Clip

    FA-9600 setting 50.0-150.0% 500-1500 Sets the White threshold in RGB. This command is disabled when FA-9600 is in 3D-LUT mode. See “KNEE (RGB) CLIP (White/Black)” in FA-9600 Operation Manual. 4-26. KNEE (RGB) CLIP White Knee Slope Command statement: Knee Clip,<ID code>,Knee Slop,<Value>[CR][LF]...

  • Page 20: Knee Saturation Enable

    Knee Clip,<ID code>,Knee Saturation Enable,<Value>[CR][LF] ID code Value FA-9600 setting Disable Enable This command is disabled when FA-9600 is in 3D-LUT mode. See “KNEE (RGB) CLIP (White/Black)” in FA-9600 Operation Manual. 4-29. KNEE Saturation Level Command statement: Knee Clip,<ID code>,Knee Saturation Level,<Value>[CR][LF] ID code...

  • Page 21: Knee (Rgb) Clip Black Output Clip

    Knee Clip,<ID code>,Black Clip,<Value>[CR][LF] ID code Value FA-9600 setting -50.0 to 50.0% -500 to 500 Sets the Black threshold for RGB space. This command is disabled when FA-9600 is in 3D-LUT mode. See “KNEE (RGB) CLIP (White/Black)” in FA-9600 Operation Manual.

  • Page 22: Audio Commands

    Normal Ch1 to Ch8 (for AES) EMB2 Invert This command is disabled for EMB2 (ID code) when FA-9600 is in 3D LUT mode. See “EMD. AUDIO INPUT POLARITY” and “AES AUDIO INPUT POLARITY” in FA-9600 Operation Manual. 5-2. Audio MAPPING Command statement: Audio MAP,<ID code>,<Item code>,<Value>[CR][LF]...

  • Page 23: Audio Master Gain

    -20.0 to +20.0dB -200 to +200 Sets Gain Offset for all channels. EMB2 This command is disabled for EMB2 (ID code) when FA-9600 is in 3D LUT mode. See “AUDIO OUTPUT GAIN” in FA-9600 Operation Manual. 5-4. Audio Gain Command statement: Audio Gain,<ID code>,<Item code>,<Value>[CR][LF]...

  • Page 24: Audio Delay

    ID code Target Value FA-9600 setting ADLY G1 Internal Ch1-16 ADLY G2 Internal Ch17-32 See “AUDIO DELAY ADJUST FS SELECT” in FA-9600 Operation Manual. 5-8. FA-96AES-UBL Polarity Command statement: FA-96AESUBL,SlotB,<Item code>,<Value>[CR][LF] Value FA-9600 setting Item code Normal Polarity Ch1 to Ch8 Invert This command requires FA-96AES-UBL.

  • Page 25: Fa-96Aes-Ubl Mapping

    96, 98, 100, 102, 104, 106, 108, 110, 112, Mono Sum Ch1-Ch16 114, 116, 118, 120, 122, 124, 126 This command requires FA-96AES-UBL. See “AES AUDIO OUTPUT MAPPING” in FA-9600 Operation Manual. 5-10. FA-96AES-UBL Master Gain Command statement: FA-96AESUBL,SlotB,Master Gain,<Value>[CR][LF] Value FA-9600 setting -20.0 to +20.0dB...

  • Page 26: Fa-96Ana-Aud Polarity

    Value FA-9600 setting Item code Normal Polarity Ch1 to Ch4 Invert This command requires FA-96ANA-AUD. See “ANALOG AUDIO INPUT POLARITY” in FA-9600 Operation Manual. 5-13. FA-96ANA-AUD MAPPING Command statement: FA-96ANAAUD,SlotB,<Item code>,<Value>[CR][LF] Item code Value FA-9600 setting MAP Ch1 to Ch4...

  • Page 27: Fa-96Ana-Aud Input Gain

    * Master Gain should be added to each channel gain to get the final value. (Final value range: ±20 dB) This command requires FA-96ANA-AUD. See “ANALOG INPUT/OUTPUT GAIN” in FA-9600 Operation Manual. 5-16. FA-96ANA-AUD Output Master Gain Command statement: FA-96ANAAUD,SlotB,Out Master Gain,<Value>[CR][LF]...

  • Page 28: Fa-96Madi Mapping

    96, 98, 100, 102, 104, 106, 108, 110, 112, Mono Sum Ch1 to Ch16 114, 116, 118, 120, 122, 124, 126 This command requires FA-96MADI. See “MADI OUTPUT MAPPING” in FA-9600 Operation Manual. 5-19. FA-96MADI Master Gain Command statement: FA-96MADI,SlotB,Master Gain,<Value>[CR][LF] Value FA-9600 setting -20.0 to +20.0dB...

  • Page 29: Other Commands

    6. Other Commands 6-1. Power On (with Specifying FA-9600 Software Version) Command statement: PowerOn,COM,CHK,<Value>[CR][LF] Value FA-9600 setting (Protocol number) Supports FA-9600 Software older than Ver. 3.1x. Supports FA-9600 Software from Ver. 3.1x to 3.3x. Supports FA-9600 Software Ver. 3.5x. Supports FA-9600 Software Ver. 3.6 (latest).

  • Page 30: Audio 1 Status Request

    6-5. Audio 1 Status Request Command statement: Status2,<ID code>,Get,0[CR][LF] ID code Description EMB1 Request for FS1 embedded audio status EMB2 Request for FS2 embedded audio status Request for AES audio status 6-6. Audio 2 Status Request Command statement: Status3,<ID code>,Get,0[CR][LF] ID code Description ADLY G1 Request for audio delay group 1 status...

  • Page 31: Status Messages From Fa-9600

    Send ACK[CR][LF] when receiving status report messages. Otherwise, FA-9600 re-transmits the message up to three times at 1 sec intervals and no ACK is still returned, FA-9600 performs the timeout processing. 7-1. Video Status Message (for Protocol Number 3) Return message: Status1,<ID code>,RPT,<Setting Status>,<Input Status>,<Output Status>[CR][LF]...
  • Page 32 Sec. 4-19 “Optional Function (OOTF RGB).” Setting19 Sec. 4-20 “Optional Function (Operation).” Setting20 Sec. 4-21 “Optional Function (System Gamma).” Setting21 Sec. 4-22 “Optional Function (SDR SONY).” Setting22 0-10 Sec. 4-23 “KNEE (RGB) CLIP White Clip.” Setting23 0, 1 Sec. 4-24 “KNEE (RGB) CLIP White Knee Type.” Setting24 0, 1 Sec.

  • Page 33: Input / Output Status Examples In Messages

    7-1-1. Input / Output Status Examples in Messages Ex. 1) Input State return values if no signal is present at Input 1 (FS1) <Input State1-1>: -1 (None) <Input State1-2>: -1 (None) Values “-1,-1,-1,-1,-1” are returned. <Input State1-3>: -1 (None) <Input State1-4>: -1 (None) <Input State1-5>: -1 (None) Ex.

  • Page 34: Video Status Message (For Protocol Number 2)

    7-2. Video Status Message (for Protocol Number 2) Return message: Status1,<ID code>,RPT,<Setting Status>,<Input Status>,<Output Status>[CR][LF] ID code Setting 1, Setting 2,…,Setting 31 Input state 1-1, Input State 1-2,…,Input State 2-1,…,Input State 2-5 Output State 1-1, Output State 1-2,…,Output State 2-1,…, Output State 2-5 See <p.

  • Page 35: Video Status Message (For Protocol Number 1)

    7-3. Video Status Message (for Protocol Number 1) Return message: Status1,<ID code>,RPT,<Setting Status>,<Input Status>,<Output Status>[CR][LF] ID code Setting 1, Setting 2,…,Setting 28 Input state 1-1, Input State 1-2,…,Input State 2-1,…,Input State 2-5 Output State 1-1, Output State 1-2,…,Output State 2-1,…, Output State 2-5 See <p.

  • Page 36: Video Status Message (For Protocol Number 0)

    7-4. Video Status Message (for Protocol Number 0) Return message: Status1,<ID code>,RPT,<Setting Status>,<Input Status>,<Output Status>[CR][LF] ID code Setting 1, Setting 2,…,Setting 23 Input state 1-1, Input State 1-2,…,Input State 2-1,…,Input State 2-5 Output State 1-1, Output State 1-2,…,Output State 2-1,…, Output State 2-5 See <p.

  • Page 37: Audio 1 Status Message

    7-5. Audio 1 Status Message Return message: Status2,<ID code>,RPT,<Status 1>,< Status 2>,<Status 3>,<Status 4>[CR][LF] ID code EMB1 EMB2 Setting1-1, Setting1-2 Setting2-1,Setting2-2,…,Setting2-16 Setting4-1,Setting4-2,…,Setting4-16  <Status> (Setting Status) Variable Setting range Remarks Reference Setting1-1 00000000 to 11111111 Ch1-8 Audio Polarity settings Sec. 5-1 Ch9-16 Audio Polarity “Audio Polarity”...

  • Page 38: Audio Option Status Message (Fa-96Aes-Ubl)

    7-7. Audio Option Status Message (FA-96AES-UBL) Return Message: Status4,SlotB,RPT,<Status1>,<Status2>,<Status3>,<Status4>[CR][LF] Setting2-1,Setting2-2,…,Setting2-8 Setting4-1,Setting4-2,…,Setting4-8  <Status> (Setting Status) Variable Setting range Remarks Reference Ch1-8 Audio Sec. 5-8 Setting1 00000000 to 11111111 “FA-96AES-UBL Polarity” Polarity settings 0-31,64-66,80-83, 96, 98, Setting2-x 100, 102, 104, 106, 108, Sec.

  • Page 39: Audio Option Status Message (Fa-96Madi)

    7-9. Audio Option Status Message (FA-96MADI) Return Message: Status4,SlotB,RPT,<Status1>,<Status2>,<Status3>[CR][LF] Setting1-1,Setting1-2,…,Setting1-32 Setting3-1,Setting3-2,…,Setting3-32  <Status> (Setting Status) Variable Setting range Remarks Reference 0-31,64-66,80-83, 96, 98, Setting1-x 100, 102, 104, 106, 108, Sec. 5-18 Ch1-32 mapping “FA-96MADI MAPPING” 110, 112, 114, 116, 118, (x: Channel1-32) 120, 122, 124, 126 Audio Master...
