REC ROOM MASTERS XTENSION 32 UPRIGHT User Manual

Arcade cabinet

Advertisement

Quick Links

32 UPRIGHT
32 UPRIGHT
USER & ASSEMBLY GUIDE
Xtension Arcade Cabinet
Contents:
Page 1: Cover
Page 2: Base Section - Cabinet Parts List
Page 3: Base Section - Hardware List
Page 4 - 9: Base Section - Assembly Instructions
Page 10: Top Section - Cabinet Parts List
Page 11: Top Section - Hardware List
Page 12-19: Top Section - Assembly Instructions
Page 20: Game On!
Required Tools:
Phillips Head Screwdriver
Included M4 Allen Wrench
PLEASE NOTE:
Adult Supervision Recommended
For Assembly
2 People Required For Assembly
PLEASE TRY OUR NEW
VIDEO INSTRUCTIONS!
youtube.com/@Recroommasters
WARNING:
NEED SUPPORT?
Please be sure to read assembly
Send an email to:
instructions thoroughly, as improper
support@recroommasters.com
assembly may lead to instability.
