Summary of Contents for Vident iBT200
- Page 1 12V & 24V Battery Analyzer USER MANUAL (ENGLISH) SHENZHEN VIDENT TECHNOLOGY CO.,LTD Copyright @ 2020 Vident Tech.
-
Page 2: Brief Introduction
IEC/EN61010-1 safety standard. Also it reaches double insulation over voltage standard CATⅢ 600V and pollution degree 2 . (1) Vident iBT200 is used for 12V and 24V Lead-Acid Starting Battery. The working voltage is DC 9V to 36V. (2) The voltage value will be higher than that in the normal situation after the checked battery being fully charged . - Page 3 (6) Wear proper eye mask when testing or repairing in order to avoid some objects hitting eyes from the engine. (7) Keep the site ventilated when testing or repairing in order to avoid inhaling some toxic gas. (8) When the engine is running, do not place the tester or accessories beside the engine or exhaust pipe in order to avoid damage by high temperature.
- Page 4 < > cancel / return BACK < > confirm / test ENTER > restart unit / return under any status < iBT200 Battery Tester < > battery good condition light < > battery warning condition light BACK ENTER < >...
- Page 5 Select language as below. 5-1. BATTERY CAPACITY TEST This test determines condition of battery according to rated value labeled on the battery. 5-1-1. First make sure the engine and all devices are off . The voltage value will be higher than that in the normal situation due to the checked battery is fully charged after the vehicle runs for a while.
- Page 6 5-1-3. Press <▲> <▼> to select “BATTERY TYPE” and press <ENTER> to continue. 5-1-4. Press <▲> <▼> to select CCA TYPE which is displayed on the battery rating label, and press <ENTER> to continue. 5-1-5. Press <▲> <▼> to select CCA RATED which is displayed on the battery rating label.
-
Page 7: Cranking Test
Battery State of Health (SOH) and Test Result Reference Table LIFE RESULT NOTE >80% GREAT Good to Use GREEN >60% NORMAL Not Bad GREEN >45% CAUTION Keep Caution YELLOW <45% SUGGESTREPLACE! ReplaceNeeded Please note that Internal Resistance refers to the sum total resistance of two series connection 12V batteries when testing 24V system. - Page 8 5-2-4. Test result will be displayed as below. Press <BACK> to return to main menu. Reading over 9.6V ( for 24V system, reading over 16V ) means cranking is good. Reading below 9.6V ( for 24V system, reading below 16V ) means cranking is abnormal.
- Page 9 5-3-3. Press <ENTER> to Charging Test interface. Start engine as guide displayed in the screen. 5-3-4. Test result will be displayed as below. Press <BACK> to return to main menu. Charging Test Result Reference Table Reference Table (For 12V System) Status Battery Voltage Engine Performance...
- Page 10 6.FAQ 6-1 What is the measurement principle of this tester? The battery will gradually aging with increase of time. The main reason is that it can no longer generate some eff ectively chemical reaction because of aging of the surface of the battery plate. That is why most of the batteries can longer be used mainly.
- Page 11 6-4 Is the CCA value tested by this tester correct? CCA is considered as a control standard with the produce of the battery. According to the accumulated records, the tested value of new battery is 10-15% higher than the standard value, and along with consuming of the battery, the value is getting close to standard, even lower afterward.
- Page 12 Shenzhen Vident Technology Co.,Ltd. Tel: 86-755-28305016 Email: support@videnttech.com Web: www.videnttech.com...
