Summary of Contents for Truper DES-330
- Page 1 Manual brushcutter Applies for: Code Model 11029 DES-330 DES-330 Motor Read the user’s manual thoroughly CAUTION before operating this tool.
-
Page 2: Table Of Contents
Contents WARNING Technical Data Fuel Specifications To gain the best performance of the tool, prolong the duty life, Safety warnings for motor tools make the Warranty valid if necessary, and to avoid hazards Safety warnings for brushcutters of fatal injuries please read and understand this Manual before Parts using the tool. -
Page 3: Technical Data
Technical data DES-330 Code 11029 Description Gas brushcutter Net weight 19.8 lb Motor 33 cc Motor rated power 1.4 Hp Fuel tank 0.23 gal Speed 9 000 RPM Cutting capacity 18” Axis length 5.2 ft Cutting systems Nylon line spool and blade Blade diameter Outer: 10”... -
Page 4: Safety Warnings For Motor Tools
Safety warnings for motor tools Keep your work area clean, tidy and well lit. Wear adequate protective safety accessories. CAUTION CAUTION Cluttered and dark areas may cause accidents. Wear eye protection, dust mask, non-skid safety shoes, helmet and ear plugs. These safety gears reduce the risk Never use the brushcutter in explosive areas or in the of injury. -
Page 5: Safety Warnings For Brushcutters
Safety warnings for brushcutters formations or condensation in the brushcutter. Fuel handling • Verify visibility and light condition are adequate to see clearly. Otherwise do not use the brushcutter. • Never smoke near fuel or where gasoline is supplied. Or where the oil mix is prepared or while operating the •... -
Page 6: Parts
Parts Spark Plug Cover Starter Fuel WARNING • Do not try to modify the brushcutter Handle Tank or manufacture not recommended accessories. Otherwise, the user may suffer severe injuries and will make the warranty void. WARNING • When assembling parts, always disconnect the motor spark plug cable to prevent an accidental start up causing severe personal injuries. -
Page 7: Assembly
Assembly Handle Guard • Separate the hinge bracket from the straight axis frame • Fasten the guard into the cutting head using the bracket loosening the easy adjusting knob (a). and the bolts included (A). • Set the handle in the straight axis frame. •... - Page 8 Assembly Line spool installation • Set the pressure turn table onto the cutter head (7). • Set the flange onto the turn table (8). • Insert the Allen key into the turn table side to block the axis (5). • Place the threaded spool in the axis and tighten counterclockwise using your hand (9).
-
Page 9: Fuel Supply
Fuel supply • Follow the safety standards for handling fuel (page 5). • Wait until the motor has cooled down completely before supplying fuel. • Set the brushcutter onto a flat surface. • Wipe clean around the fuel tank cap to prevent contamination. -
Page 10: Operation
Turning on Start up with a hot motor • Set the brushcutter on level ground where the blade or spool will not make contact with any obstacle. • Set the switch into the ON position (A). • Press simultaneously the trigger release (D) and the throttle trigger (E).Keep the trigger depressed. -
Page 11: Maintenance
Maintenance • Before inspecting, cleaning or servicing the tool turn the motor off, wait for all the mobile parts to stop, disconnect the spark plug cable and set it away from the spark plug. Otherwise, the operator may suffer severe burns and / or damage the tool. General cleansing Spark plug replacement •... -
Page 12: Troubleshooting
Maintenance Gas Brushcutter Storage In the event of storing the Gas Brushcutter for one month or longer, bear in mind the following considerations: • Drain all the fuel tank contents into an approved gasoline container. All the remaining fuel can be re-used in another tool that uses 2-stroke motor with a 50:1 ratio. -
Page 13: Notes
Notes ENGLISH... - Page 14 Notes ENGLISH...
-
Page 15: Authorized Service Centers
Authorized Service Centers In the event of any problem contacting a Truper Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800-018-7873 to get information about the nearest Service Center. -
Page 16: Warranty Policy
It includes the costs of transportation of the product that derive from its fulfillment of its service network. . Phone number 800-018-7873. Made in China. Imported by Truper, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100.
