Phenomena
Causes
Switch on the transmitter.
The headset is not put into the charging
slot properly or firmly.
Headset
can not be
charged
The battery is not inserted into the battery
successfully
compartment in the correct way resulting
in the battery contacts distorted.
The transmitter base can not be
powered properly.
LIMITED WARRANTY
12 months limited warranty: The 12 months warranty will cover defects in
manufacturing and product failure for a period of 12 months from the original date of
purchase. The warranty period is not extended if we repair or replace a warranted
product.
This warranty is provided at the discretion of Simolio Ltd. And does not cover
cosmetic damage or damage due to acts of nature, accident, misuse, abuse, negligence,
commercial use, or modification of or to any part of the product.
audio cables, power adapter and perishable items such as ear tips and batteries are
not covered under this warranty.
Please contact: support@simolio.com (for NA/AU) or support_uk@simolio.com
(for UK) and provide your Amazon order ID to register the warranty.
TECHINICAL SPECIFICATIONS
Transmission mode
Transmission Frequency
Transmitter
Power Supply
Headset
Frequency response
Distortion
Signal-to-noise ratio
Range
Up to 40 feet (without obstacles)
Working time
approx 15 hours under wireless hearing mode
Charging time
Solutions
The transmitter is not switched on.
Make sure the headset is put into the charging
slot correctly and firmly, the front of the
headset with the logo of "SIMOLIO" is facing
towards the front of the transmitter with the
logo of "SIMOLIO".
Replace with a new headset.(damage due to
misuse, not covered by warranty)
Please change another power adapter
to have a try.
Accessories such as
Infrared light
2.3 MHz
output: DC 12V, 400mA
input : 100~240V
plug of power cable : 4.0*1.7mm
built-in 350mAh Li-ion Battery
20 Hz – 20 KHz
≤1%
≥70dB
3 hours
18
Part 2
Infrared Wireless TV Headsets
Sales & Support Email: support@simolio.com (for NA/AU)
SM-863D
User Manual
support_uk@simolio.com (for UK)
