Westcott ICE LIGHT 2 Manual

CONTENTS & USAGE

POWER CONTROL

Press and slide the power control upward to power on the Ice Light 2. Press and slide the power control downward to power off the Ice Light 2.

LIGHT OUTPUT CONTROLS

The Ice Light 2's light output can be adjusted in 18 increments. Use the up and down arrow buttons to adjust the light output. The current output level appears on the Digital Light Output Display. From lowest to highest output, these values are displayed as:
L - 2 - 2. - 3 - 3. - 4 - 4. - 5 - 5. - 6 - 6. - 7 - 7. - 8 - 8. - 9 - 9. - H

FEATURES & SPECS

FEATURES

FEATURES

  1. Accessory attachment threaded 1/4-20"
  2. Frosted diffusion front
  3. Removable Lithium Ion Battery
  4. AC/DC Operation
  5. Accessory attachment threaded 1/4-20"
  1. All-metal construction
  2. Digital LED Light Output Display
  3. Dimmer Controls
  4. Power Slider
  5. Battery Power Indicator

SPECIFICATIONS

LAMP TYPE LED Array DIMMABLE RANGE 1.5w – 15w
LED HOURS 50,000+ POWER SUPPLY Input 100-240v 50/60hz Lithium Ion 7.4v
CRI 96 BATTERY CHARGE TIME 2.5 hours
LUMENS 1,740 lm BEAM ANGLE 72.6 degrees
COLOR TEMPERATURE 5500K ± 100 MOUNT Handheld with 1⁄4-20" thread (both ends)
BATTERY LIFE 60 minutes ± 10% SIZE 21.6" x 1.7" (55cm x 4.4 cm)
POWER DRAW 1.5w – 15w WEIGHT 1.25 lbs (0.57 kg)

  • The included charger is restricted to use with only the Ice Light 2. Never use any power cable or transformer on the Ice Light 2 other than the one provided.
  • Do not use the Ice Light 2 in or near water. Do not allow the unit to become wet and do not expose the unit to extreme temperature.
  • The charging terminal and indication lights may become warm during operation or charging. Take care when handling.
  • Always unplug the charging cord when not in use.

REMOVABLE BATTERY

BATTERY POWER LEVEL

The Battery Power Indicator displays the current battery power level using the illuminated lights:
BATTERY POWER LEVEL

CHARGING

To charge, connect the Ice Light 2 charger cord to the battery's AC/DC operation input and plug into any standard 110v-240v outlet. A fully depleted battery recharges in approximately 2.5 hours.
The Ice Light 2 can be charged both inside and outside of the unit using the charging port on the battery. To remove the battery, press downward on the tab and pull outward.

TIPS

TRAVELING WITH CHARGER

When on-location, secure the charger bag by latching its loop end and drawstring onto the top and bottom of the carry case's strap hooks.

GEL CLIPS

Add color or warmth using the included gel clips. Simply cut your gel to size, place over the Ice Light and clip into place.
