GIMPRO MS1(A) User Manual page 2

Operations
TX
1. Power On/Off
On: Long press the Switch Key for 3s.
Off: Long press the Switch Key for 3s.
2. Pairing
After power on, plug the receiver into device and the system will pair automatically.
※ If there are more than one set of MS1 working simultaneously, it is suggested that
pair one set first and then the other to avoid pairing confusion.
3. Charging
5V/1A;
Please fully charge the TX transmitter with charging cable before use.
RX
1. Power On/Off
On: Plug in the device
Off: Plug out of the device
2. Connecting
Connect the receiver to phone.
※ Use the Type-C to USB Adapter [Only for MS1(C)] to connect with computer.
※ Realme / XIAOMI / OPPO / VIVO / IQOO / HUAWEI mobile phones can be used
normally only when OTG function ( please search "OTG" on the settings) turns on.
3. Pairing
After power on, plug the receiver into device and the system will pair automatically.
4. Reset
Plug out of the device and plug it in to restart it.
5. Charging
There is no battery in RX receiver and no need to recharge during live.
※ If the phone is low power during live, it can be recharged directly through
Lightning port on the RX receiver. Devices with Type-C port do not support this
function.
Specifications
TX Transmitter
Transmission Frequency 2.4GHz
Transmission Distance ≥10m
Latency ≤20ms
Sensitivity -38dB±3dB
Frequency Response 20Hz-20KHz
Sampling Rate 48KHz
SNR ≤90dB
Standby Time 8H
Working Temperature -10℃ -50℃
Dimensions 15x57x15mm
Weight 7g
RX Receiver
Transmission Frequency 2.4GHz
Frequency Response 20Hz-20KHz
Dimensions 44x26x8mm
Weight 4g
