Summary of Contents for ABLEYE DW-HC-70
- Page 1 Handheld Real-time Camcorder III Model: DW-HC-70 （ V22.2 ） Operation Manual Drawell International Technology Limited Chongqing Drawell Instrument CO,.Ltd Add:Suite 2705,Building No.12,Shiyou Road No.1,Yuzhong District, Chongqing,China Tel: 0086-023-63268643 Shanghai Drawell Scientific Instrument Co.,Ltd Add : Suite 1117,Lane561XiuChuan Rd.,PuDong New Area,Shanghai,China Web : www.drawell-ableye.com...
- Page 2 SafeSafety Warnings and Precautions 1. Do not expose the equipment to rain, place it in a humid environment or spill any liquid on it to avoid damage to the equipment circuit. 2. Do not expose the device to direct sunlight and do not place the device near heat sources such as electric heaters.
-
Page 3: Table Of Contents
Content 1 Instructions ................3 1.1 Switch-on preparation ............3 1.2 Device Operation ............3 1.3 Wire Controller Instruction ............ 4 1.3.1 Extended Function Key List ..........4 1.4 Record/Playback ............5 1.5 Time Setting ..............6 2 File Export ................7 3 Equipment Charge .............. -
Page 4: Instructions
Instructions Switch-on preparation 1、Please read the "Safety Warnings and Precautions" carefully before turning on the machine and make sure that all the relevant matters mentioned are implemented! 2、First, select a flat ground, open the tripod, adjust the length of the three support brackets, so that the bubble in the top of the tripod level is in the right center position. -
Page 5: Wire Controller Instruction
1.3 Wire Controller Instruction The device is equipped with a specific wir3 controller for user-friendly operation. It contains the host operation keys and several extended function keys. 1.3.1 Extended Function Key List Icon Item Note Opening color night vision to open this function，compared to the color night vision mode, Starlight 1 mode can enhance image brightness and clarity (at Starlight 1... -
Page 6: Record/Playback
Confirm Press “CONFIRM” to keep the current selection Composite button, it is “PLAY/PAUSE” in playback mode; it is “PLUS 1” Composite each time in time setting mode. Minus it is “MINUS 1” each time in time setting mode. Exit Exit time setting or exit playback mode Record/Playback The following playback operation keys, are the same keys on the host and the same function on the line control, both can be operated;... -
Page 7: Time Setting
Time Setting Note: Time setting needs to be done through the wire controller. Step 1.Plug the wire controller into the hostline controller socket. Step 2.Press the "Time" button of the wire controller, the system time dialog box pops up on the host screen. -
Page 8: File Export
Right Shift Cursor moves to the right Minus it is “MINUS 1” each time in time setting mode Exit the current mode. Exit the time setting after confirmation. The Exit system will save the current setting, but not modify the system time, if not pressing “CONFIRM”... -
Page 9: Common Fault Analysis & Solutions
Attention： The device can only be charged with the factory-configured charger, do not use any other chargers. To ensure safety and extend the service life of the battery, please do not charge the battery at a temperature below 0℃ or above 40℃. If the battery is placed in a high or low temperature environment, such as in a closed car in summer or winter, it will reduce the battery capacity and shorten the battery life. - Page 10 Drawell International Technology Limited Chongqing Drawell Instrument CO,.Ltd Add:Suite 2705,Building No.12,Shiyou Road No.1,Yuzhong District, Chongqing,China Shanghai Drawell Scientific Instrument Co.,Ltd Add : Suite 1117,Lane561XiuChuan Rd.,PuDong New Area,Shanghai,China Tel: 0086-023-63268643 Web : www.drawell-ableye.com 第9页...
