Summary of Contents for Xoopla MS21Y-01
- Page 1 MS 21Y- 0 1 Instruction manual Xoopla handheld vacuum cleaner Before using the product, please read this instruction manual carefully and keep it for future reference.
-
Page 2: Security Notice
Security Notice When using this vacuum cleaner, basic safety precautions are need to be followed, Please read all instructions completely: Do not use the vacuum cleaner to clean the following objects: - Liquids - Large objects - Hard or sharp objects (glass, nails, screws or coins) - Large amounts of dust (including drywalls, fireplace ash or residual troubles). -
Page 3: Component Description
Component description 1.Vacumm 2.Combined flat brush 3.Square brush 4.USB type-C charging cable 5.Charging base... -
Page 4: Installation Instructions
Installation instructions Charging base installation 1.Please firmly insert the pillar into 2.Put the vacuum cleaner into the charging the socket of the base baes for charging. 4.In addition to the host, small square brushes 3.Charge the USB with adapter. and combination flat brushes can also be placed on the charging base Do not place the charging cable in a place where people are walking around. - Page 5 Instructions 1.When fully charged, press " " to start working. Press the mode button to switch large /small mode The 3 white LED lights are on constantly and the product starts to work; during the work, the indicator light is gradually reduced until the power is out. Power indicator Mode button Divided into large/small mode...
- Page 6 2.Vacuum cleaner instructions Combination flat brush Use a combination flat brush to suck away garbage in narrow places. Square brush When cleaning the sofa, use a small square brush...
-
Page 7: Charging Instructions
3.Charging instructions Charging base Install the charging base, plug in the power supply after plugging in the adapter, and put the product on the charging pad to charge. USB Charging Install the charging base, plug in the power supply after plugging in the adapter, and place the product on the charging pad to charge. - Page 8 Garbage cleaning Deep cleaning Light cleaning 1.The host is facing down to the trash can, You can first remove the dust cup from the press the dust pour button, and the dust host and pour the dust from the cup into cup lid opens automatically.
-
Page 9: Cleaning And Maintenance
Cleaning and maintenance 2.Remove the Hepa, metal filter and 1.Remove the dust cup from the body dust cup at one time Press the dust cup removal button to remove After removing the dust cup, hold the handle the dust cup. of Haipa and take it out in sequence as shown in the picture. -
Page 10: Fault Resolution
Fault Resolution Fault Possible causes Exclusion method Machine doesn’ t work Machine has no power Use after charging Insufficient power Make sure to be fully charged Suction is weak The dust cup is full Clean up the dust cup Hepa and other filter filled Clean hepa and other filter with dust system... - Page 11 The name and content of harmful substances in products Part Name/ (Pb) (Hg) （Cd） （Cr6+） （PBB） （PBDE） Hazardous Substance Shell parts Motor × Battery Internal wire metal parts This form has been prepared in accordance with st/T 11364. ○： Represents that the content of the hazardous substance in all homogeneous materials of the component is below the limit requirements specified by GB/T26572 ×：...
-
Page 12: After-Sales Service
After-sales service 1 year of warranty and professional lifetime support Email: fangsen666@outlook.com If you have any questions, please feel free to contact us. We will try to come up with a solution within 24 hours. If you like our products, please give a good reviews to us. This is our greatest encouragement and we are happy to receive any suggestions.
