Summary of Contents for Conductix-Wampfler MU-705
- Page 1 Instruction manual MU-705 Hand-held Programming Device Item number 3233528 CWA-60060967 MU-705 3226594 CWA-60060968 MU-705 3226595 CWA-60060969 MU-705 TF BDA_0005_MU-705_en www.conductix.com...
- Page 2 January 2023 The standard names, trade names, product names etc. used in this description may also be brand names even when not specially indicated and, as such, are subject to the statutory stipulations. © 2023 Conductix-Wampfler Automation GmbH BDA_0005_MU-705_en www.conductix.com...
-
Page 3: Table Of Contents
Characteristics and Design ...................... 11 Characteristics ........................11 Design ..........................12 Operation ........................... 13 Functioning ........................13 Switching on/off the MU-705 ..................... 13 The Menus ..........................14 Menu-Overview ......................... 14 Menu Parameters ......................15 4.2.1 Write Data ....................... 15 4.2.2 Read Data ....................... 15 4.2.3 Modify Data ...................... - Page 4 Instruction manual MU-705 Table of contents Menu Tag/Number ......................21 4.4.1 Tag .......................... 21 4.4.2 Number ........................21 4.4.3 Display ........................22 4.4.4 WNR/Ser ......................... 22 4.4.5 Type ........................23 Menu Tables ........................24 4.5.1 Write Table ......................24 4.5.2 Read Table ......................25 4.5.3 Modify Table ......................
-
Page 5: General Information And Safety
You can find the user manual and the software for the hand-held programming device as downloads on our website www.conductix.com. Please download the current “MU-705 Package” under Downloads/Software. This contains the user manual in several languages, the PC Software “MU-705 Utility”, as well as the necessary driver unit for the MU-705. BDA_0005_MU-705_en... -
Page 6: Symbols In The Documentation
Instruction manual MU-705 General information and safety 1.2 Symbols in the documentation There are warning instructions and symbols in this description. It is absolutely mandatory to comply with these and follow them. These are working aids and they will warn you of possible damage to property and personnel. -
Page 7: Limitation Of Liability
Any improper utilization is punishable by law. 1.5 Conformity Devices made by Conductix-Wampfler Automation GmbH have been designed to comply with EU di- rectives. Please contact Conductix-Wampfler Automation GmbH if you wish to obtain a copy of these EU decla- rations of conformity. BDA_0005_MU-705_en www.conductix.com... -
Page 8: Proper Use
Instruction manual MU-705 General information and safety 1.6 Proper use The Hand-held programming device MU-705 is used to programming, parameterizing and manually control Conductix/LJU devices. Warning! Danger due to improper use! Any improper use and/or different use of the device can lead to dangerous sit- uations. -
Page 9: Warranty
Internet; see contacts on the inner side of the covering sheet (page 2). 1.10 Modifications and alterations To avoid danger and to ensure optimal performance, no modifications, remodelling or add-ons are al- lowed on the device unless expressly approved by Conductix-Wampfler Automation GmbH. Warning! Risk of injury due to design modification! Unauthorized technical modifications can lead to considerable damage to per- sons and property. -
Page 10: Personnel And Qualification
Instruction manual MU-705 General information and safety 1.11 Personnel and qualification Warning! Risk due to improper use! Improper operation can lead to serious damage to persons or property. Therefore: It may be operated only by qualified technical personnel. During manual operation, ensure that there is no risk to persons from the manual operation and that there are no persons in the working area of the vehicle. -
Page 11: Characteristics And Design
The data is transmitted between the MU-705 and the controller by means of infrared and is thus com- patible with the controllers of the product lines 6xx, 7xx with corresponding software and with all con- trollers of the latest generation 8xx. -
Page 12: Design
▪ The housing of the hand-held programming device MU-705 is made of impact-resistant material. ▪ The MU-705 has a clearly visible LCD-display and a user-friendly membrane keypad ▪ The 18 buttons of the keypad are embossed, which prevents the buttons from being accidentally pressed with the correct amount of pressure. -
Page 13: Operation
3 Operation 3.1 Functioning The 18 buttons of the MU-705 are used not only for inputting the vehicle parameters but also for re- mote controlling and acknowledging errors. The arrow keys are used for scrolling through the menus. You can go ▪... -
Page 14: The Menus
4 The Menus 4.1 Menu-Overview After the MU-705 is switched on and the controller type is selected (see also point 4.2.3), the MU-705 display appears, which consists of serially numbered menu items, an information bar and a scroll dis- play. -
Page 15: Menu Parameters
Instruction manual MU-705 The Menus 4.2 Menu Parameters 1. Write Data 2. Read Data 1. Parameters 3. Modify Data 4. Verify Data Note! The controller type configured in the MU must necessarily match with the con- troller description. (see point 4.2.3/3) 4.2.1 Write Data... -
Page 16: Modify Data
Instruction manual MU-705 The Menus 4.2.3 Modify Data 1. Data 3. Modify Data 2. Configuration 3. Type Caution! Important controller settings are changed in this menu item. Notes pertaining to the settings are to be taken from the separate software description of the used controller. -
Page 17: Verify Data
The type stored in the MU is deleted by pressing the button F3 [Delete]. 4.2.4 Verify Data The option “Verify Data” compares the checksums of the parameter records of the controller and that of the MU-705. 1. Select menu item. 2. Establish infrared communication. -
Page 18: Menu Test
In this mode, the MU-705 can substitute the manual remote operation to a certain extent and control the vehicle remotely; the range is however limited to one meter. -
Page 19: Ir Test
3. Send the protocol (e.g. press the button) from the test device. 4. The received protocol appears in the display. Other MU, LBS (read-write station) and remote controls are supported. 4.3.4 BIOS Exceptions Evaluation of software error messages Controller-BIOS. DEBUG information for the Conductix-Wampfler staff. BDA_0005_MU-705_en www.conductix.com... -
Page 20: Error Log
3. Press F1 [Yes] to delete the error log in the controller. 4.3.6 Memory This menu item reads individual memory areas. The read information is used for the memory management of the controller software and is used only by the Conductix-Wampfler staff. BDA_0005_MU-705_en www.conductix.com... -
Page 21: Menu Tag/Number
Instruction manual MU-705 The Menus 4.4 Menu Tag/Number 1. Tag 2. Number 3. Display 3. Tag/Number 4. WNR/Ser 5. Type 4.4.1 Tag In this menu item, target details of the system control (project-dependent) can be read from or written into the vehicle controller. -
Page 22: Display
Function not available. 4.4.4 WNR/Ser Writes the plant number WNR and serial number SER into the controller. Only for internal use, password-protected by Conductix-Wampfler! Read WNR/Ser! The plant and serial number is read via the menu item “BIOS info” (see point 4.7.1). -
Page 23: Type
Instruction manual MU-705 The Menus 4.4.5 Type This menu item is used to read out the car type and extra type (project specific) from the car control or to write the car type and extra type to the control. Read car type and extra type: 1. -
Page 24: Menu Tables
Instruction manual MU-705 The Menus 4.5 Menu Tables 1. Write Table 2. Read Table ..-Tab 3. Modify Table 4. FCS ..-Tab 3. Tab. group 4. Tables 5. Clear Table 4. Tab. group 5. All 1. Write 2. Read 3. FCS The Tables menu contains the tables pre-defined for the project, like e.g. -
Page 25: Read Table
After the changes are made, the new values can be transferred to the controller as described under point 4.5.1 or 4.5.6/1. 4.5.4 FCS The option “FCS” compares the checksums of the table of the controller and that of the MU-705. 1. Select menu item. 2. Establish infrared communication. -
Page 26: Clear Table
Instruction manual MU-705 The Menus 4.5.5 Clear Table Go to the menu item “Clear Table” and then confirm the question ‘Clear?’ by pressing the button F1 [Yes] to delete the content of the currently displayed table in the MU. If the content of the table need not be deleted, cancel the operation by pressing F3 [No] or ESC. - Page 27 MU-705 The Menus 3. FCS The option “FCS” compares the checksums of the tables of the controller and that of the MU-705. 1. Select menu item. 2. Establish infrared communication. 3. Wait till the checksums appear in the display of the MU.
-
Page 28: Menu Mu Config
4. Backlight 5. Infrared 4.6.1 Language Selection menu for the interface language of the MU-705. You can select using the arrow keys or directly select the number keys 1 – 4. Select the desired language button for accepting a language setting. -
Page 29: Infrared
Instruction manual MU-705 The Menus 4.6.5 Infrared Only MU-705 (WNR CWA-60060967) In this menu, the transmission speed for infrared communication is set. The selection is made with the function keys F1 and F3 keys. F1 [IR] Slow infrared (9600 bit/s) -
Page 30: Bios Info
Displays information about the MU and general information. More information can be called by pressing the function keys F1 – F3. Display of start screen Conductix-Wampfler Automation GmbH - Contacts Size and type of the internal flash memory BDA_0005_MU-705_en www.conductix.com... -
Page 31: Menu Program Files
If an incompatible software is downloaded, the vehicle controller reports this - after it is switched on - by displaying “U - - -“. The operating manual of the MU-705 Utility contains detailed information about downloading of the USER-software into the MU. -
Page 32: Password
Instruction manual MU-705 The Menus 4.7.2 Password The access rights for special functions, like e.g. program download is assigned through this menu. Input a password for this. The rights are enabled so long as the switched-on state of the MU continues. -
Page 33: Menu Accessories
4.8 Menu Accessories 1. Timer 8. Accessories 2. Calculator 3. Applications 4.8.1 Timer The MU-705 contains a stop clock with four time measurements. F1 [Start] Start, new start of the four time measurements simultaneously F2 [Reset] resets the four measurements F3 [Stop]... -
Page 34: Menu Identification (Only St-8Xx)
Instruction manual MU-705 The Menus 4.9 Menu Identification (only ST-8xx) 1. R L Parameter 9. Identification 2. Controller Params 3. Angle 4.9.1 R L Parameter This menu item is used for enabling automatic recognition of the stator resistance and the stator in- ductance of a motor that is connected to the control. -
Page 35: Controller Params
Instruction manual MU-705 The Menus 4.9.2 Controller Params This menu item is used to automatically adjust the control parameters for the drive system. Caution! This menu item is used to change important control settings. For information on the settings, please refer to the separate description of the control used. -
Page 36: Angle
Instruction manual MU-705 The Menus 4.9.3 Angle This menu item is used to automatically recognise an angle offset between the motor encoder and the rotor position, to read it out from a control and to write it in a control. -
Page 37: Technical Information
3223944 3224633 CWA-60760967 CWA-60060888 CWA-60608101 Content 1 x MU-705 1 x MU-705 1 x MU-705 TF (3233528) (3226594) (3226595) 1 x battery pack 1 x battery charger extension 1 x plug-in battery charger with adaptors 1 x USB cable BDA_0005_MU-705_en... -
Page 38: Device Drawing
Instruction manual MU-705 Technical information 5.2 Device drawing BDA_0005_MU-705_en www.conductix.com...
