- Page 1 User Manual PowerGate Arma PGA-0-D, PGA-0-2D, PGA-0-4D Version 1.04 March 11, 2020...
-
Page 2: Table Of Contents
PowerGate Arma Waterproof DMX/ArtNet/sACN over Powerline transceiver Contents Specifications Safe operation General information Advantages Wireless network configuring Indication Connection scheme Technical maintenance Notes... -
Page 3: Specifications
PowerGate is a series of transceivers employing existing power lines (110V/220V) to transmit DMX signal using PWRDMX technology introduced by Sundrax. PWRDMX eliminates the need of new cabling. Connected to the same power network, PowerGate devices form a network for reliable... -
Page 4: Advantages
PowerGate Arma Waterproof DMX/ArtNet/sACN over Powerline transceiver Advantages DMX512 via 220/110 V transceiver Die-cast metal casing No buttons Full galvanic isolation Up to 400 m transmission range The devices supplied are configured as data transmitters to the 230/110V power line (hereinafter referred to as the «transmitter») or as data receivers from line (hereinafter referred to as the «receiver»). -
Page 5: Wireless Network Configuring
PowerGate Arma Waterproof DMX/ArtNet/sACN over Powerline transceiver Normal operation of the device in any mode starts immediately after switching power on. Wireless network configuring (receiver) 1. At power-on the receiver waits for a connection request from the transmitter. In this state the green LEDs on it lights steadily. -
Page 6: Connection Scheme
PowerGate Arma Waterproof DMX/ArtNet/sACN over Powerline transceiver Connection scheme Transmitter POWER IN ArtNet/sACN/Other DMX 1 A COM B DMX 4 DMX 3 DMX 2 A COM B A COM B A COM B ETHERNET SWITCH ArtNet/sACN/Other Electric socket 100-270 V 100-270 VAC Electric socket 100-270 V 100-270 VAC... -
Page 7: Technical Maintenance
Maintenance, search and troubleshooting should be performed by service personnel. The device should be free from dirt, dents, connecting cables and wires must be intact and securely fastened. Notes Please send all your warranty-related questions to support@sundrax.com All Sundrax products are covered by a 36 months warranty. - Page 8 PowerGate Arma Waterproof DMX/ArtNet/sACN over Powerline transceiver Sundrax Electronics 6008, First Central 200 2 Lakeside Drive, Park Royal, London NW10 7FQ United Kingdom + 44 (0) 208 991 33 19 office@sundrax.com www.sundrax.com...
