- Page 1 DNCP Solutions, LLC - A Platinum Equity Company U916 T1/E1 PCI Card Installation Guide Part Number: MAN0064-00...
- Page 2 This document contains information that is the property of DNCP Solutions, LLC. This document may not be copied, reproduced, reduced to any electronic medium or machine readable form, or otherwise duplicated, and the information herein may not be used, disseminated or otherwise disclosed, except with the prior written consent of DNCP Solutions, LLC.
-
Page 3: Table Of Contents
Contents About This Guide Purpose Audience Revision Information Operating System Information How to Use This Guide Notation and Terminology Conventions Product Documentation Related Books Software Hardware A Note on the Contents of DNCP Books Ordering Documentation How to Send Comments About This Document Customer Assistance Center xiii 1. - Page 4 Contents 3. Troubleshooting Getting Help Interpreting the PCI Card Cage Status Lights Interpreting The U916 PCI Card Status Light Index Index-1 U916 T1/E1 PCI Card Installation Guide (MAN0064)
- Page 5 Figures Figure 1-1. Top and Bottom Views of the U916 4-Port T1/E1 PCI Card 1-2 Figure 1-2. Location of PCI Card Cages Figure 1-3. Location of PCI Cards Figure 1-4. Grounding-Strap Jacks Figure 1-5. RJ-48C Connector Figure 1-6. T1/E1 Hardware Components Figure 1-7.
- Page 7 Tables Table 3-1. PCI Card Cage Status Lights Table 3-2. LED Messages Tables...
-
Page 9: About This Guide
Office system.) Procedures are provided for the cabinet version of the DNCP Series 400/400-CO systems. Audience This guide is intended for DNCP Solutions customers who are installing or maintaining a U916 T1/E1 PCI card in a DNCP Series 400/400-CO system. Revision Information This is the first edition of this document. -
Page 10: How To Use This Guide
DNCP Series 400 and 400-CO: D859 CD-ROM Drive: Installation and Operation Guide (MAN0052) • DNCP Series 400 and 400-CO: T807/T808 Tape Drive Release Notes (MAN0053) • DNCP Series 400 and 400-CO: D84X Disk Drive Release Notes (MAN0054) U916 T1/E1 PCI Card Installation Guide (MAN0064) -
Page 11: Related Books
U512 Ethernet PCI Card Installation Guide (MAN0061) • U522 Ethernet PCI Card Installation Guide (MAN0063) • U916 T1/E1 PCI Card Installation Guide (MAN0064) Related Books In addition to this document, the following documentation contains information related to the DNCP fault-tolerant platforms and supported operating systems:... -
Page 12: Hardware
DNCP books document all of the subroutines and commands of the user interface. Any other commands and subroutines contained in the operating system are intended solely for use by DNCP Solutions personnel and are subject to change without warning. Ordering Documentation... -
Page 13: Customer Assistance Center
About This Guide Customer Assistance Center You may contact the DNCP Solutions Customer Assistance Center (CAC) , 24 hours a day, 7 days a week by calling one of the phone numbers listed below. Service Area CAC Location Phone Number... -
Page 15: Overview
Chapter 1 Overview This chapter provides an overview of the U916 PCI card and peripheral component interconnect (PCI) cards in general. This chapter contains the following sections: • U916 4-Port T1/E1 PCI Card • Locating the PCI Cards • Handling PCI Cards •... - Page 16 U916 4-Port T1/E1 PCI Card Figure 1-1 shows the U916 PCI card. Voltage Regulator Voltage Backplane Regulator Connector Component Side gm0708 Figure 1-1. Top and Bottom Views of the U916 4-Port T1/E1 PCI Card U916 T1/E1 PCI Card Installation Guide (MAN0064)
-
Page 17: Locating The Pci Cards
Locating the PCI Cards Locating the PCI Cards The PCI cards in a DNCP Series 400/400-CO system are installed in one of two PCI card cages, which are located in the rear of the cabinet (Figure 1-2) Rear of PCI Card Cages System Card Card... - Page 18 Slot Labels (slots Status Cards 4-6) Lights (slots Optional 1-3) Optional Cards (slots Cards 4-6) (slots Yellow 1-3) Green PCI Card Cage 2 PCI Card Cage 3 cp0398 Figure 1-3. Location of PCI Cards U916 T1/E1 PCI Card Installation Guide (MAN0064)
-
Page 19: Handling Pci Cards
Handling PCI Cards Handling PCI Cards PCI cards are extremely sensitive to electrostatic discharge. To avoid damaging a PCI card during handling, take the following precautions. C A U T I O N Do not walk around carrying a PCI card that is not in its static-protective envelope. - Page 20 Handling PCI Cards Grounding-Strap Jack Rear of System cp0254 Figure 1-4. Grounding-Strap Jacks U916 T1/E1 PCI Card Installation Guide (MAN0064)
