Summary of Contents for DoorHan BARRIER-N
-
Page 1: Table Of Contents
General information Safety rules Barrier unit Installation Release operation Maintenance Troubleshooting Barrier BARRIER-N Installation and Operation Manual © DoorHan, 05.2020... -
Page 2: General Information
GENERAL INFORMATION 1. GENERAL INFORMATION Barrier is ideal for managing access points in residential and industrial areas in moderate to heavy traffic. It suits for passage clearances of up to 6 m. The barrier cabinet has only one spring if the boom length doesn’t exceed 3 and 4 m. If the boom length is 6 m a second spring should be installed. - Page 3 ƒ DoorHan Company assumes no liability for unstable operation of the automatic system when using safety devices and accessories produced by other than DoorHan manufacturers without the approval of DoorHan. ƒ Only original DoorHan spare parts and accessories shall be used, as other manufacturers accessories may cause the au- tomatic system to malfunction.
-
Page 4: Barrier Unit
BARRIER UNIT 3. BARRIER UNIT 1. Logo plate 5. Boom fastening plate 9. Control block 2. Hex bolt 6. Boom 10. Cabinet top cover 3. Boom cover 7. Cabinet 11. LED lamp 4. Hex bolt 8. Side cover up to 6 000 mm up to 6 m 300 mm 300 mm... - Page 5 INSTALLATION 4.2. INSTALLATION GUIDELINES Follow the directions given below to install the barrier properly: ƒ Enter the guarded territory and choose the place for the barrier cabinet. ƒ Make sure that nothing impedes the boom travel (i.e. tree branches) and a safe clearance distance of at least 2 m is provided between the tip of the barrier boom and the overhead power lines.
- Page 6 INSTALLATION 4.4. ADJUSTMENT OF BOOM EXTREME POSITIONS 4.4.1. Setting the boom closed position (red cam) ƒ Verify the barrier is fixed rigidly. Move the barrier to the manual control mode and move the boom to the closed position. ƒ Loosen the screw (pos. 1) which fastens the cam of the boom closed position. ƒ...
-
Page 7: Release Operation
ƒ The Barrier automatic system does not require any special servicing. ƒ Repairs may be carried out only by a qualified technician trained and certified at an authorized DoorHan centre. ƒ The installer shall supply all information concerning manual operation of the system in case of an emergency, and shall hand over to the User the Manual supplied with the product. - Page 8 For information on purchasing, distribution and servicing contact DoorHan central office at: 120 Novaya street bld. 1, Akulovo village, Odintsovo district, Moscow region, 143002, Russia Phone: +7 495 933-24-00 E-mail: info@doorhan.com...
