- Page 1 User Manual Portable Solar Panel www.marxon.net...
- Page 3 User Manual, the company(“Marxon”) is not liable for any damages caused. In compliance with laws and regulations, Marxon holds the final explanation right of this document and all related documents of the product. For the latest product information, please visit Marxon's official website at www.marxon.net.
-
Page 5: Table Of Contents
CONTENTS 1. Safety Guide 2. Specifications 3. Connection Methods 3.1. Connecting Single Solar Panel to the Power Station 3.2. Parallel Connection 3.3. Series Connection 4. FAQs 5. What’s in the Box... -
Page 6: Safety Guide
1. Safety Guide Don't contact with strong corrosive substances. Avoid hard or sharp objects hitting and scratching the surface during use or storage. Don’t step on it. Don't bend during transportation, assembly, or operation. Don’t immerse the product in water. When using the product, please strictly follow the operating environment temperature specified in this user manual. -
Page 7: Specifications
2. Specifications 100W Technical Specifications Product Model NO. PETC-S100 Peak Power 100W Tolerance ±10% Cell Type MONO Conversion Efficiency 21.5-23.5% Power Voltage (Vmp) Power Current (Imp) 5.5A Open Circuit Voltage (Voc) 24.5V Short Circuit Voltage (Isc) 6.1A Output Port Operating Temperature Range -10°C~65°C... -
Page 8: Connection Methods
Connect the negative pole of the Solar MC4 Connection Cable to the positive pole of the MC4 to Anderson Connection Cable. Step 3: Connect the MC4 to Anderson Connection Cable to the Anderson Input Port on the Marxon portable power station. -
Page 9: Parallel Connection
Anderson Connection Cable. Step 3: Connect the MC4 to Anderson Connection Cable to the Anderson Input Port on the Marxon portable power station. Note:For the parallel use of two or more solar panels, please confirm the output power, voltage, and... -
Page 10: Series Connection
Connect the negative pole of B solar panel to the positive pole of the MC4 to Anderson Step 3: Connection Cable. Connect the MC4 to Anderson Connection Cable to the Anderson Input Port on the Marxon Step 4: portable power station. -
Page 11: Faqs
Please note that applying external pressure to solar panels may damage them and reduce their output. Can Marxon solar panels store power themselves? Solar panels convert solar energy into electricity instead of storing it and sending it to Marxon power stations. 5. What’s in the Box... - Page 12 Scan the QR Code to Learn More About US. www.marxon.net...
