- Page 1 IM220 V1.0 Digital output Module User Manual www.intelart.ir 08/2021...
- Page 2 Warning notice system This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert symbol, notices referring only to property damage have no safety alert symbol.
-
Page 3: Table Of Contents
Contents Technical Specifications ......................1 Hardware Parameters ...................... 1 Configurations ......................... 2 Digital Inputs ..............Error! Bookmark not defined. Digital Outputs ......................... 2 2.2.1 Pulse width modulation (PWM) ................2 2.2.2 Pulse train ......................... 4 2.2.3 Stop action ........................ 4 Address Space ......................... -
Page 4: Technical Specifications
IM220 user manual 1 Technical Specifications 1.1 Hardware Parameters The following table specifies the hardware information of the module. Table 1 Hardware parameters Outputs count Type of digital output Isolated transistor (sinking) Type of output voltage Operating voltage 5 to 30 V... -
Page 5: Configurations
IM220 user manual 2 Configurations 2.1 Digital Outputs The outputs of the module can configure in order to execute another function. 2.1.1 Pulse width modulation (PWM) The output channels are grouped in 4 clusters. Each group has its own PWM frequency setting in the properties window of the module. - Page 6 IM220 user manual Figure 1 PWM frequency setting The pulse waveform is slightly wider than the ideal pulse waveform for a resistive load. The following figure shows the ideal PWM signal versus the actual signal waveform. The ideal signal is specified by the blue line and the actual waveform is figured by the dashed line. The duty cycle can vary from 0% to 100%.
-
Page 7: Pulse Train
IM220 user manual 2.1.2 Pulse train The pulse train function generates a configurable PWM signal with duty cycle of 50% and specified pulse count. The period of the PWM signal is a factor of 200µs. 2.1.3 Stop action Each output channel has a property named “StopAction” which determines the act of channel when PLC state changes to stop mode. -
Page 8: Address Space
IM220 user manual 3 Address Space The value of input channels and output channels and some configurations will be accessible via an address space. There are bunch of predefined mapped tags in order to read or write a value in the address space. The following table illustrates the type and purpose of each mapped tag. - Page 9 IM220 user manual PulseStartQ00 %Q8.0 ⋮ ⋮ BOOL Starts the pulse generating process PulseStartQ07 %Q8.7 PulsePeriod00 %QW4 PulsePeriod01 %QW12 Sets or gets the value of pulse period. PulsePeriod02 %QW20 Note that the value is a factor of 200µs. PulsePeriod03 %QW28...
-
Page 10: Diagnostic And Wiring
IM220 user manual 4 Diagnostic and Wiring The module has 2 LEDs indicating the status of module. The following table explains the combination of these two LEDs state. Table 5 Combination of "POWER" and "MAINT" LEDs Indicating Solution POWER MAINT ... - Page 11 IM220 user manual The following block diagram shows you information about wiring of the module. Figure 3 Wiring diagram and terminal assignments Digital outputs DQx: Digital output terminal POWER: Power LED MAINT: Maintenance LED...
-
Page 12: Dimensional Drawing
IM220 user manual 5 Dimensional drawing The dimensions of the module are available in this section. For install the module and its main device follow the below dimensional drawing. Figure 4 Dimensional drawing of IM220 module...
