Page 3: Table Of Contents
Table of Contents Introducing PowerSight ............. 9 Connecting to PowerSight ............10 Voltage Test Leads ..................10 Current Probes .................... 11 Connections to PowerSight ............... 13 Introduction to Power Delivery Configurations ........15 Connecting to Single-phase Power ............17 Connecting to 120 V Outlet Adapter Box ..........18 Connecting to Multiple Single-phase Loads ..........
Page 4 Frequency Measurements in PowerSight ..........81 Frequency Measurements in PSM ............81 Duty Cycle / Power Cycle Measurements ..........82 Duty Cycle / Power Cycle Measurements in PowerSight ...... 83 Time and Capacity Measurements ............83 Time and Capacity Measurements in PowerSight ......... 85 Time and Capacity Measurements in PSM ..........
Page 5 Setting Measurement Types ..............121 Setting Measurement Modes ..............122 Saving and Retrieving Data Setups to File or PowerSight in PSM ..123 Loading Data Setups from the Memory Card (SD Card) ....123 Saving Data Setups to the Memory Card (SD Card) ......124 Restoring the Default Setup ..............
Page 6 Remote Control of PowerSight ..............156 Locating and Installing Software and Firmware ........157 Setting up Administrative Features of PowerSight via PSM ....158 Setting Operational Features of PSM ............ 158 Putting it all Together (Monitoring for the First Time) ..159 Working with Graphs and Waveforms ........
Page 7 Advanced Motor Diagnostics Option ........173 Introduction ....................173 Capturing On-Line Motor Data ..............173 Frequency Analysis Option ........... 175 Overview of the Keypad Functions ........176 Compatibility Guide ..............178 Specifications* ................ 180...
Page 9: Introducing Powersight
You have just purchased one of the smallest and yet most powerful instruments for measuring and analyzing electric power that exists. The PS4500 is a complete solution for the measurement and analysis of all aspects of power: ♦ High-speed transient analysis ♦...
Page 10: Connecting To Powersight
Voltage Test Leads A Deluxe Voltage Probe set consisting of four leads is included with each PowerSight. Each of the voltage test leads is 6 feet (2 meters) long, with safety banana jacks at one end and safety plunger clamps at the other end. Each is labeled at both ends as...
Page 11: Current Probes
Probes such as the HA1000 are excellent choices to use with PowerSight because they support all the accuracy specifications of the product. For instance, the HA1000 has an accuracy of 0.5% whereas many probes on the market have an accuracy of 2- 3%.
Page 12 The HA100 probe is the same compact size as the HA5. The HA100 measures from 0.1 to 100 amps at 2% accuracy. It is a good choice over the HA1000 if you wish to lock PowerSight, its leads, and current probes inside a power panel that you are monitoring.
Page 13: Connections To Powersight
Any dirt or rust will affect the accuracy of the measurements! Connections to PowerSight Voltage test leads plug into the top end of PowerSight. Each test lead of the Deluxe Voltage Test Lead set is labeled (V , or...
Page 14 Current probes plug into the top end of PowerSight, just above the voltage inputs. Each current probe is labeled (I , or I ) and each jack is similarly labeled (I , or I ). When plugging a current probe into PowerSight, the flat side of the plug should be facing upwards so the label is readable.
Page 15: Introduction To Power Delivery Configurations
Introduction to Power Delivery Configurations Figure 1 presents most common power delivery configurations. PowerSight is able to measure voltage, current, power, power factor, and more for all of these systems. Figure 1A presents the normal single- phase and split-phase service as found in a residential service.
Page 16 Connections to an Open Delta Circuit (2PT/3CT)figure Although phase-to-phase is the normal voltage measurement mode for this service, PowerSight can be set to phase-to-neutral (even though the neutral is not connected). In this case, the measured voltages will be phase-to-metering-neutral (such as V = 277V for a 480V service) and all other measurements will also be correct.
Page 17: Connecting To Single-Phase Power
1 power and phase 1 power factor. Caution: Until you are certain that your voltage connections to PowerSight are correct, disconnect any current probes. This is because PowerSight and all of its connections float at the potential of V . If V is "hot", there may be a breakdown through the insulation of any attached probes.
Page 18: Connecting To 120 V Outlet Adapter Box
PowerSight are as shown in figure 2, V will be some relatively large number like 120 volts and V will be a small voltage like 3 volts. If you then reverse the ground and neutral leads, V will now read slightly less, like 117 volts. If "hot" and "neutral"...
Page 19: Connecting To Multiple Single-Phase Loads
Note: The 120ADPa is rated for continuous duty of up to 15 Arms. Do not exceed this continuous load. To evaluate the power usage of an appliance, simply plug the appliance into the top of the 120 V Outlet Adapter Box after the other connections have been made and verified.
Page 20: Connecting To Split-Phase (Two Phase) Power
In this configuration, the voltage, current, and power of each load can be displayed directly or graphed on your PC using our PSM software. Connecting to Split-Phase (Two Phase) Power Fig 5 shows the recommended connections to a split-phase system as found in commercial and residential facilities, when measuring the supply to two single phase...
Page 21: Connecting To Three-Phase Four-Wire (Wye) Power
change the measurement mode to phase-phase, V will be the hot-to-hot voltage that serves the high power appliance. Connecting to Three-Phase Four-Wire (Wye) Power Figure 6 presents the recommended connections to a three-phase system with voltages referenced to neutral, a "phase-neutral"...
Page 22: Connecting To Three-Phase Three-Wire (Delta) Power
Connecting to Three-Phase Three-Wire (Delta) Power Figure 7 presents the recommended connections to a three-phase system with voltages referenced to each other instead of to neutral. This is a "delta", "phase- phase", or “three- phase three-wire” configuration. Be sure to follow the safety warnings of the previous...
Page 23: Connecting To Three-Phase Four-Wire Delta Power
It also provides 208V. Depending on what you intend to monitor, it may be appropriate to set PowerSight in phase-phase voltage measurement mode (to monitor three-phase loads or to look at total power) or in phase-neutral voltage measurement mode (to monitor single phase loads).
Page 24: Connections Using 2 Current Approach
A necessary use for this type of connection is to measure utility power where only two metering CTs and three PTs are provided. After hooking up to the CTs and PTs, you enter the input ratios into PowerSight (see the Setting Input Ratios section) in order to record the correct values (the values on the primary side of the transformers).
Page 25: Connections To A 3 Ct / 3 Pt Metering Circuit
Connections To a 3 CT / 3 PT Metering Circuit Sometimes it is helpful to monitor a load indirectly, by connecting PowerSight to a metering circuit in front of the load. A few circumstances where this is the case are: ...
Page 26  the voltage delivered to the load exceeds the 600Vrms rating of PowerSight and you do not have other high voltage probes. A typical metering circuit showing PowerSight connected is shown in figure 9. This circuit has three CTs and,...
Page 27 This in turn allows accurate power and cost readings without having to multiply the results times some ratio. Remember that these ratios are reset to 1:1 whenever PowerSight is turned off. Similarly, the PTs take a primary voltage and step it down to a secondary value.
Page 28: Connections To A 2 Ct / 2 Pt Metering Circuit
If you clamp onto the CTs, rather than clamping onto each of the primary currents directly, PowerSight must be operating in the 2 Current Probe mode of operation (see the Phase-Neutral vs Phase-Phase vs 2 Current Mode section). Connections To an Open Delta (3CT / 2PT) Metering Circuit In the open delta configuration, two PTs and 3 CTs are available.
Page 29: Connecting To Line-To-Dc (Ldc) Converter Accessory
PowerSight. The LDC comes with two long red input leads that end with a stackable safety banana plugs. These stackable plugs are to be inserted directly into two of the inputs of PowerSight. If you are monitoring power without a neutral, we recommend...
Page 30 The fuses are the only circuit protection for the LDC. When the input side of the LDC is fully connected properly, plug the long DC output plug into the DC input jack of PowerSight. The...
Page 31: Measuring Multiple Parallel Conductors
red charging indicator near the jack will light up if everything is operating and connected properly. Note: If a fuse is burned out or missing, it will appear that there is no voltage at the source. Verify that the fuses are working properly before assuming that the source is dead.
Page 32 2. Start monitoring for 10 seconds or so and then stop monitoring (see the Starting Data Logging Stopping Data Logging sections). 3. Press the [Current] key and then the [More] key four times to view the average current for phase 1 (which is actually just one of the conductors of one of the phases).
Page 33: Measuring Currents Below The Range Of The Current Probe
If you use this method, set the input ratio for the current probe to 1 : 2 (see the Changing Input Ratios in PowerSight section). If the current to be measured is small, it may be acceptable to...
Page 34: Turning Powersight On
If you wish to operate PowerSight without being tethered to a power outlet, the Line-to-DC converter accessory (order LDC4) offers the ability to power a PS4500 (or any model except the PS3000) directly off the line voltage being monitored. It works with 50 Hz and 60 Hz power, operating off 100 to 480 Vrms input, single-phase or three-phase.
Page 35: Turning Powersight On
Turning PowerSight Off To turn PowerSight off, simply press the green on/off button at the lower right of the keypad on the front panel. This provides a graceful software/firmware shutdown. If pressing the button briefly does not turn the meter off, press the on/off button down and hold it down for 3 seconds to force a hardware shutdown.
Page 36: Communicating With Powersight
Communicating with PowerSight Introduction The PS4500 uses Bluetooth wireless communications to communicate with your PC. There are several advantages to this method:  safety enhancement - since there are no metallic connections between the meter and your PC (part of what allows your...
Page 37: Step 1: Connecting To The Meter At The Operating System Level
“My Bluetooth Devices”. Click on it and if you have previously communicated with your meter, an icon for your meter will probably appear. It will have a name of “PS4500- nnnnn”, where “nnnnn” is the serial number of your meter. If it does not appear, click on an option like “Discover”...
Page 38: Step 2: Connecting To The Meter In Psm (The Application Level)
COM7). Remember this port identifier; you will need it for the next step, connecting to your PSM software. Note: Whenever you close PSM or turn your PowerSight meter off, you will break the connection between your meter and Windows. Once your meter is turned on, you will need to double...
Page 39 with your meter, then click on the COM7 entry and then OK. PSM will automatically attempt to connect to your meter at this point. If it is successful, the communications status box with display a yellow banner with the words “Attempting to Connect”.
Page 40: Using Removable Memory Cards
If the feature is not enabled on your meter, it is a free upgrade. Go to our website and download the latest firmware for your meter (http://www.powersight.com/downloads/index.cfm?list=Firmware). Be sure that you PSM software is version 3.3 or higher. Operation and Limitations ...
Page 41: Using The Memory Card Data With Psm
Do not change the location of the files and folders that are automatically created when the card is inserted into the meter. Any changes will likely make the data impossible for your PowerSight Manager (PSM) software to locate them. Using the Memory Card Data with PSM...
Page 42 on the drive number assigned by your computer to your card reader and locate the data of interest. Browse the card to find the data you want to receive. The data is organized in the following hierarchy of folders:  Serial Number –...
Page 43: Verifying Connections Using Powersight (Surestart Tm )
There are two primary methods for doing this. You may either send waveforms from PowerSight to your PC and visually check that all connections are correct and all signal levels and shapes...
Page 44 1/3 of the power of a three-phase system), the probe may be misidentified (resulting in current readings of a fraction or a multiple of the correct value), or the display may say “I input too large” and PowerSight will refuse respond to any keypad button. ...
Page 45: Identifying The Power System
Identifying the Power System After the SureStart feature is done analyzing the inputs, the type of power system that is present is displayed on PowerSight. Check that you agree that PowerSight has identified the system correctly. If it hasn’t, there is probably a problem with the system or the connections.
Page 46: Error Summary
(they will have been shifted 60 degrees). So PowerSight might report “no errors detected”, and with good reason, but the connections are very incorrect. Similarly, if all of...
Page 47  Probe not connected. The probe that is identified appears to not be connected to PowerSight. Check that the probe is firmly connected to both PowerSight and to the power system. ...
Page 48 Wrong frequency setting. PowerSight is expecting one frequency, but it is measuring another. The display of this error tells the frequency mode that PowerSight is set for and then displays the actual frequency that is measured. Use PSM to set the frequency mode to the correct setting.
Page 49: Checking Out Connections Using Psm
Checking out Connections using PSM The PowerSight Manager (PSM) software is included in the cost of your PowerSight meter. You can use it to visually determine if the system connections and levels are correct. Use PowerSight’s patented SureStart feature for a fast reliable approach to checking that connections and settings are correct.
Page 50: Check Voltage Phase Sequence - Using Psm
PowerSight, this measurement is in reference to the neutral point between all the phases that are connected. If the measurement mode is phase-phase (as shown in the example), the labels will be V , and V is the voltage potential between phases 1 and 2.
Page 51: Checking Current Levels - Using Psm
An order of 2-3-1 or 3-1-2 is the same as an 1-2-3 sequence; the reference point just starts at a different place (for instance 2-3- 1 is just a portion of the continuing sequence of 1-2- 3-1-2-3). Sometimes an order of 3-2-1 is correct.
Page 52: Checking I Phase Sequence - Using Psm
waveforms that may be seen are shown in the Checking Phase Lag – Using PSM section below. Checking I Phase Sequence – Using PSM While still viewing all current waveforms of a three-phase system, notice how they reach their peak value. Each of the peaks should be the same distance from each other (similar to as shown in the Checking Voltage Sequence –...
Page 53 90 degrees. Next select a view of “phase 2” only and then “phase 3” only. In each case, note the time delay between the peak voltage and the peak current. It should be close to the same. If one current leads voltage and the other two currents lag voltage by different amounts, then two of the voltage or current...
Page 54: Measurement Types
Measurement Types Voltage Measurements Voltage is the difference in electromotive potential between two points. Simply stated, it is the force that generates current flow and to measure voltage, two points of connection are required. In AC circuits, this force, measured in volts, usually varies continuously and always reverses direction.
Page 55 PS4500, the RMS of every full cycle is measured, so these numbers are exact. In the PS4500, the present voltage is the summary of the RMS voltage over one second. It is the average of the RMS voltages of every cycle during the most recent second.
Page 56: Voltage Measurements In Powersight
Voltage Measurements in PowerSight PowerSight performs all commonly desired voltage measurements. When in phase-neutral measurement mode, the RMS (root mean square) voltage between V and the V , and input jacks is displayed by simply pressing [Volt] repeatedly. The sequence of the display as [Volt] is pressed is V >...
Page 57: Voltage Measurements In Psm
Note that if PowerSight is not monitoring consumption, the maximum, minimum, and average values are the results from the last monitoring session. Please note that when PowerSight is operating in 2 current mode, is not calculated or displayed. To set PowerSight for reading phase-neutral, phase-phase, or DC...
Page 58 But the summary value at the top is the Vpk value above the trigger, with its timestamp. If trending data is being recorded and PowerSight is operating in phase-neutral voltage measurement mode, the average V and V voltages for each second will be displayed and recorded each second.
Page 59: Current Measurements
Current Measurements Current is the flow of charged particles, usually electrons, through a point. Current is measured in units of amps (which is short for amperes) and its symbol is commonly “I”. In AC circuits, current often varies continuously and always reverses direction. In DC circuits, it is usually steady and never reverses direction.
Page 60: Current Measurements In Powersight
For the PS4500, the RMS of every full cycle is measured, so these numbers are exact. In the PS4500, the present current is the summary of the RMS current over one second. It is the average of the RMS currents of every cycle during the most recent second.
Page 61 Note that if PowerSight is not monitoring consumption, the maximum, minimum, and average values are the results from the last monitoring session. Note that when PowerSight is operating in 2 current mode, I not measured or displayed.
Page 62: Current Measurements In Psm
When measuring DC current, the RMS value is the same as the DC value. To set PowerSight for reading DC currents, refer to the section on Setting Measurement Modes. Remember that you need to have a DC current probe in order to read DC current.
Page 63: Imbalance Measurements
Ipk value above the trigger, with its timestamp. If trending data is being recorded and PowerSight is operating in phase-neutral voltage measurement mode, the average RMS current of each phase and neutral for each second will be displayed and recorded each second.
Page 64: Imbalance Measurements In Psm
actually cause damage, depending on the driven load. Therefore it is important to measure voltage and current imbalance. There are two methods of measuring imbalance. NEMA (National Electronic Manufacturers Association) uses an approach that measures the deviation of each measurement from the average. For instance, here is the formula for V imbalance: −...
Page 65: Power Measurements
The imbalance measurements appear to the left of the phasor diagram. Power Measurements There are three basic interrelated measurements of power:  True power  Apparent power  Reactive power Apparent power is defined as the sum of the products of the RMS currents and their associated RMS voltages: ×...
Page 66: Power Measurements In Powersight
Power Measurements in PowerSight PowerSight performs all commonly desired power measurements. Total true power (watts or KW), total reactive power (VAR or KVAR), and total apparent power (VA or KVA) measurements are available by simply pressing [Power] repeatedly. The sequence of the display is KW >...
Page 67: Power Measurements In Psm
The measurements of power presented on PowerSight can also be displayed in PSM by using the remote control feature. In addition our Report Generator software will present maximum,...
Page 68: Power Factor Measurements
( DPF = cos(θ) ), where θ is the phase lag of current. To do this measurement properly, PowerSight uses Fast Fourier Transform (FFT) analysis to separate the harmonic...
Page 69 using its inverse cosine to obtain the displacement power factor. This value is useful for deciding how much capacitance to add to a circuit to bring current into phase with voltage, thereby raising the displacement power factor. Displacement power factor is 1.00 for a purely resistive load or a DC system and drops down as the reactive power increases.
Page 70: True Power Factor Measurements In Powersight
True Power Factor Measurements in PowerSight The PS4500 performs all commonly desired true power factor measurements. To view true power factor, press [Power Factor]. If the display says “True P.F.”, then pressing [Power Factor] repeatedly will allow you to view the true power factors of phases 1, 2, and 3 and the total power factor of the three phases.
Page 71 ), [Power Factor] (to display PF ), [More...] (to display maximum PF ), [More...] (to display minimum PF ), and then [More...] (to display average PF In this way, by combining the [Power Factor] and [More...] keys, there are 16 true power factor measurements available. The display of true power factor gives an indication if current may be leading or lagging voltage.
Page 72: Displacement P.f. And Phase Measurements In Powersight
Displacement P.F. and Phase Measurements in PowerSight PowerSight performs all commonly desired displacement power factor measurements. The displacement power factors of phases 1, 2, and 3 can be displayed. To view displacement power factor, press [Power Factor]. If the display says “Displacement P.F.”, then pressing [Power Factor] repeatedly will allow you to view the displacement power factors of phases 1, 2, and 3.
Page 73: Power Factor And Phase Measurements In Psm
1 voltage and all other signals. The measurements of true power factor, displacement power factor, and phase lag angle presented on the PS4500 can also be displayed in PSM by using the remote control feature.
Page 74: Energy Measurements
KWH of each cycle totals to 5 KWH after 10 minutes of monitoring, then the energy consumed during the monitoring session is 5 KWH. The PS4500 calculates KWH for each second, using every cycle during that time for exact measurements.
Page 75: Energy Measurements In Powersight
10 12 hours). Energy Measurements in PowerSight PowerSight performs all commonly desired energy measurements. When monitoring consumption, the actual energy consumed is displayed by pressing [Energy]. Based on the history of consumption, estimates of energy use per hour, energy use per month, and energy use per year are calculated each second.
Page 76: Energy Measurements In Psm
The cost of energy consumed is defined as the product of the × energy consumed times the user-defined rate: $= KWH rate PowerSight presently uses a simple single rate price system. Useful measurements and estimates of cost are:  Cost of energy consumed (elapsed cost) ...
Page 77: Cost Measurements In Powersight
10 minutes of monitoring and the rate is $0.10/KWH, then the cost during the monitoring session is $0.50. The PS4500 calculates cost each second, using every cycle for exact measurements. The estimated cost per hour is the elapsed cost, divided by the hours of monitoring.
Page 78: Cost Measurements In Psm
In this way, by combining the [Cost] and [More...] keys, there are 4 cost measurements available. The rate used by PowerSight to estimate cost can be displayed or changed by the user at any time. It is one of the setup functions that can be accessed through the [Setup] key.
Page 79: Demand Period Measurements
Peak demand  Peak demand period. Demand Period Measurements in PowerSight During monitoring of energy consumption, the peak demand period is constantly updated. The logging interval is used as the demand period, so if the logging period is set to 15 minutes, the demand periods will also be 15-minute periods.
Page 80: Frequency Measurements
The average frequency is the average frequency of all the cycles during the time of interest. When operating in the variable frequency modes, the PS4500 determines the fundamental frequency of every cycle. The bands of frequencies that it can measure are from 22 to 220 Hz and from 360 to 440 Hz.
Page 81: Frequency Measurements In Powersight
[More...] (to display maximum frequency), and then [More...] (to display minimum frequency). PowerSight scans its inputs each second to look for an active power signal to measure. If none is detected, all voltage and current measurements are assumed to be zero for that second.
Page 82: Duty Cycle / Power Cycle Measurements
The measurements of frequency presented on the PS4500 can also be displayed in PSM by using the remote control feature. In addition, our Report Generator software will present maximum, minimum, and average frequency during any one or two intervals of time set by the user. If two time intervals are chosen, it will report the percent change and the actual change between the two intervals.
Page 83: Duty Cycle / Power Cycle Measurements In Powersight
2 amps as "off"). This would allow minor currents to flow in a circuit without affecting the duty cycle measurement. PowerSight comes from the factory with the "on" current set to 1 amp. If power consumption is being monitored, the number of times that current in phase 1 goes "on"...
Page 84 The present time and date is the time and date of the clock inside PowerSight used for creating timestamps for the records of the log and for dating waveform sets that are saved. It can be changed...
Page 85: Time And Capacity Measurements In Powersight
Data Setup feature of the PSM software (see Starting Data Logging section). When the clock inside PowerSight reaches that time and date, monitoring begins and the old log is erased. The programmed stop time of monitoring is a time and date that is...
Page 86: Time And Capacity Measurements In Psm
(if one exists) can be reviewed and changed. The number of records used in any of the log types can be determined by attempting to receive the log data from an attached PowerSight.
Page 87: Harmonic Measurements
The measurements of time and capacity presented on the PS4500 can also be displayed in PSM by using the remote control feature. Harmonic Measurements French mathematician Jean Baptiste Fourier determined 150 years ago that any periodic waveform can be mathematically...
Page 88 harmonic has a magnitude of 30 amps or a relative magnitude of 50%. The harmonic phase angle is the number of degrees that it leads the fundamental frequency. Comparing the difference in the phase angle between voltage and current of a given harmonic allows you to determine the “direction”...
Page 89: Harmonic Measurements In Powersight
138.3 0.75 1.69 1.18 0.58 4.20 Harmonic Measurements in PowerSight PowerSight performs all commonly desired measurements of harmonic distortion. The total harmonic distortion (THD) of any voltage or current can be calculated and displayed upon demand by simply pressing [Harmon] and then [Yes/Accept] or [No/Reject] in response to the displayed questions.
Page 90: Swells (Surges) And Inrush Measurements
The measurements of voltage presented on the PS4500 can also be displayed in PSM by using the remote control feature. In addition our Report Generator software will present average THD-F for voltage and current of each phase during any one or two intervals of time set by the user.
Page 91: High-Speed Transient Measurements
For this reason, dips are measured in RMS. For highest accuracy, PowerSight calculates the RMS of each ½ cycle of each voltage and current input in order to detect even the smallest dips.
Page 92: Measurement Modes
PowerSight asking you to make the same choices over and over. Many of the basic choices define how you wish PowerSight to interpret its inputs and how you want it to calculate and record its results. To accomplish these ends, several measurement modes can be selected by the user.
Page 93 The power factor and power reading for each phase are not necessarily accurate. This is not due to any accuracy problem with PowerSight. Instead, it is the result of each phase's current being the result of two different phase-phase voltages, whereas a phase’s power and power factor calculations rely on only one of...
Page 94: Changing The Voltage Measurement Mode In Powersight
V The voltage measurement mode that you choose will stay in effect until you change it. It will not be changed by turning PowerSight off. Changing the Voltage Measurement Mode in PSM To determine the voltage measurement mode using PSM, connect...
Page 95: 50/60/400Hz Vs Dc Vs Variable Frequency
50/60/400Hz vs DC vs Variable Frequency There are 5 frequency measurement modes in the PS4500:  Fixed 50 Hz and DC  Fixed 60 Hz and DC  Fixed 400 Hz and DC  Variable Frequency from 22 – 200 Hz ...
Page 96: Changing The Frequency Measurement Mode In Powersight
PowerSight can also measure the true RMS of DC and rectified signals that are also connected while in this measurement mode. It is generally recommended that you operate in one of the fixed frequency modes whenever you can. One reason is that there is the potential of slight errors in measuring the frequency of certain waveforms.
Page 97: Changing The Frequency Measurement Mode In Psm
Changing the Frequency Measurement Mode in PSM To determine the frequency measurement mode using PSM, connect PowerSight to PSM and then either go to the Setup Data menu and read what appears in the Input Frequency box or operate in Remote Control mode and press the key combinations described above.
Page 98: Changing The Power Measurement Mode In Powersight
PowerSight. If current and power readings of the highest accuracy are necessary, use the Checkout Connections feature that is discussed earlier in this manual or view the waveforms in order to ensure that current probes are connected correctly.
Page 99: Changing The Power Measurement Mode In Psm
The power measurement mode that you choose will stay in effect until you change it. It will not be changed by turning PowerSight off. Changing the Power Measurement Mode in PSM To determine the power measurement mode using PSM, connect...
Page 100 CT or PT. Entering the ratios of the CT and/or the PT into PowerSight allows all recorded values to be scaled appropriately. PowerSight then records primary values, although it is connected to the secondary. There are other instances where input ratios are valuable. If a...
Page 101: Changing Input Ratios In Powersight
Changing Input Ratios in PowerSight If you wish to set or change the input ratios in PowerSight, press the [Input Ratios] key once. The display will say “Set Input Ratio?” Press [Yes/Accept]. If you are setting a current input ratio, press [Yes/Accept]. If you are setting a voltage input ratio, press [No/Reject] and then [Yes/Accept].
Page 102 Click on “OK” when done. Note: Once it is entered, an input ratio is kept for the specified inputs until you change the ratio again. The default ratios for PowerSight are set to 1 : 1.
Page 103: Voltage & Current Waveforms
Whenever a set of consumption waveforms is manually recorded by PowerSight, all 3 voltages and all four 4 currents are recorded for 50 milliseconds. This time-coincident snapshot of 7 waveforms is called a "waveform set". Please Note: When operating in one of...
Page 104 The benefit of doing this is you can always retrieve a look at what the waveforms were like when monitoring began. It must be noted that the PS4500 allows the user to disable waveform sets. In this case, you will be unable to save wavesets.
Page 105: Receiving Stored Consumption Waveforms
“Data” dropdown button and then “Receive Data”. In either case, the Receive Data menu will open and all the different types of data files in the connected PowerSight will be displayed. Make sure that there is a check in the...
Page 106: Viewing Consumption Waveforms
Viewing Consumption Waveforms To select a waveform set to view, at the main menu, click on “View Consumption Data”, or click on “View” and then “View Consumption Data”, or click on “File” and then “View Consumption Data”. Any of these approaches will result in the View Consumption Data screen being shown.
Page 107 voltage, current, or voltage and current and then you make a secondary choice of which phase or phases to view, then click on “OK”. There is a wealth of features related to viewing and analyzing waveforms. Voltage and current can be viewed together and multiple phases of signals can be viewed together.
Page 108 magnitude or to percentage, click on the little box to the right of the harmonics icons. To transform back from one of the harmonic presentations into a waveform presentation, either click on the Waveform icon or click on “View” then “Waveform”. You can easily display a phasor diagram of the signals by either clicking on the phasor icon or...
Page 109 signal, so its angle is 0 degrees. If the phase 1 current lags it, it will be slightly above it. In a three phase circuit, normally the other two phases will be 120 degrees before and after phase 1 and the phase lag of each current relative to its associated voltage will be similar.
Page 110 “Invert Signal(s)”. If you save the waveform file, the change becomes permanent.
Page 111: Monitoring Power Consumption
Monitoring Power Consumption Introduction When PowerSight is first turned on, it operates like a reporter, describing what it sees. New measurements are generated each second that replace old measurements. Old measurements are discarded. These are the “present” values that are displayed as you press various keys.
Page 112: Basic Consumption Data Logging
After you direct PowerSight to stop monitoring, all the information remains available to you in the data log that is in PowerSight. The contents of the data log are not displayed on PowerSight's display.
Page 113  Frequency mode = “Variable, 22-200Hz”. This allows PowerSight to measure the frequency every second and perform measurements whenever the fundamental frequency is in that range. If you do not need to measure varying frequency, it is recommended that you change the mode to one of the fixed frequency modes.
Page 114  voltage from phase 1 to phase 2 (phase-phase mode)  voltage from phase 2 to phase 3 (phase-phase mode)  voltage from phase 3 to phase 1 (phase-phase mode)  current in phase 1  current in phase 2 ...
Page 115: Receiving Consumption Data Log From Powersight
Custom Consumption Data Logging chapter. Receiving Consumption Data Log from PowerSight To receive a consumption data log from PowerSight, the PowerSight unit must be connected to a computer running PSM. At the main menu of PSM, the green “Unit Connected”...
Page 116: Viewing Consumption Logs
PowerSight to PSM and immediately start looking at the data. Or click on the “Receive Only” button to simply receive the data log. Viewing Consumption Logs To select a consumption log to view, at the main menu, click on “View Consumption Data”, or click on...
Page 117 will be graphed. If you chose one phase to view, the maximum, minimum, and average of the phase measurement will be graphed. Of course, average, maximum, or minimum will only be displayed if that measurement type was included in the data setup.
Page 118: Custom Consumption Data Logging
Custom Consumption Data Logging Introduction PowerSight has many optional ways of operating that allow you to accomplish almost any type of power logging task you may wish to do. It does this by allowing you to make choices in the areas of: ...
Page 119: Stopping Data Logging
Once the custom setup is sent to PowerSight, that date and time will be stored in the unit, until a new date and time are written over it. This is a great way to synchronize several PowerSights to start logging at the same time, so there data logs can be synchronized.
Page 120: Setting The Consumption Logging Period
This has no effect on the measurement rate or the sampling rate. Unlike inexpensive data loggers that only take measurements when a record is created, PowerSight measures all its variables every second, regardless of the recording rate. This is very important when logging power, since loads typically vary greatly and quickly.
Page 121: Setting Measurement Types
entry. To change the logging interval number, use the numeric keypad of the meter, using [Yes] when done. Setting Measurement Types In addition to the measurement types listed in the default data log, the following measurement types can be included in each record of a custom data log: ...
Page 122: Setting Measurement Modes
When done modifying the measurement types, be sure to click “OK” and then save the new setup to file and/or send it to the connected PowerSight. Setting Measurement Modes The measurement modes and how to check and modify them...
Page 123: Saving And Retrieving Data Setups To File Or Powersight In Psm
Refer to the Measurement Modes chapter. Saving and Retrieving Data Setups to File or PowerSight in PSM When you create a customized data setup, it is usually a good idea to save the setup to a file. To do this, click on “Save to File”...
Page 124: Saving Data Setups To The Memory Card (Sd Card)
that is named the same as the serial number of the meter. For instance, a meter with serial number 12345 can detect data setups that are in the root directory (e.g. “F:/”) or the serial number directory (e.g. “F:/12345”). To detect a data setup on an SD card, press the [Setup] key.
Page 125: Restoring The Default Setup
Restoring the Default Setup The default setup can be restored to PowerSight at any time. The easiest method is to press the [Setup] key several times until the message “Restore Default Setup?” is displayed on the meter.
Page 126 Each of these recordings will be discussed at length in next few sections. The fact that the PS4500 evaluates the RMS value of every ½ cycle of every input means that no swells or dips are ever missed and the most precise measurement of their duration is available.
Page 127: Swell/Dip Event Log
PowerSight to your computer using the PSM software. The data is recorded into files in a plain text format that may be easily imported into spreadsheets, databases, and word processors. In addition, PSM has extensive graphing and printing capabilities.
Page 128: Swell/Dip Rms Graph Log
 placement of duration vs calendar timeframe. The text record allows for quickly spotting certain trends, such as the problem always being with the same signal or the problem is always a dip event. The placement of magnitude and/or duration vs calendar timeframe allows spotting times of day that events occur, and noticing if events are of similar durations, and noticing if events are of similar magnitudes.
Page 129: Swell/Dip Event Waveforms
Each record of the Swell/Dip RMS graph log is a recording of the RMS level of the signal starting 2 cycles before the trigger threshold is passed and continuing for 48 cycles or until the first ½ cycle that did not exceed the trigger threshold and was followed by 1 second of not passing the trigger threshold.
Page 130: Setting The Swell/Dip Trigger Thresholds In Powersight
Whatever is seen can be zoomed-in on and can be printed. Setting the Swell/Dip Trigger Thresholds in PowerSight Press [Setup] key twice. The display will be “Check Trigger Levels?” Press [Yes/Accept]. The present setting for voltage swell will be displayed.
Page 131 are connected to at that time. If you press [No/Reject], it allows you to use the keypad to enter an RMS value of your choice. Press [Yes/Accept] when you are done. To skip over checking the transient trigger levels, press [Yes/Accept] twice.
Page 132: Setting The Swell/Dip Trigger Thresholds In Psm
Setting the Swell/Dip Trigger Thresholds in PSM To check or set the swell/dip trigger thresholds, at the main menu click on Data Setup. At the bottom of the screen is the “Triggering for Swells, Dips, Transients” section. The upper area of this section is for setting which signals to trigger on and for deciding how many signals to capture when a trigger occurs.
Page 133: Receiving Swell/Dip Data From Powersight
When all the trigger levels are set correctly, you may save the data setup to a file or to a connected PowerSight. Receiving Swell/Dip Data from PowerSight To receive swell/dip data from PowerSight, the PowerSight unit must be connected to a computer running PSM.
Page 134 PowerSight will be displayed. Make sure that there is a check in the box before the line “Swells and Dips” in the Data Types to Receive section. Next, look in the tabular section for swell/dip files that you wish to receive.
Page 135: Viewing Swell/Dip Event Data
Viewing Swell/Dip Event Data To view previously stored swell/dip data, at the main menu of PSM, click on “View Swell/Dip Data” or click on either “File” or “View” on the top line and then “Swell/Dip Data”. The “View Swell/Dip Data” screen will now appear.
Page 136: Monitoring High-Speed Transient Events
Monitoring High-Speed Transient Events Introduction The three general areas of power quality analysis are in investigating on-going harmonic content, analyzing temporary changes in RMS voltage and current levels, and in analyzing instantaneous high-speed (non-RMS) voltage and current transients. High-speed transients are voltages or currents unrelated to the fundamental frequency of the power being used.
Page 137: Transient Event Log
PowerSight. The data is preserved even if the unit is turned on and off repeatedly. The contents of the data log are not displayed on PowerSight's display. To obtain the information, it must be uploaded from PowerSight to your computer using the PSM software.
Page 138: Transient Event Waveforms
The “timestamp” records the date and the time that the event began, to the nearest microsecond. The “signal affected” is simply the name of the signal that had was triggered, such as “V ”. The “peak value” is the highest (or lowest) instantaneous value that was reached.
Page 139: Setting The Transient Trigger Thresholds In Powersight
Whatever is seen can be zoomed-in on and can be printed. Setting the Transient Trigger Thresholds in PowerSight Press [Setup] key twice. The display will be “Check Trigger Levels?” Press [Yes/Accept]. The present setting for voltage swell will be displayed.
Page 140: Setting The Transient Trigger Thresholds In Psm
will be “Would you like a suggestion?” If you press [Yes/Accept], it will suggest a trigger 50% above what seems to be the peak current level that you are connected to at that time. If you press [No/Reject], it allows you to use the keypad to enter an instantaneous current value of your choice.
Page 141 on a box that already has a checkmark in it, erases the checkmark, indicating that the triggers do not apply t that signal. Similarly, if you wish to trigger on one or more currents, check the “Current to trigger on” section and make sure that the current signals you wish to trigger on are checked.
Page 142: Receiving Transient Data From Powersight
When all the trigger levels are set correctly, you may save the data setup to a file or to a connected PowerSight. Receiving Transient Data from PowerSight To receive transient data from...
Page 143: Viewing Transient Event Data
When the desired files have checkmarks to their left, click on the “Receive and View” button to transfer the data from PowerSight to PSM and immediately start looking at the data. Or click on the “Receive Only” button to simply receive the data.
Page 144 If the Transient Event Log has a checkmark in front of it, a list of available logs will appear at the lower right. You must click on the one that you wish to view. Each entry lists its name. To understand the various presentations of the data, refer to the Swell/Dip Event Log, Swell/Dip RMS Graph...
Page 145: Allocating Memory Within Powersight
Allocating Memory within PowerSight Allocation of memory in the PS4500 is very flexible. If one type of measurement or area of analysis is of no interest, its storage can be eliminated. If you wish to monitor for very long periods of time,...
Page 146 Data Setup Menu. Note that it is usually good practice to allow for at least 1 consumption waveset. This is because PowerSight will automatically record all signals into waveset1 when monitoring begins. It is often helpful to have a record of what the waveforms...
Page 147: Report Generator Software
Report Generator Software Introduction PSM comes with a Report Generator Software program. The Report Generator software provides concise reports to summarize and document findings. Comparison reports are excellent for presenting before/after comparisons of power usage and projected cost. Separate logs can be compared or sections of the same log can be compared for this analysis.
Page 148 data from one log to the data of another log. Or it compares one section of data of a log to another section of data in the same log. This type of report is great for preparing “before” and “after” reports to verify energy savings or to prepare longitudinal reports, documenting how performance or load has...
Page 149: Viewing A Report
The Log Details screen also has a checkbox to direct graphs to be included in the report. If this box is checked, each variable will have a graph only included. The data of the graph will only be during the time period specified in the Datalog Information screen. A word of caution here: if your computer is under-powered or has limited extended memory and you select all of the variable types and checkmark either of the graphics boxes, the report program...
Page 150 The next column is the “Change” in the value of the “After” column from the data in the “Before” column. The values of this column use the same units as the “Before” and “After” columns (such as “volts”). At the far right is the “%Change” column. This presents what percent the “before”...
Page 151: Other Functions Of Powersight
Other Functions of PowerSight Calibrating PowerSight PowerSight is calibrated at the factory and automatically adjusts itself every second during normal use. However, in order to ensure that the meter continues to meet its specifications, provision has been made for you to quickly recalibrate it yourself.
Page 152: Administrative Functions
Monitoring High-speed Transient Events. To review the log interval of the PS4500, press [Setup] four times. The present setting will be displayed. To change this setting, press [No/Reject] and then follow the instructions to enter the new log interval.
Page 153 The next number is for the use of Summit Technology personnel. The final number is the highest level of PowerSight Manager software that the unit is presently eligible to work with.
Page 154 If the PC Control/Analysis Option is available, the greeting may be quickly typed directly into the PC and then sent to PowerSight via the communications cable. When repeatedly pressing [Incre], the sequence that a character goes through is : A>B>C>...>X>Y>Z>...
Page 155 2 current mode by accident, it is normally disabled in all new PowerSight units. The user is required to enable the feature as an administrative function before the opportunity to operate in that mode is even offered in the user interface.
Page 156: Other Functions Within Psm
In addition to the many power analysis functions of PSM that have been presented in previous chapters, there are several other functions available. These are functions of convenience, functions for setting up attached PowerSight meters, and functions for setting up the PSM program. They include: ...
Page 157: Locating And Installing Software And Firmware
The software that resides in PowerSight is called “firmware” (it’s not as soft to change as “software” is, but is not as hard to change as “hardware”). The PS4500 has the ability to have its firmware upgraded via Bluetooth communications with PSM or via the SD card.
Page 158: Setting Up Administrative Features Of Powersight Via Psm
PowerSight. A very important feature is the ability to synchronize the time of the connected PowerSight to the time of the PC. This is nice for quickly and accurately setting the time, but it is also very important for synchronizing multiple PowerSight units in order to correlate logs and events from several units located at different points at a site.
Page 159: Putting It All Together (Monitoring For The First Time)
PowerSight up for logging. The other methods can be set up at another time and location and then PowerSight can be transported to the site of logging. The first step is to set up or check the parameters for logging.
Page 160 PC operating system and the meter after the meter is turned 2. Enter PSM and note that PSM has successfully connected to PowerSight. This will be clear by the box on the main menu with the words “Unit Connected” appearing within a large green banner.
Page 161 3. Turn PowerSight on. Enter PSM and note that PSM has successfully connected to PowerSight. This will be clear by the box on the main menu with the words “Unit Connected” appearing within a large green banner. Note that the box also says “Serial Comm: enabled”...
Page 162: Working With Graphs And Waveforms
Working with Graphs and Waveforms General It is important to us to allow you to work with and manipulate the various graphs and waveform presentations in PSM. We try to make the features that accomplish this look and feel the same throughout the program so you can handle all waveforms and graphs in the same way as much as possible.
Page 163 Often, the presentation of a graph can be enhanced by changing the title at the top from the filename to something more descriptive. This does not change the filename, but it may improve the look of the graph. Also, points of interest can be brought out in a presentation by adding labels to the chart.
Page 164: Reading Graphs And Waveforms
Whatever is displayed can be printed by clicking on “File” and then “Print”. It can also be saved as a Windows bitmap file by clicking on “File” and then “Save as BMP”. A very handy feature is the “Redo” icon. Whenever it is visible, clicking on it give you fresh data to look at.
Page 165 there will be a vertical name and metric on the left side and a different one on the right side of the graph. 4) The horizontal axis is usually time. Logs have time and date stamps to help determine when events occurred and how long they lasted.
Page 166: Zooming And Panning
power and power factor of the phase or phases is also shown at the right. c) For a swell/dip RMS graph or waveform, the summary is the maximum RMS value (for a swell) or minimum RMS value (for a dip), the duration of the event, and the threshold.
Page 167 waveform so that it fills the screen. It also allows you to trim off areas that you don’t want displayed (for instance, you may only want one week of a 30 day log displayed for printing). There are multiple ways to zoom in on an area of interest. The easiest is to position your cursor at the upper left corner of the area you wish to expand and then left-click-and-hold-down and “drag”...
Page 168 Specifically, the cursor is positioned on Record 224 of the log. The timestamp of that point is 6:41:00 on 9/24/04. The value of the average phase 3 power for that record is 3450 watts, whereas the average of all the average phase 3 power points that are displayed is 3511.6 watts.
Page 169: Troubleshooting & Frequently Asked Questions (Faq)
First, check that you have all the voltage and current leads connected correctly. Then if that doesn't solve your problem, check that the frequency mode of the PowerSight is in the correct mode for your situation. 5. Why doesn't my PowerSight turn on? This is most likely caused by a dead battery.
Page 170 A fully charged PS4500 will run 10-12 hours. The PS4500 displays the charge of the battery and the estimated time of charge when you press the [Setup] button. The PS4500 is fully charged in about 3-4 hours. The battery should not need replacement for at least 2 years.
Page 171 PowerSight? Unfortunately, no. Only current probes made by Summit Technology can be used with the PowerSight Products. This is because all of our probes are "self-identifying". This means the user does not have to use an input ratio to use the probes. If there is a special need to use a certain probe, let us know at support@SummitTechnology.com.
Page 172 14. Why won't my PS4500 run on an LDC (line-to-DC converter) for more than 6-8 hours? You may be using the wrong LDC. The PS4500 only works with the LDC4 model. It can supply up to 500ma. 15. How do I measure a large load carried by 2 or more parallel conductors? There are two approaches you can use.
Page 173: Advanced Motor Diagnostics Option
Predictive maintenance assistance. Maintaining a performance history for each motor allows spotting trends indicative of approaching failure. Capturing On-Line Motor Data To perform the motor diagnostics, your PowerSight must have this option loaded into it. Viewing the options display on the meter, it...
Page 174 PSM. If your PS4500 has normal memory, then data for 8 separate motors can be stored in memory. If the PS4500 has the extended memory option (MEM1), then data for 20 different motors can be stored in the meter.
Page 175: Frequency Analysis Option
The Frequency Analysis Option (order number FAO) adds the capability of a high frequency power-line spectrum analyzer to your PS4500. Normally, harmonics are measured up to about 3,000 Hz, this option starts where normal frequency analysis ends. It allows you to capture and view the small amplitude high frequency signals that ride on the normal waveforms of your voltage and current.
Page 176: Overview Of The Keypad Functions
Overview of the Keypad Functions One of the best features of PowerSight is its user interface. A surprising amount of capability is quickly available through the touch of a button. We have attempted to make the interface intuitive and flexible.
Page 177 Freq – read fundamental frequency (combine it with the More button for more information) On/Off Cycles – duty cycle, number of on/off cycles, “on” time (combine it with the More button for more information) Power Factor – true power factor and displacement power factor (combine it with the More button for more information) Demand Period –...
Page 178: Compatibility Guide
Although we attempt to make all products and accessories compatible, there are limitations to what devices and versions can work well together. The PS4500 must be used with PSM software of at least the 3.2 series. Compatibility of the PS4500 with Summit Technology accessories is as follows: Accessories...
Page 179 Accessories (cont’d) PS4500 HA-GFD LDC (discontinued) not compatible LDC2 not compatible LDC3 not compatible LDC4 SafeConnect SCAS2 (soft operating case) SCAS3 (soft accessory case) SCAS4 (soft all-in-one)
Page 180: Specifications
Specifications* Size × × 3.88” (9.86cm) Wide 7.72” (19.61cm) Long 1.58” (4.01cm) Deep in Hand-held region, 2.14” (5.44cm) deep at the top end Weight 1.1 pound (0.5 kg) Operating Range 0 - 50 degrees C (32 - 122 degrees F) Relative humidity to 70% (non-condensing) Meets mechanical shock requirements of MIL-PRF 28800F for a class 1 (harshest) environment...
Page 181 Harmonic Distortion: Range: Display of THD and individual harmonics through 25th (1800 Hz) of all signals With PowerSight Manager software, display of harmonics through 63rd (3900 Hz) Accuracy: To within 1% of fundamental Measure Rate: Measure every cycle of every input.

This manual is also suitable for:

Pk4563

PowerSight PS4500 User Manual

Quick Links

Need help?

Questions and answers

Related Manuals for PowerSight PS4500

Summary of Contents for PowerSight PS4500

This manual is also suitable for:

Table of Contents
