- Page 1 MP3 / WMA PLAYER & USB FLASH DRIVE With Speaker, FM Radio, Voice Recorder User’s Manual For Model SLD1GBSDM, SLD2GBSDM Only Release 1.0 The Product and materials mentioned in this manual are subject to change without prior notice.
- Page 2 Preface Thank you for your purchase of Pengo MP3 digital player. The functions of the player are introduced in this manual in detail. Please read it carefully before using. Caution of Operation 1． Don’t squeeze or cast the player to break the plastic case.
- Page 3 10． The MP3 player should be no driver need for windows XP/2000/ME except windows 98 (a installation disc is packed in the player box) 11． Set the HOLD switch to the release position before operation. 12． When you use this player as a USB stick, please always follow the correct operation method .Any misuse may...
-
Page 4: Product Specification
1.2 PC system requirements ◎ Windows 98/ME/2000/XP ◎ CPU, Pentium 200MHz or senior ◎ USB interface ◎ CD - ROM driver ◎ 40MB or senior hard disk space ◎32MB or senior memory 1.3 Product feature ◎ Support MP3/WMA/WAV format play ◎... - Page 5 1.5 Introduction of button functions 1.6 Display window...
- Page 6 1.7 The sketch of menu function MENU Music FM radio Voice Setting Record M library About Exit Equalizer Play Mode Contrast Text scroll speed Power Set Record set Language Display time Load default Exit...
- Page 7 Normal Rock Jazz Equalizer Classical Bass Treble DISABLE 2 mins Power Set 10 mins 30 mins Play Mode Display time Normal Repeat one Repeat All Shuffle ShuffleRepeat Preview 5 Seconds 10 seconds...
- Page 8 8000HZ Recordset 16000HZ 32000HZ 48000HZ Language English Finnish Swedish Polish Danish French Portuguese Italian Dutch German Hebrew Spanish...
- Page 9 Music library Play all Artist Album track genre year Voice record Fm record Delete exit...
-
Page 10: Operation Instruction
2.Operation instruction． Power ON/ Power off/play/pause /stop Power ON：Press the button and the player start Power off: In the stop / play / pause state, press and hold the button will Power off the player. Play: In the stop/pause state, press the button begin playing pause：In the play state，press the button... - Page 11 the last track. Skip Backwards: Press and hold the button , time of track will skip backwards fast. Go to above options ：In the menu option, press the button and go to the above menu. Next track/ skip forward / go to next Next track: In the stop/pause/play state, press the button the current track go to the next track.
- Page 12 Repeat: In the play state, press the button Mode and player the repeat to be the beginning. A is displayed on the screen; press the button Mode to set it as ending. A-B is displayed on the screen. The player will repeat between the beginning point and the ending point.
- Page 13 In the" music " main menu，first press " MODE " button to enter the play mode ◎ FM radio Select the main menu “FM radio” and press “MODE” button to enter FM radio . You can select the saved channels via button.
- Page 14 from FM radio, the screen will display the file name to be recorded (Fxxx.WAV). press PLAY key to pause recording, long press MODE to stop recording. Save station: select “save station” menu, press " MODE " button to enter save station and prompt：" Save? "，press “MODE”...
- Page 15 ◎ voice Select “voice” main menu, press “MODE” button and enter voice mode. The window displays the previous saved voice file. Press button and select the saved voice file. Press “ ” you can play voice file. ◎ Setting elect “setting” main menu, press “MODE” button and enter setting mode.
- Page 16 Rock, Jazz, classical, pop, Bass, Treble”. Press button then you can choose relative mode and press “MODE” button to confirm. Play mode: select “play mode” menu, press “MODE” button and enter play mode, There are five playing mode in the play mode menu, namely “Normal, Repeat track, Repeat all, shuffle and shuffle repeat”...
- Page 17 ON”. Press Power set: select “power settings” menu , press MODE button enter, There are four modes optional in the power set menu, namely “2 mins, 10 mins ,30 mins and disable ”, press button and select relative settings. Record set: select “record setting” menu, Press “MODE” button to enter, There are three recording modes in the record set menu, namely “8000Hz, 16000Hz, 32000Hz , 48000Hz”, press...
-
Page 18: Music Library
text scroll speed” Text scroll speed: Select menu " press " MODE " button, Press the button to select Display speed setting which includes the following options: normal(0), fastest(2), slowest(-2), faster(1), slower(-1). Press the MODE button to save. Load default set: Select “Load default set” menu, and press “MODE”... - Page 19 MODE button to return to forward menu. Play all: Under the Music Library mode, press the button to select play all function. Press the MODE button to select and then the player begin playing all the songs saved in Artist: Under the Music Library mode, press the button to select artist function.
- Page 20 automatically. Track: Under the Music Library mode, press the button to select track function. All the songs will be sorted according to the track. You can select certain track which you love, or select the play all then press the MODE button to confirm.
- Page 21 which you love, or select the play all then press the MODE button to confirm. Then the system will play automatically. Voice record: Under the Music Library mode, press the button to select Voice record function. All the voice files are saved in this folder.
-
Page 22: Usb Flash Drive
Delete: Under the Music Library mode, press the button to enter into the Track function and select the music , then press “ - ” button to delete this music. ◎ about Select “about” menu and press “MODE” button to enter the window displays: Total：1GB（memory gross capacity）... - Page 23 2)The sudden power failure while the data-transmitting between the MP3 player and the PC has not completed 3)The sudden power failure while the MP3 player is working or violated by virus. These will damage the software of Mp3 player and cause the following problems. 1. Cannot turn on the player 2.
- Page 24 3) Remove the battery in the MP3 player. Press and hold play key of the player, then connect it to the computer, till the computer display the picture of firmware download.
- Page 25 favorite song again. step: 1: Insert the cdrom to the computer Second: Run the programs in the cdrom 2: Run setupdaterapp.exe 3:The computer scans the device automatically 4: Take out the battery from the player, then...
- Page 26 connect the player to the computer and long press the play button without released, until the computer display the download picture...
- Page 27 5:Select the “format DataArea” option, and click the start button , the program will update automatically, then exit after finish. The player can be used normally after you copy the songs again.
- Page 28 Support: For tech support or RMA request, please write your email to support@pengo.com or call 1-888-PENGO99 www.pengo.com...
