- Page 1 SKU: RLXM20RPK Revision 2022.1.0 RLX-M20R Red Beam Rotary Laser Level Package I NS TRU CT ION MANUAL...
-
Page 2: Table Of Contents
CONTENTS SAFETY ITEM CHECKLIST LASER LEVEL OVERVIEW USING THE LASER LEVEL USING THE MOUNT USING THE TRIPOD USING THE DETECTOR CARE AND MAINTENANCE WARRANTY TROUBLE SHOOTING CUSTOMER SUPPORT EU DIRECTIVES AND DISPOSAL SPECIFICATIONS... -
Page 3: Safety
SAFETY Read the following safety instructions before attempting to • Do not set up the tool at a position where the laser beam operate this tool. can cross any person at head height. Keep these instructions in a safe place or store in the carry •... -
Page 4: Laser Level Overview
LASER LEVEL OVERVIEW Rotating laser port Speed control indicator Protective lighthouse Tilt (disturbance) alarm button Control panel Tilt (disturbance) alarm indicator Rechargeable battery charging port Screw fixing point Power button Battery door Power indicator 5/8” -11 thread for horizontal operation on a tripod Speed control button... -
Page 5: Using The Laser Level
USING THE LASER LEVEL POWER SUPPLY • The laser level is supplied with 2x lithium-ion batteries as its power source. The batteries are supplied inside the laser level by default. • The batteries are supplied only partially charged. Charge the batteries before use. •... -
Page 6: Using The Mount
USING THE TRIPOD USING THE LASER LEVEL (continued) • Extend the tripod legs to the required height and ensure the legs are spread wide enough so that the tripod Speed control platform is stable. Secure the legs in place. • Press the speed control button to cycle through the •... -
Page 7: Using The Detector
USING THE DETECTOR • In bright outdoor conditions, visible distance will be significantly reduced. For outdoor use, it is recommended to use the included detector. DETECTOR OVERVIEW Laser sensor Detection mode: fine LCD display screen Detection mode: course Power on / off Battery level indicator Detection mode Speaker indicator... - Page 8 USING THE DETECTOR (continued) OPERATION Powering on / off • Switch the detector on by pressing the power button . The LCD screen will turn on and the speaker will emit a small tone to indicate the instrument is operating. •...
-
Page 9: Care And Maintenance
8. Smudges and fingerprints may be removed with a damp tissue or a soft, lint-free cloth. WARRANTY All Goblin Tools measurement tools are carefully checked 4 YEAR STANDARD WARRANTY PERIOD and tested to our precise quality assurance standards. 1. The warranty period for your tool is 4 years from the date We offer a warranty in accordance with the following of purchase. -
Page 10: Trouble Shooting
TROUBLE SHOOTING Error Cause & Solution • The battery pack may require charging or need to be replaced due to age and / or a high number of charging cycles. Laser level does not turn on • Check the battery compartment for signs of damage and ensure that the compartment is clean and that the battery terminals are not bent. -
Page 11: Specifications
SPECIFICATIONS Specifications RLX-MR20 Product code RLXMR20PK Warranty 8 Years* ±2mm at 30m Accuracy (±1/10in / 0.06in at 98ft) Operating range (diameter) 400m (1312ft) with detector Levelling range ±8% / ±5° Laser class 2 Red Battery life 40 hours+ 7.4V 4000mAh Battery type Li-ion battery pack Vertical lines... - Page 12 © 2023 Spot-on Global Group Ltd. Goblin Tools is a trademark of Spot-on Global Group Ltd and is used under license by Spot-on Laser & Tool Company UK Ltd. All Rights Reserved.
