USE AND MAINTENANCE MANUAL MANUAL FINGER CUTTING MLT-F120...
Page 2
Index: EC Declaration of conformity:....................................2 What is the manual finger cutting MLT-F120 ?..............................3 Operating instructions :......................................4 Spare parts:..........................................11 IMPORTANT Read this user manual and follow the instructions and warnings before operating this device. Any modification or transformation performed on this machine may cause the loss of the manufacturer’s guarantee and liability.
«CE» DECLERATION OF CONFORMITY We, the undersigned, MLT ZI du Clos Marquet - Rue Michel Rondet - CS 70059 - 42 200 Saint-Chamond, France The person(s) empowered to carry out the technical documentation : - Gilles FURNON : product manager, MLT...
What is the manual finguer cutting MLT-F120? Description Portable die cutter to cut conveyor belts in a zigzag pattern, featuring exchangeable cutting heads for different cutting geometries. Support bench with material positioning guides. This die cutter is especially designed to operate onsite for cut thermoplastic materials with interior tissue.
Operating Instructions WARNING THIS DEVICE INVOLVES THE HAZARD OF HANDS AND ARMS BEING TRAPPED BY THE MOVEMENT OF THE CUTTING HEAD GREAT CARE MUST ALSO BE TAKEN BETWEEN THE CUTTING HEAD AND THE SUPPORT PLATE, AS THERE IS A DANGER OF CUTTING LIMBS. Portable head assembly Ensure the cutting handle is positioned completely vertical to keep the down pin inside the body.
Page 6
Operating instructions First, place the first end of the belt on the GREEN side by the guide rail with the coverage on top, and position the tread bar to the end of the plastic plate. Fix the belt by lowering the bar with two knobs and tightening at the same time.
Page 7
Avoid over-tightening to prevent bending of the clamp in the central part. Once the belt is in position and complete fixed, push the down camp to liberate the step pin and move the head until end of stroke of GREEN side. Then we can start to punch acting with handle in all the stork up and down.
Page 8
When the first head of the belt is completely punched, open the clamp and introduce the second head in the YELLOW side, with coverage on top also. When handle is completely up, push the head to YELLOW side until the belt down the blades. Once the head is in position to cut the second head of the belt, start to punch until end of stroke in YELLOW side.
Page 9
Changing the die head : WARNING WHEN CHANGING THE DIE, IT IS RECOMMENDED TO TURN OFF THE EQUIPMENT WITH THE OFF SWITCH FOR GREATER SAFETY. Remove the punching head for replacing the knives plate. Remove the 2 bolts using a 10mm key. Remove the die and install the new one.
Page 10
Adjust the pressure stroke. NOTE You must adjust the cutting pressure every time that nylon plate is replaced. Otherwise, excess pressure may cause breakage of the blades, or deterioration of the cutting nylon. Loosen the 4 screws key 17mm M-10 M-10 Up or down the back side of head across the screw pressure like a next picture.
Spare parts Number Part name Units F06001 45x90x1850 E2101 Inclined handle F06002 Clamping bar F12003 Belt clamp F06004 Rail Franke F12005 Side frame F06006 miniter_20_1033_0_ F061010 Ramp F12007 Ramp tongue F12008 Belt clamp tongue F06009 Poliamide F12010 Nylon support F12011 Tongue plug F12012 vc_192_50_b_m10.par...
Page 13
Number Part name Units E2101 Inclined handle F12026 Base of the device F12027 Cutting base F12028 Spacer upper punch F12029 Spacer inferior pointer F12030 Device side-1.par F12031 Device side-2.par F12032 Pressure regulator SB152015 Rolling bearing 15-20-15 SB202615 Rolling bearing 20-26-15...
Page 14
Number Part name Units F12013 Trigger guide bar F12014 Base of the runner F12015 Trigger hinge F12012 Bushing_kh_0824_0.par F12016 Trigger switch F12017 Trigger F12010 i_280_40_p_m6x1.par F12018 Spring F12019 Trigger guide ramp 2 F12020 Trigger guide ramp F12021 Hiwin trolley/skid 15 F12022 Pin/Bolt F12022...
Page 15
Number Part name Units F12035 Fixing pin F12036 Hinge F12037 Pin 10x35 F12038 Pin 12x70 F12042 din_464_m5_20 F12039 Excentrique F12040 i_280_90_m12 F12041 Lever...
Page 16
Number Part name Units Kn77102 Blade 0.7x82xdable bis normal 70200 Spacer punch F12023 Anti-rotation shaft F12024 Pressure axis F12022 Punch screw F128010 Punch F12025...
Page 17
HOTLINE MLT service Our MLT representatives will assist you remotely and in pictures HOTLINE MLT Our teams are available to answer your questions in 10 service is at your disposal to assist you live in the resolution of any problems you may...
Page 18
DIE CUTTER MLT-F120 PAT E N T E D P R O D U C T MADE IN FRANCE MLT Minet Lacing Technology More than 70 years of innovation at your disposal TECHNICGUM Distributor’s logo www.mltgroup-conveyor.com - info@mltgroup-conveyor.com...
