METRO SHUFFLEBOARD™ ASSEMBLY INSTRUCTIONS


1. Remove the table and other contents carefully from the box in order to avoid scratching the surface of the table (Grips on
both  ends  can  be  a  help).    As  shown  below,  place  the  table  upside  down  on  floor  (covered  with  carpet,  cardboard  or
padding in order to protect the cradle from scratching).



2. Loosen each leg leveler then pivot the legs straight up from the table, as shown.
Grips on both ends
3. Remove the Allen wrench and the 8 Allen bolts from the parts bag.
4. Place the Allen bolts into the holes on the brackets in front and behind the legs.    Each leg is fastened with 2 bolts.    Use
the Allen wrench to tighten the bolts.
  1 / 2
Mega Mania Diversions LLC Tel: 1-888-322-9076
www.megamaniadiversions.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the METRO SHUFFLEBOARD and is the answer not in the manual?

Questions and answers

Summary of Contents for Snap-Back Shuffleboard METRO SHUFFLEBOARD

  • Page 1   METRO SHUFFLEBOARD™ ASSEMBLY INSTRUCTIONS                  1. Remove the table and other contents carefully from the box in order to avoid scratching the surface of the table (Grips on  both  ends  can  be  a  help).    As  shown  below,  place  the  table  upside  down  on  floor  (covered  with  carpet,  cardboard  or  padding in order to protect the cradle from scratching).                   ...
  • Page 2   5. Turn the table right‐side up on the floor.    Note that there are small red tape on each side of the cradle near the front of  the table.    These tapes mark the position of the abacus scoring system, and are to be used as guides in their installation.    Be sure the top of the cradle is clean of dust and dirt in the area before the red tapes. Red tape  6. Next, prepare to install the abacus scoring system.    The red abacus will be installed on the left side of the table, before  the red locating tape, and the blue abacus will be installed on the right side of the table, before the red locating tape.    To  install  the  abacus  scoring  system,  remove  the  black  liners  off  the  adhesive  strips  on  the  underside  of  the  abacus.    Then  place each abacus on top of the cradle before the red tape, make sure it is aligned evenly with the sides of the cradle, and  press down against the cradle for 10 seconds.    Remove the red tapes after the abacus is installed.  7. ...
  • Page 3   How to Play the Game The object of the game is to reach the Game Goal before your opponent. HOW TO START: - A coin toss decides who starts the game. The winner of the coin toss also decides if the game will start from the left or the right.
  • Page 4   - When a weight comes to rest on a scoring (Black) line, that weight scores the smaller number. The weight must clear the first line completely to score. - If a weight comes to rest before entering the scoring surface area, it must be removed from the playing surface before the opponent plays the next weight.
