Summary of Contents for Bass Habit ELITE E28DSP

Page 1 E28DSP Elite Digital Signal Processor User Manual...
Page 3 THANK YOU! Thank you for purchasing this SPL Elite DSP from Bass Habit. Please read this manual in order to fully understand how to get the best result from this product and ensure that the advice on how to look after the product and the safety precautions are followed.
Page 4: Table Of Contents
TABLE OF CONTENT • SAFETY & WARRANTY • TOOLS Caution Tone generator Warranty Frequency sweep What is not covered Pink sweep Warning • SPECIFICATIONS International technical enquiries • INSTRUCTIONS • TROUBLESHOOTING Installation experience Choosing DSP mounting locations Installation precautions Power connections •...
Page 5: Safety & Warranty
Ensure that no moving parts get caught on the subwoofer or grill. WARRANTY All Bass Habit products carry a full warranty depending on the conditions in the country where it is sold. The warranty is valid from the date of the original receipt as proof of purchase (warranty period differs depending on local warranty laws and policies).
Page 6: Instructions
• When making connections, make certain all cables are secure and properly insulated. POWER CONNECTIONS To get the very best performance out of your Bass Habit Elite DSP, carefully follow the instructions below: GROUND CONNECTION (GND): Connect the DSP Ground (GND) terminal to a solid point on the vehicle’s metal chassis, as close to the DPS as possible.
Page 7: Overview
CONTROL PANEL OVERVIEW Three diﬀerent (with delay) remote out for ampliﬁers. Remote out Use 1.5mm² cable. Remote in (REM IN) Automatic start from source. Negative ground (GND) Connect to the vehicle chassis. Minimum 2.5mm² cable. Connect to positive pole of battery (+12V). Minimum 2.5mm² cable. Positive battery (+BAT) Display LCD display.
Page 8: Connect Bluetooth
NAVIGATION AND CONTROL Navigation and control of the Bass Habit E28DSP are made via the “MAIN CONTROL” knob and the “OUTPUT SELECTS” hotkeys. MAIN CONTROL OUTPUT SELECTS Rotation: NAVIGATION/INCREASE/DECREASE Quick press: SELECT CHANNEL Quick Press: ENTER/SELECT Hold: OUTPUT ON / OFF...
Page 9: Audio Processing
Q factor, the smaller the Q the greater the width of that equali- zation band, affecting to a greater extent the neighboring frequencies. Bass Habit E28DSP has 8 parametric equalizers for the outputs (1 for each output) PARAMETRIC EQ freq.: 214 Hz...
Page 10: Audio Out- Routing
AUDIO OUT- Routing The purpose of the routing option allows you select the audio source A, B ROUTING or A + B (sum) for each output. Turning the “MAIN CONTROL” dial moves IN A+B ---> OUT1 the audio source to the selected route. To select another channel, quickly press the corresponding “OUTPUT SELECT”.
Page 11: Audio Out- Delay
AUDIO OUT- Delay The Delay function allows for the digital alignment of transducers speakers DELAY via the time correction performed by the DSP, and ensures that the sound 12.0cm 0.349ms from all the speakers arrives at the listener with improved audio fidelity while avoiding frequency cancellations.
Page 12: Audio Out- Gain
This menu allows you to adjust the gains of the individual outputs within a MASTER LVL: range of -45 to +15 dB, as well as to increase the volume of the Bass Habit OUT1 GAIN: +3 dB E28DSP from 0 to 100%.
Page 13 X-OVER Presets The crossover presets you can choose from is the following: SWBW1 SWBW2 SWBW3 50Hz BT12 10Hz 30Hz BT12 150Hz LR24 80Hz LR24 90Hz LR24 WOOFER1 WOOFER2 WOOFER3 100Hz LR24 60Hz BT12 45Hz BT12 LPF 1000Hz LR24 LPF 1000Hz LR24 800Hz LR24 DRIVER1...
Page 14: Copy Channel
Time: 2.0 s SEQUENCER SEQUENCER ON/OFF S1: ON SCREENSAVER The Bass Habit E28DSP has a screensaver function, which allows the user SCREENSAVER to define a 15-character scrolling text. E28DSP LANGUAGE You can select from the following operating languages: English, Spanish and Portuguese.
Page 15 TOOLS The Bass Habit E28DSP has tools to aid in the regulation of your sound system, TONE GENERATOR, FREQUENCY SWEEP and PINK NOISE GENERATOR. These tools are signal sources for all outputs, that is, during their use as inputs. Make sure to always start with gain: -60 dB due to a high output signal! TONE GENERATOR A tone Generator is used to generate a specific frequency with gain control.
Page 16 SPECIFICATIONS 2, BT Number of Input Channels: Number of Output Channels: 15 Bands, gain ± 12dB Graphic Equalizer: Graphic Equalization Presets: 1 Input + 1 per Output, Gain ± 12dB, Q Factor 0.4 to 10.0 Parametric Equalizer: Butterworth 12/18/24/36/48 dB / Oct Crossover with Variable Frequency: Linkwitz-Riley 12/18/24/36/48 dB / Oct Crossover Presets:...
Page 17 TROUBLESHOOTING Symptom Check / Control No sound • Check and measure voltage at +12V and REM IN / No active unit (Allowed working range is 10.0-16V DC). • Check ground connections. • Check the external fuse. • Check input signal and cables from the source unit. •...
Page 18 The crossed-out wheelie bin symbol means that the product, literature and packaging included must be taken to a separate collection at the end of their working life. Do not dispose of these products as unsorted municipal waste: dispose of them at a recycling point. For info on your nearest recycling point, check with your local waste authority.
