安装说明书
K-98454T-NW-CP
K-98454T-NW-BN
K-98454T-NW-BL
K-98454T-NW-AF
K-98454T-NW-2MB
K-28577T-NW-CP
K-28577T-NW-BN
K-28577T-NW-BL
K-28577T-NW-AF
K-28577T-NW-2MB
K-28577T-NWS3-CP
1495654-T2-A
萝瑞台盆感应龙头-单冷，1.9L
LOURE DM SENSOR FCT COLD 0.5GPM
萝瑞台盆感应龙头-单冷，1.9L,罗曼银
LOURE DM SENSOR FCT COLD 0.5GPM - BN
萝瑞台盆感应龙头-单冷，1.9L,原色黑
LOURE DM SENSOR FCT COLD 0.5GPM - BL
萝瑞台盆感应龙头-单冷，1.9L,法兰金
LOURE DM SENSOR FCT COLD 0.5GPM - AF
萝瑞台盆感应龙头-单冷，1.9L,摩登金
LOURE DM SENSOR FCT COLD 0.5GPM - 2M
萝瑞碗盆感应龙头-单冷，1.9L
LOURE TH SENSOR FCT COLD 0.5GPM
萝瑞碗盆感应龙头-单冷，1.9L，罗曼银
LOURE TH SENSOR FCT COLD 0.5GPM - BN
萝瑞碗盆感应龙头-单冷，1.9L，原色黑
LOURE TH SENSOR FCT COLD 0.5GPM - BL
萝瑞碗盆感应龙头-单冷，1.9L，法兰金
LOURE TH SENSOR FCT COLD 0.5GPM - AF
萝瑞碗盆感应龙头-单冷，1.9L，摩登金
LOURE TH SENSOR FCT COLD 0.5GPM - 2MB
萝瑞碗盆感应龙头-单冷，1.4L
LOURE TH SENSOR FCT COLD 0.35GPM
科勒（中国）投资有限公司
中国上海市静安区江场三路158号 邮编：200436
制造商：上海科勒电子科技有限公司
中国上海市宝山区丰翔路1955号 邮编：200444
Desk-mount Sensor Faucet
萝瑞
LOURE
1
Advertisement
Table of Contents
Related Manuals for Kohler LOURE K-98454T-NW-CP
Summary of Contents for Kohler LOURE K-98454T-NW-CP
- Page 1 萝瑞 LOURE 安装说明书 Desk-mount Sensor Faucet K-98454T-NW-CP 萝瑞台盆感应龙头-单冷，1.9L LOURE DM SENSOR FCT COLD 0.5GPM K-98454T-NW-BN 萝瑞台盆感应龙头-单冷，1.9L,罗曼银 LOURE DM SENSOR FCT COLD 0.5GPM - BN K-98454T-NW-BL 萝瑞台盆感应龙头-单冷，1.9L,原色黑 LOURE DM SENSOR FCT COLD 0.5GPM - BL K-98454T-NW-AF 萝瑞台盆感应龙头-单冷，1.9L,法兰金 LOURE DM SENSOR FCT COLD 0.5GPM - AF K-98454T-NW-2MB 萝瑞台盆感应龙头-单冷，1.9L,摩登金...
-
Page 2: Before You Begin
BEFORE YOU BEGIN 安装之前 All information is based on the latest product information available at the time of publication. Kohler Co. reserves the right to make changes in product characteristics, packaging, or availability at any time without notice. Please leave these instructions for the consumer. -
Page 3: Rough-In Dimensions
ROUGH-IN DIMENSIONS 安装尺寸 98454T 98454T 萝瑞 萝瑞 204.5 204.5 136.5 136.5 台盆顶面 台盆顶面 G1/2 Please prepare external thread angle valve G1/2 开关 G1/2 Switch Please prepare external thread angle valve G1/2 220V交流电Connect AC 220V 穿线管 Wire Tube 28577T 28577T 萝瑞碗盆感应龙头（交流） 萝瑞碗盆感应龙头（直流）... -
Page 4: Installation
PARAMETERS (LR06×4) Power: DC 4 pieces of AA size alkaline batteries AC 220V, 50/60Hz 220V 50/60Hz Senser Duration: Less than 0.75s 0.75 Shut-off Delay: 0.5~1s 0.5～1 Sensing Distance: Automatic adjustment Flow Rate: No more than 0.0315L/s at 0.1MPa. 0.1MPa 0.0315L/s Overtime Flowing Control: Automatically stop flushing when the faucet senses an object for more than 1 minute continuously... - Page 5 Connect check valve (14) to outlet, then connect the hose (15) to check valve (14). Put a bucket in the front of hose (15). Keep check valve (14) fully open, turn on the water supply for about 1 min, make sure no leakage on pipeline, and then turn off the water supply.
- Page 6 1.建议交流电源线采用带绝缘和护套层的电线，导 1.Suggested wire: AC connection wire should with insulated protecting layer or sleeve and the section should be bigger 体标称截面积 0.5mm ；直流连接线采用导体标 than 0.5mm . The section of DC connection wire should be 称截面积 0.3mm 的电线。请严格按照上图进行 bigger than 0.3mm . The connection pattern must according 连接。...
- Page 7 2.Cabing and tidying wires such as 2.如图所示,将电源线,龙头感应器线 power wire assembly,senor wires 及电磁阀线与相应的接线端相连 assembly and solenoid wire assembly 接。然后整理好线束并锁紧控制盒 to right position. Then lock the control box. 盖。 电磁阀接线端 Solenoid wire connector 电源线接线端 龙头感应线接线端 Power wire connector Sensor wire connector Note: ① is the outlet of AC power supply. 注：①为交流电源出线口，使用时，...
- Page 8 外螺纹 三通软管组件 Note: Please let users prepare the hose and tee by themselves. 注：软管、三通请用户自备。 It is recommended to use Kohler TEE inlet hose assembly, 建议使用科勒推荐的三通进水软管 otherwise there is a risk of cold and hot water mixing problem. 组件，否则有冷热水互窜的风险。 HOW TO CHANGE TO THERMOSTATIC 如何转换成恒温阀感应龙头...
-
Page 9: Installation Checkout
Many cleaners may contain chemicals, such as 许多清洁剂，比如氨水，去污粉及洁厕灵等，会 ammonia, chlorine, toilet cleaner etc. which could adversely 对电镀表面造成伤害，切忌使用。 affect the finish and are not recommended for cleaning. 有腐蚀性的清洁剂或溶剂不可使用于科勒的水龙 Do not use abrasive cleaners or solvents on Kohler faucets 头及其配件上。 and fittings. IMPORTANT CONSUMER INFORMATION 用户须知 1. 感应指示灯的各种闪烁情况... - Page 10 3. 清洗过滤系统 3. Clean the Filtration System The faucet includes connector assembly with high quality 该感应龙头的阀体组件内已包含了优良的过滤装 filtration system. If there is a lot of debris in the supply pipes 置。如管内杂质过多或水质较差，长期使用会引 or the quality of water is bad, it will cause the flow in bad 起出水情况不良。请按以下步骤清洗过滤装置：...
- Page 11 常见故障排除 以下部分故障现象可通过指示灯闪烁情况识别。（参考“感应指示灯的各种闪烁情况”） 现 象 因 处理方法 原 检查电池 无电池或电池装反(直流电) 检查总电源和接线情况 无电源或接线有误(交流电) 不出水 移开物体 感应范围内有其它物体 （感应指示灯不闪烁） 清洁窗口 感应窗口较脏 检查接线端 接线端未插好、插错 电池耗尽(直流电) 更换电池 感应指示灯每2秒快速 刚刚停电 ( 交流电 ) 检查总电源 闪烁1次而不出水 直流或交流接线端接触不良 重新连接接插件 等待 30秒 刚装机完毕 感应指示灯闪烁 阀体组件关闭 打开阀体组件 不出水 起泡器脏堵 清洗起泡器 过滤装置堵塞 清洗过滤装置...
-
Page 12: Troubleshooting
The connection of inlet hose may not smooth. Cut the inlet hose flat and smooth(about 1cm) hose and valve. Please contact with distributor or Kohler China Investment Co., Ltd., if the trouble remains after above-mentioned actions aretaken. Please do not disassembly the other parts of the faucet freely except installing and replacing batteries. - Page 13 产品中有害物质含量的说明 回收提示 本产品超过使用期限或经过维修无法正常使用后，不应随意丢弃，请交由有废弃电器电子产品处理资质的 企业处理，正确的处理方法请查阅国家或当地有关废旧电器电子产品处理的规定。 有害物质统计表 有害物质名称 部件名称 六价铬 多溴二苯醚 多溴联苯 铅(Pb） 汞（Hg） 镉（Cd） (Cr(VI)） （PBDE） （PBB） × ○ ○ ○ ○ ○ 外壳组件 ○ ○ ○ ○ 阀体组件 ○ × ○ ○ ○ ○ ○ 控制盒组件 × ○ ○ ○ ○...
- Page 14 * :Indicate only partial product series contains this substance. Note: the information provided is based on the supplier data and Kohler inspection results. The product is designed not to hurt the environment. Under current technology, all hazardous materials have been used in the smallest amounts possible. Kohler will strive to reduce the use of these hazardous materials used in this product.
