Mitox 26MT-SP Assembly

26MT-SP Multi-Tool
Assembly of the Hedgetrimmer
1. Remove the locating screw (1).
2. Using a T25 Torx Key, loosen the clamping bolt (2).
3. Slide the drive shaft (3) into the hedgetrimmer gearbox (4) until the locating hole (5) in
the drive shaft is visible though the locating hole (6) in the gearbox.
4. Insert the locating screw (1) into the gear box (6) and tighten.
5. Using a T25 Torx Key, tighten the clamping bolt (2).
The thickness of fresh growth (green branches), which may be cut using this
hedgetrimmer, is limited to up to approximately 10mm. Never try to cut branches
thicker than this, as doing so may result in damage to the hedgetrimmer.
Blade information
• Never cut hedges thicker than 10mm and only fresh growth.
• If wire is caught by the blades, damage can occur which is not covered by the warranty.
• When sharpening, removing, or reattaching the blades, be sure to wear thick, sturdy gloves
and use only appropriate tools and equipment to prevent injury.
• After you have finished using the hedgetrimmer, clean the blades and apply clean light grade
lubricating oil to the entire length of the blades, including the blade bolts.
Original Instructions Version December 15
