DeviaLIM
User
Guide
Author
Christophe Denis
Revision history
DeviaLIM
User Guide
Fax: +33 (0)4 72 37 72 76
Description
Initial issue
Creation : 17/01/2012
Update : 26/08/2014
Author : Christophe Denis
Open document
Page
1
of 13
Status: Complete
Advertisement
Table of Contents
Summary of Contents for LIM DeviaLIM
- Page 1 LIM SAS 86 rue de la Poudrette F-69100 Villeurbanne Tel: +33 (0)4 72 14 68 30 Fax: +33 (0)4 72 37 72 76 http://www.lim.eu DeviaLIM User Guide Affected Date Author Description pages 17/01/2012 toutes Christophe Denis Initial issue Revision history...
-
Page 2: Table Of Contents
5.2 View Menu....................8 5.3 Info Menu.....................8 6. Main Menu..................9 7. File explorer menu................10 8. Configuration...................11 9. Connection to a PC via the USB............12 10. Angles conventions..............13 DeviaLIM Creation : 17/01/2012 Page Update : 26/08/2014 of 13 User Guide Author : Christophe Denis... - Page 3 Figure 15 : Explorer Menu....................10 Figure 16 : Setup Menu.....................11 Figure 17 : Screen displayed when device is connected to a PC via a USB....12 Figure 18 : Inclination......................13 Figure 19 : Azimuth......................13 DeviaLIM Creation : 17/01/2012 Page Update : 26/08/2014 of 13...
-
Page 4: General Presentation
GENERAL PRESENTATION The DeviaLIM consists of an HMI casing (1) and a probe connected together by an electro- mechanical cable. A. Socket for the probe sensor, USB cable, and area B. Front face of the device in anodized aluminium C. Screen LCD D. -
Page 5: Performance Of The Product
After a few seconds, the display automatically returns to the Acquisition menu. • Turning the device off To turn off the DeviaLIM, press on the On/Off button until the device turns off. • To save battery life, the DeviaLIM automatically turns off after 5 minutes of no activity. -
Page 6: Recording Drilling Deviations
Figure 3 : Acquisition menu, stand-by mode Preparing to Record Go to Acquisition menu. This is now on stand-by mode (3); this means that the DeviaLIM • is not recording any measurement. Check the acquisition parameters displayed at the top left side of the screen (direction •... -
Page 7: Measuring
10. If this is the case, check the connections and the battery. When battery life is lower than 5%, it is no longer possible to start a new recording. • Recharge the battery. DeviaLIM Creation : 17/01/2012 Page Update : 26/08/2014... -
Page 8: Results Of The Recording
Average measured azimuth of the drilling AZI avg.: 58.4°N Theoretical azimuth of the drilling (set point) AZI theo.: 76.0° The Close button takes you back to the File Explorer menu (15). • DeviaLIM Creation : 17/01/2012 Page Update : 26/08/2014 of 13 User Guide... -
Page 9: Main Menu
Acquisition, Explorer and Setup menus. The main menu provides access to the following menus: Acquisition (Acquisition) • File Explorer (Explorer) • Configuration (Setup) • DeviaLIM Creation : 17/01/2012 Page Update : 26/08/2014 of 13 User Guide Author : Christophe Denis Open document Status: Complete 6. -
Page 10: File Explorer Menu
The file explorer (15) allows you to view the contents of the memory card. • Select an item by pressing on the up/down buttons, and open the file you selected by • pressing on Open (button 2). DeviaLIM Creation : 17/01/2012 Page 10 Update : 26/08/2014 of 13... -
Page 11: Configuration
The time delay for the screen's start-stop (also called stand-by) is indicated in seconds. It • allows you to configure the time of inactivity starting from the time the DeviaLIM is put on standby. During this period, the casing is on (visible on the On/Off button which is lit); only the screen and the probe are turned off to save battery life. -
Page 12: Connection To A Pc Via The Usb
CONNECTION TO A PC VIA THE USB Figure 17 : Screen displayed when device is connected to a PC via a USB When the DeviaLIM is connected to a PC via its USB cable, the screen, as shown in 17, •... -
Page 13: Angles Conventions
ANGLES CONVENTIONS The DeviaLIM's angle conventions are defined as follows: Inclination expressed from 0.0° to 180.0° (18): • 0°: vertical probe, pointing downward 90°: horizontal probe 180°: vertical probe, pointing upward Azimuth expressed from 0.0°N to 359.9°N (19) •...
