Input Voltage
Output Voltage
Output Power
Enclosure Material
Operating Temperature
Time Delay
Enclosure Dimension
Backup Battery Type
5 Input Wiring Diagram
6 Output Wiring Diagram
100-240VAC
12VDC
36W
Aluminum alloy
-4 to +140℉ [-20 to +60°C]
0-15s
4-29/64" x 3-5/64" x 1-17/64" [113x78x32mm]
12V storage battery. Recommend 12V 7AH battery.
Input Frequency
50-60Hz
Output Current
3A
Efficiency (Typ.)
90%
Enclosure Finish
Spraying
Operating Humidity
10%-90%RH
Product Weight
7.3oz [207g]
