Aampal TMR 501 Operating Instructions Manual

MULTI FUNCTION DIGITAL TIMER-TMR_501
FUNCTIONS OF KEYS:
S.NO SYMBOLS
1
2
3
4
5 Enter
Reset
⚠️CAUTION:
➢ To avoid electric shock, power supply of the unit should be kept off while wiring.
➢ Wiring should be done strictly as per the terminal layout, given in the manual.
➢ This unit is not intended for outdoor use.
➢ The power connection cable must have a cross-section of at least 1mm and insula-
tion capacity of at Least 1.5kV.
➢ Avoid inflow of dust and contact of conductive material with the internal circuitry
of the unit.
OPERATING INSTRUCTIONS
NAME OF KEY
MENU KEY To Change Settings of Timer.
SCROLL KEY Scroll to next Parameter Configuration.
DECREMENT KEY To Decrease the Value.
INCREMENT KEY To Increase the Value.
ENTER KEY To Save New Parameter Values.
Thank you for purchasing this
Multi-Function Digital Timer.
P l e a s e
read this manual before operating
the unit. Store this manual in a
safe, easily accessible place for
your future reference.
www.aampal.com
FUNCTIONS
1
