Summary of Contents for Opti-Med JM-OT06
- Page 1 Opti-Med ® Operation Table JM-OT06 USER MANUAL Hangzhou Jupiter Medical Equipment Co., Ltd 1116, Gudun Road, West Lake District, Hangzhou, China Tel: +86-15021634329 Web: www.opti-med.net Email: info@opti-med.net...
- Page 2 Opti-Med ® 1. General Description This operating table is suitable for surgical procedures of the head, neck, thorax, abdomen perineum and extremities as well as for gynecological, obstetrical, urological, otorhino laryngological and cranial operations. It can be raised , lowered, Reversed Trendelenburg, Trendelenburg, Lateral Tilt.
- Page 3 Opti-Med ® 2. Specifications Dimensions of Table Top Overall length………………………………………………………………………2100mm Width………………………………………………………………………………...500mm Dimensions of Sections Head Rest ……………………………………………………………………...250×500mm Back section …………………………………………………………………...465×500mm Kidney Bridge…………………………………………………………………...75×500mm Seat Section …………………………………………………………………..450×500mm Leg Section …………………………………………………………………..600×240mm Foot Rest ……………………………………………………………………..273×180mm Table Top from Floor Min. height………………………………………………………………………...…750mm Adjust……………………………………………………………………………..≥200mm Range of Movements Max.
- Page 4 Opti-Med ® 3. Operation Instruction Operation of the oil pump The tabletop must be moved to the middle-surface, and make sure that the center of the tabletop remain consistent with the counterpart of column before adjusting operating table to rise or to decline.
- Page 5 Opti-Med ® 2) Movement and fixation of the base: By loosening Handle(As is shown in picture 1) of the base clockwise, the table can move, on the contrary, it can be stabilized. Attention : Do not loosen or tighten a handle, otherwise, the phenomenon that the base is not stable may happen.
- Page 6 Opti-Med ® 5. Accessories Accessories Pc（S） Remark Head Rest Body Support, Large Body Support, Small Shoulder Rest Kidney Bridge Anesthetic Screen Knee Crutch Arm support Cushion Optional Body Restraint Strap Components 6. Caution 1）The table board should be moved to the central position before the patient begins to operate.
- Page 7 12) It must be repaired and kept clean regularly once a year. 13） The service life for model JM-OT06 is in nine years. If it is used in expired period, it maybe led to wearing and corrosion of some mechanical parts, and had a negative influence upon the mechanical intensity.
