Summary of Contents for Opti-Med JM026-001
- Page 1 Opti-Med ® LED Examination Light JM026-001 USER MANUAL Hangzhou Jupiter Medical Equipment Co., Ltd 1116, Gudun Road, West Lake District, Hangzhou, China Tel: +86-15021634329 Web: www.opti-med.net Email: info@opti-med.net...
-
Page 2: Table Of Contents
Opti-Med ® Contents I. Brief introduction II. Structure and working theory III. Features and technical data IV. Installation and Modulation V. Operating instruction VI. Service VII. Safety VIII. Trouble shooting and Maintenance IX. Circumstance for transportation and storage X. Packing List... -
Page 3: Brief Introduction
The light source adopts high luminous efficiency, good color rendering, long service life and low thermal LED light emitting diode.And the lamp head of JM026-001 series consist of more light lamp, and each light source adopts multiple LED light emitting diode to produce... -
Page 4: Installation And Modulation
Opti-Med ® excellent, more reasonable. Advanced lighting system of integral reflection makes the luminance of the lamp reach 35,000LUX. Illumination can be adjusted steplessly and be memorized. The focal depth can be adjusted at will. B. Technical data Input voltage... -
Page 5: Service
The power should be switched off after operation, otherwise, the transformer will burnt out due to the condition of power on for a long time. JM026-001 integral reflection operation lamp, its tilt degree must be less than or equal to 10°. -
Page 6: Circumstance For Transportation And Storage
Opti-Med ® Repair How to replace a fuse: Cut off the power. Remove the cover by screwing out screws by a “ + ”screwdriver. Take the burnt fuse out of the connector at the base and replace a new one with the same specification. - Page 7 Opti-Med ® Control Circuitry Board LAMP 2 4V/ 75 W AC 220V DC 24V JSL2009-160D Titl e Size Nu mber Rev i sio n Dat e: 2 8-Sep -2 0 17 Sheet File: E:\说明 书\2 01 1 版说 明书中文 \1 60 简易 式\J SL1 60 D1 .DDB Drawn By: www.opti-med.net...
- Page 8 Opti-Med ® Hangzhou Jupiter Medical Equipment Co., Ltd 1116, Gudun Road, West Lake District, Hangzhou, China Tel: +86-15021634329 Web: www.opti-med.net Email: info@opti-med.net...
