Copper Beech CBHP12-2 Installation Instructions

Gas Hotplate
Model: CBHP36-6
INSTALLATION INSTRUCTIONS
1. A gas pressure regulator supplied with the unit
must be installed. Natural Gas 4.0" (102 mm)
W.C. Propane Gas 10.0" (254 mm) W.C.
2. An adequate ventilation system is required for
commercial cooking equipment.
3. These units are manufactured for installation in
accordance with National Fuel Gas Code, ANSI-
Z223.1/NFPA #54 (latest edition).
4. This appliance is intended for commercial
installation only and is not intended for home use.
JMC Furniture
Spartan/Bison Refrigeration
P: 855-525-5505
F: 863-816-5883
Copper Beech Range
□ CBHP12-2 12" wide 2 open burners
□ CBHP24-4 24" wide 4 open burners
□ CBHP36-6 36" wide 6 open burners
STANDARD FEATURES
■Stainless steel front w/ galvanized sides
■Octagon cast iron burner (25,000 BTU/hr)
■12" x12"(30x30cm) cast iron grate
■Standby S/S pilot for easy start
■Adjustable heavy duty legs
■Full width crumb tray at the bottom
■Durable brass control valve
■Easy access to pilot, w/ adjustment screw
■Easy gas conversion in field
■3⁄4" NPT rear gas connection
■Shipped with gas regulator
■One year limited parts and labor warranty
5. Equipment clearance requirement:
Non-Combustibles
Sides 0"
Back 0"
6. All the installation must be performed by qualified
technicians.
7. For gas conversion, please refer to conversion
instructions in the Instruction Manual Book.
Combustibles
Sides 4"
Back 4"
