Summary of Contents for KaVo EWL 9045
- Page 1 Operating instructions EWL 9045. Always on the safe side.
- Page 2 KaVo Elektrotechnisches Werk GmbH Wangener Straße 78 D-88299 Leutkirch Tel.: 0 75 61 / 86-0 • Fax: 0 75 61 / 86-265...
-
Page 3: Table Of Contents
Supplementary control 9045. User information ................................2 A 1.1 Meaning of the pictograms ............................2 A 1.2 Important information ..............................2 A 1.3 Safety measures ..............................2 A 1.4 Intended use and potential applications ........................3 A 1.5 Technical data ................................3 Description ..................................4 Operation ..................................5 Maintenance ..................................6 Malfunctions ..................................6 Installation ..................................7... -
Page 4: A 1 User Information
Important information for operator distribution of the instructions for use (IU) • the accident prevention regulations. and technician. require the prior consent of KaVo. Automatic mode All technical data, information and proper- Automatic sequence ties of the product described in these IU correspond to the state on going to press. -
Page 5: A 1.4 Intended Use And Potential Applications
Supplementary control 9045. A 1.4 Intended use and potential applications 4 dust-generating consumers can be con- nected to a central extraction system via the supplementary control 9045 with the single suction path switching system and the four- fold suction path diverter. A 1.5 Technical data Single suction path switching system Width... -
Page 6: A 2 Description
Supplementary control 9045. A 2 Description Supplementary control ” @ Jacks of external control inputs for suction points 2.1 to 2.4. ” Adjusting wheel for inlet air pressure reducer # Manometer for regulated inlet air pressure · £ Mains switch fi... -
Page 7: A 3 Operation
Supplementary control 9045. A 3 Operation When EWL products are operated for the first time and for every operation thereafter, it is essential to note the points mentioned in the section « A 1.3 Safety measures » ! Put central extraction system into operation. Switch on supplementary control at mains switch @. -
Page 8: A 4 Maintenance
Supplementary control 9045. A 4 Maintenance Repair and maintenance work on the electrical part of the unit may be performed only by qualified specialists or trained persons who have been made aware of the safety regulations. For maintenance work, disconnect the mains plug or isolate the unit completely from the mains supply, thus cutting off power to the unit. -
Page 9: B Installation
Supplementary control 9045. B Installation B 1 Scope of delivery – Accessories Scope of delivery Supplementary control 0.657.1561 Mains cable 0.223.4232 Vacuum hose 2m 0.695.0522 Protective filter 0.620.2091 Nipple 6/4 0.220.0455 L screw union 0.220.0962 Instructions for use 1.000.4141 Fastening rail for supplementary control 0.642.0282 Single suction path... -
Page 10: The Installation Is Performed In Two Steps
Supplementary control 9045. The installation is performed in two steps: B 3 Installation of the single suction path switching system (or optionally of the four- fold suction path diverter) and connection of the suction hoses. B 4 Installation of the supplementary control. -
Page 11: B 4 Installation Of The Supplementary Control
Staubabsa ” Connect external sealed keypads (optional) by means of KaVo cable fittings # to the sub-D jacks. Ensure correct assignment. Connect control lines @ for optional, external control elements to the control input jacks. Ensure correct assignment. -
Page 12: B 5 Commissioning
Mount L screw union R 1/8’’ Ì at a suitable point, chiefly at a reducing socket £ \ between central extraction system and KaVo suction hose. Make hole required for this purpose. Wind sealing tape around the thread of the L screw union and screw the Ì... -
Page 13: Guarantee Conditions
6 months from the date of purchase certified by the sales person. After expiry of the guarantee period, KaVo undertakes to provide a guarantee for a further 6 months for damage due to defects in the material or in the manufacture. -
Page 14: Spare Parts
Supplementary control 9045. Spare parts 0.657.1451 0.657.0961... -
Page 15: Declaration Of Conformity
Declaração de conformidade; EU-konformitetsförklaring EU-Konformitetserklæring; EY Vaatimustenmukaisuusvakuutus EC-Êîíôîðìíîñòü EU-Konformitetserklæring; Wir, We, Nous, Nosotros, Noi, Wij, Nós, Vi, Vi, Me, Vi, KaVo ELEKTROTECHNISCHES WERK GmbH Ìû, Wangener Str. 78 D-88299 Leutkirch im Allgäu erklären, dass das Produkt Nebensteuerung 9045 declare that the product Supplementary control 9045 déclarons que le produit... - Page 16 D D - - 8 8 8 8 2 2 9 9 9 9 L L E E U U T T K K I I R R C C H H . . T T e e l l e e f f o o n n 0 0 7 7 5 5 6 6 1 1 / / 8 8 6 6 - - 1 1 5 5 0 0 · · F F a a x x 0 0 7 7 5 5 6 6 1 1 / / 8 8 6 6 - - 2 2 6 6 5 5 I I n n t t e e r r n n e e t t : : w w w w w w .
