Summary of Contents for U Technology UT-GC-DMX-DECOD-5CH
- Page 1 UT-GC-DMX-DECOD-5CH USER GUIDE For further information please contact us customersuccess@utechnology.ca • utechnology.ca • (403) 800-3044...
- Page 2 GC-DMX-DECOD-5CH USER GUIDE Function Diagram, Product Data, Safety & Warnings ............3 Button Introduction &...
-
Page 3: Product Data
Pin2:D- Pin3:D+ Pin3:D+ CH 3:B/WW output (-) 3/B- CH 2:G/CW output (-) 2/G- CH 1:R/WW output (-) 1/R- UT-GC-DMX-DECOD-5CH Common anode output (+) DMX512 & Decoder Back Enter Down DC power input 2 groups plug in type terminal: Digital display DMX512 signal input &... -
Page 4: Factory Default Settings
GC-DMX-DECOD-5CH USER GUIDE BUTTON INTRODUCTION AND MENU DESCRIPTIONS • After powering on the device, use the Up and Down buttons to select different settings • Press the Enter button to enable setting changes, display will flash • Use the Up and Down buttons to change settings •... -
Page 5: Menu Settings
GC-DMX-DECOD-5CH USER GUIDE MENU SETTINGS A: DMX Address Setting Select menu click Enter button then click or hold Up/Down buttons to set DMX address. Click Back button to confirm. CH: DMX Channel Quantity Setting Select menu click Enter button then click or hold Up/Down buttons to set DMX channel quantity. Click Back button to confirm. - Page 6 GC-DMX-DECOD-5CH USER GUIDE MENU SETTINGS (CONTINUED) GA: Output Dimming Curve Gamma Value Setting Select menu click Enter button then click or hold Up/Down buttons to set gamma value (0.1-9.9). Click Back button to confirm. Output GAMMA <1 Brightness VALUE Level >1 DMX Value Level Micro Dimming:...
- Page 7 GC-DMX-DECOD-5CH USER GUIDE DMX DECODING MODE TABLES DMX address is 001, CH01: DMX Console Slide Number DMX Channel: dp1.1 dp2.1 For all output dimming For all output dimming For all output micro dimming DMX address is 001, CH02: DMX Console Slide Number DMX Channel: dp1.1 dp2.1...
- Page 8 GC-DMX-DECOD-5CH USER GUIDE DMX DECODING MODE TABLES (CONTINUED) DMX address is 001, CH04: DMX Console Slide Number DMX Channel: dp1.1 dp2.1 dp5.4 dp6.4 For output 1 dimming For output 1 dimming For output 1 dimming For output 1 dimming For output 1 micro For output 2 dimming For output 2 dimming For output 2 dimming...
- Page 9 GC-DMX-DECOD-5CH USER GUIDE STROBE CHANNEL DATA DEFINITIONS {0, 7} //undefined › {8, 65} //slow strobe − fast strobe {66, 71} //undefined {72, 127} //slow push fast close {128, 133} //undefined {134, 189} //slow close fast push {190, 195} //undefined {196, 250} //random strobe {251, 255} //undefined...
-
Page 10: Product Dimensions
GC-DMX-DECOD-5CH USER GUIDE 164 mm PRODUCT DIMENSIONS 73 mm 15 mm WIRING DIAGRAM DMX in/out DMX in/out DMX Signal 12345678 12345678 RJ45 Single Color LED Strip Pin1:Data+ 5/W2- Pin2:Data- Pin7:GND Signal Pin1:GND DMX Signal Pin1:GND RGBW LED Strip 4/W1- Pin8:GND Female Pin2:D- Male...
