Summary of Contents for BENETEAU OC30.1
- Page 1 OC30.1 Quille Relevable - Operating Instructions...
- Page 2 Operating Instructions: Keel command • You have two positons (keel UP – keel DOWN) • Keel command button (electric) is placed on the starboard side at the helm (see the command button here below) • The above button activates a pump to operate the hydraulic spring that moves the keel...
- Page 3 Operating Instructions: Keel Button • the red button is for SECURITY reason, once unlocked you push the above button and the system switch ON • by pushing on the left buttons the keel goes UP and DOWN • the buttons is electric, is simply connected to a pump •...
- Page 4 Operating Instructions: Keel Position - UP...
- Page 5 Operating Instructions: Keel Position - DOWN...
- Page 6 Interiors: Keel Lifting System • The keel lifting system is hidden by the saloon table • Table leaves: open/close • Canvas to hide the hydraulic spring...
- Page 7 Interiors: Keel Lifting System • The keel lifting system is hidden by the saloon table • Table leaves: open/close • Canvas to hide the hydraulic spring...
- Page 8 Interiors: Keel Lifting System • The keel lifting system is hidden by the saloon table • Table leaves can be opened • Canvas to hide the hydraulic spring...
- Page 9 THANK YOU...
