Summary of Contents for STARTEK FM220U
-
Page 2: Table Of Contents
Contents 1. Overview................ 1 2. Features................. 1 3. Applications ..............1 4. Specifications and System Requirements ....2 5. Driver Installation ............3 6. Fingerprint Matching ............ 5 7. How To Use Your Fingerprint Reader ......6 8. How To Scan Your Fingerprint Reader ......7 9. -
Page 3: Overview
FM220U User Guide Doc. FM220U_Win_1.0 1. Overview: FM220U is a high quality CMOS-based optical reader. It captures images and verifies fingerprints with high speed. FM-220U has been widely used in system wide enrollment and verification applications as a stand-alone or embedded device. -
Page 4: Specifications And System Requirements
FM220U User Guide Doc. FM220U_Win_1.0 4. Specifications and System Requirements 4.1 Specifications Parameter Value Unit Sensors CMOS Scanning 1/15 Image resolution Image capture format 13.3 x 16.4 Scanner output image size 264 x 324 Pixels Gray Level 8bits/pixel, max 256 gray scales... -
Page 5: Driver Installation
FM220U User Guide Doc. FM220U_Win_1.0 5. Driver Installation Install the driver before using the Startek fingerprint reader. To manually install device drivers You may download the Windows device driver from the link we provided. Step1. FM-220 . Right click and s... - Page 6 FM220U User Guide Doc. FM220U_Win_1.0 Step4. Step5. Unzip fm220_driver_ver_1.9.zip, and select driver path m220_driver_ver_1.9\ and press OK. Step6. Driver install success! You can try our demo program on Windows now.
-
Page 7: Fingerprint Matching
FM220 User Guide Doc. FM220_Win_1.0 6. FINGERPRINT MATCHING Step1. Step2. Select Step3. Press the Snap and GetTemplate botton to check the fingerprints quality. It is recommended to use the index finger or the middle finger for optimal fingerprint recognition performance. - Page 8 FM220 User Guide Doc. FM220_Win_1.0 Step4. Follow the diagram instructions to Enroll clear fingerprints into the Host Device or PC. Press and release the finger for three times as indicated. Step5. Press the Match button to begin matching the fingerprints of a user whose fingerprint data has been stored in the system.
-
Page 9: How To Use Your Fingerprint Reader
Proper placement is the key to good results? Startek fingerprint extraction algorithm is capable of extracting the correct minutiae even without benefit of a perfect print. However, the proper placement of your finger while scanning can help give more consistent results for any biometric application. - Page 10 FM220 User Guide Doc. FM220_Win_1.0 Try to match the fingerprints by rotating 30 degree on the sensor area or to exceed the sensor area. Upon successful matching with the u stored fingerprints, information is displayed with a score. However, the score you get is expected to be lower than the one you press it normally because there are fewer minutiae points captured.
- Page 11 FM220 User Guide Doc. FM220_Win_1.0 If your finger is cut or injured As a precaution, it s best to enroll more than one finger so that if one finger becomes unavailable for authentication, you will have an alternate finger to use. Most biometric applications provide the option to enroll multiple fingers.
-
Page 12: How To Care For Your Fingerprint Reader
Even in case the digital information is stolen, the fully matched information does not get authorization by STARTEK products, as in normal situations the input data should be different every time considering some miscellaneous signals are also... -
Page 13: Q And A
Area B shrinks while Area A expands. Security level will vary for different applications. The picture next to "Security Level & FAR & FRR" shows different security level demand for market segments and STARTEK's FAR vs. FRR curve. Secure Level Score Threshold...
