Summary of Contents for PPM ViaLiteHD HRK-12 HB-5 Series
- Page 1 ViaLiteHD 1U GPS Splitter User Manual GPS Splitter HRK-12-x-HB-5 CR5266 02/03/23 Pulse Power & Measurement Ltd, 65 Shrivenham Hundred Business Park, Watchfield, Swindon, Wiltshire SN68TY, UK Tel +44 (0)1793 784389 Fax +44 (0)1793 784391 Email sales@vialite.com www.vialite.com...
- Page 2 HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX Instrument Care and Safety Information Please read the whole of this section before using your ViaLiteHD product. It contains important safety information and will enable you to get the most from your Fibre Optic link. Electrical Safety The ViaLiteHD chassis provides the termination for power inputs and can be fitted with power supplies.
-
Page 3: Table Of Contents
HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX TABLE OF CONTENTS INITIAL INSPECTION .................................... 4 INTRODUCTION TO THE VIALITEHD RANGE ............................. 4 VIALITEHD GPS SPLITTER .................................. 5 Description ....................................5 3.1.1 GPS blind mate RX modules............................5 3.1.2 Redundant AC Version. -
Page 4: Initial Inspection
A ViaLiteHD system can be added to at any time, enabling the system to evolve with the needs of the user. ViaLiteHD is a product brand manufactured by Pulse Power and Measurement Ltd (PPM). ViaLite Communications is a division of Pulse... -
Page 5: Vialitehd Gps Splitter
‘E’ is the newer style module. It should be noted that because of the different RF and fibre connectors the two are not interchangeable. Should you wish to upgrade your Splitter rack then please contact PPM to discuss your requirements and availability of modules. -
Page 6: Power Interface Management
HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX The plug-in modules simply plug into the chassis, allowing the user to replace modules quickly and easily. For ease of upgrade and replacement, the GPS RX modules must be blind mate compatible allowing for simple plug and play operation. – refer to section 3.1.1 above. Control of the modules is performed by an embedded SNMP controller, which is NOT field replaceable. -
Page 7: Module Alarm Defeat
HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX Condition 1 - Power applied to Chassis, no alarms (i.e. normal condition) Pin NO is open circuit Pin NC is connected to COM Condition 2 - Power removed from Chassis and/or one or more module alarms (i.e. Alarm condition) ... -
Page 8: Minimum Power Supply Load
HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX 85044 ViaLiteHD Blank Panel, 5HP HPS-1-0 Blank plug The power supply blanking plugs are friction fitted, they are simply inserted and withdrawn from the IEC inlets, they are a tight tolerance fit to ensure that they are retained in position. -
Page 9: Chassis Specification
HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX Chassis Specification GPS Splitter GPS Splitter - DC Description 19” Rack Mounting Chassis Max. No. of GPS modules 2 (in slots 1-2 only) Max. No. of PSU modules 2 (in slots 4,5 only) 19”... -
Page 10: Lna Feed Simulation
HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX Note: See module handbooks for assignment and function of the “Analogue_monitor” pins 2 x 4-40 UNC thread No.1 contact No.13 contact No.14 contact No.25 contact Common chassis connector: 25 way D-Type connector female All connectors are viewed looking into connector from mating interface Each connector is shown in the correct orientation for normally mounted 1U chassis LNA feed simulation... -
Page 11: Slide In Chassis Dc Power Supplies, Hps-1-Gps-Dc
HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX supplies are diode OR’d, hence one unit will provide most if not all of the chassis power requirements. In the event of a failure all the chassis current can be provided by the remaining operational module. The Power supply front panel LED provides a visual indication of failure, and a power good alarm output is available for use at the “Chassis common”... -
Page 12: Fuse Replacement In Dc Power Supplies
HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX The HPS-1-GPS-DC power supply has a wide range direct current (DC) input and can operate from weight nominal DC supplies. DC power is applied at the rear of the chassis via 4mm screw terminals, and regulated direct current (DC) power is supplied to the chassis backplane PCB for distribution to the plug-in modules. -
Page 13: Specification
PLITTER ANDBOOK DOCX Suitable replacement fuse: Description: 5A, 125V, slow blow, OMNI-BLOK, SMD socketed PPM part number: 59887 Source: Littelfuse Suppliers part number: 0454005.MR Slot in base to access the fuse OMNI-BLOK removable fuse Position and replacement of HPS-1-GPS-DC fuse... -
Page 14: 19" Chassis Power Requirements
HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX Fuse Internal, 15A / 250V Internal, 5A / 125V [Fused inputs] [LIVE and NEUTRAL] [POSITIVE] Efficiency 85% typical 89% Typical 90% Typical Switch on current, cold start <40A @ 230Vac <4.5A @ 20V <4.5A @ 36V Output voltage... -
Page 15: Installation Guide
HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX Installation Guide Chassis Installation The ViaLiteHD Power Supply Modules do not have an isolating switch on the mains voltage inlet. For this reason, the ViaLiteHD Chassis MUST be installed within easy reach of a clearly labelled dual pole mains isolation switch, which supplies the equipment. The ViaLiteHD 19”... - Page 16 HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX To install a GPS RX module and matching interface plate Firstly inspect the rear Blindmating plate, ensure that the connector barrels are fitted into all RF connectors and are centrally aligned. ...
-
Page 17: 5Hp Blanking Panel Installation
HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX 5HP blanking panel installation Blanking panels should be the last panel installed into your chassis To install the blanking panel Firstly inspect the blanking panel ensure that the plastic barbs are in good condition. ... -
Page 18: Snmp Fibre Connections
HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX S1A -> S1A-1 to S1A-16 S2A -> S2A-1 to S2A-16 Prior to installing any optical connections care should be taken to ensure that both mating halves of the connection are free of any dust and contamination, if necessary clean with filtered compressed air. -
Page 19: Part Numbering
HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX Part Numbering For part numbering please refer to the relevant datasheet which can be found on our website or contact us. -
Page 20: Maintenance And Fault-Finding Guide
HRK-12- -HB-5 V HD 1U GPS S PLITTER ANDBOOK DOCX Maintenance and Fault-Finding Guide Refer to the following table that gives a list of commonly encountered problems and suggested solutions. Fault Possible Causes Solution Power LED does not illuminate on the Power is not connected to the PSU. -
Page 21: Product Warranty
Product Warranty The guarantee / warranty period, unless otherwise agreed in writing, shall be as stated in document F292 - PPM Manufactured Product – Warranty, which is available at: https://ppm.co.uk/warranty-periods/. Extended warranty options are available at the time of purchase.
