CCESSORIES Alvium IP Housing Kits User Guide V1.0.0 Note: Cameras, lenses, and cables not part of this product. Allied Vision Technologies GmbH // Taschenweg 2a, 07646 Stadtroda / Germany 2023-Jan-23...
Injury by a falling product The falling product can cause injury. Intended use Intended use of Allied Vision product is the integration into vision systems by professionals. All Allied Vision product is sold in a B2B setting. Alvium IP Housing Kits User Guide V1.0.0...
Page 3
FORSIGTIG Kvæstelser, hvis produkt falder ned Falder produkt ned, kan dette forårsage kvæstelser. Tilsigtet brug Allied Vision produktets tilsigtede brug er en indbygning i et visionssystem, udført af fagfolk. Alle Allied Vision produkter sælges i B2B. DE - Deutsch Sicherheit Bevor Sie das Produkt benutzen, lesen Sie diese Sicherheitshinweise.
Page 4
Si el producto se cae puede provocar lesiones. Uso previsto El uso previsto del producto Allied Vision es la integración en el sistema de visión por parte de profesionales. Todos los productos Allied Vision se venden dentro de una relación B2B.
Page 5
La chute de la produit peut entraîner des blessures. Utilisation prévue L’utilisation prévue du produit Allied Vision est son intégration dans des systèmes de vision par le soin de professionnels. Tout produit Allied Vision est vendu dans un cadre B2B. IT - Italiano Sicurezza Leggere queste istruzioni per la sicurezza prima di utilizzare il prodotto.
Page 6
Letsel door het vallende product Het vallende product kan verwondingen veroorzaken. Beoogd gebruik Het beoogde gebruik van het Allied Vision-product is de integratie in optische systemen door professionals. Alle Allied Vision-producten worden verkocht in de B2B-markt. Alvium IP Housing Kits User Guide V1.0.0...
Page 7
17. FORSIKTIG Skade ved det fallende produktet Det fallende produktet kan forårsake skade. Tiltenkt bruk Den tiltenkte bruken av Allied Vision-produktet er integrering i visjonssystemer av profesjonelle. Alle Allied Vision-produkter selges i en forretning til forretning-situasjon. SV - Svenska Säkerhet Läs igenom säkerhetsinstruktionerna innan du använder produkten.
Page 8
Read before use ZH - 简体中文版 安全需知 在使用产品之前,请阅读这些安全说明。请务必遵守相关警告 和 Intended 于第 17 页 . 注意事项 由坠落的产品造成的伤害 产品可能会坠落并造成伤害。 预期用途 Allied Vision 产品的预期用途是由专业人士整合到视觉系统中。所有 Allied Vision 的产品均通过 B2B 渠道销售。 Alvium IP Housing Kits User Guide V1.0.0...
This document at a glance Get an overview: About Alvium IP Housing Kits..........10 Shipping contents..............10 What else do you need? ............10 Alvium IP Housing Kits User Guide V1.0.0...
This document at a glance Read this document carefully Learn to use Alvium IP Housing Kits in the most safe and efficient way and avoid damage to cameras and lenses. About Alvium IP Housing Kits Alvium IP Housing Kits enable applications that require IP66 and IP67 protection.
Page 13
Mounting the Lens Tube..............38 Alvium IP Housing Kits User Guide V1.0.0...
Page 14
Document history and conventions This chapter includes: Document history ..............15 Conventions used in this user guide........15 Alvium IP Housing Kits User Guide V1.0.0...
NOTICE Material damage Precautions are described. Practical tip Additional information helps to understand or eases handling the product. Additional information Web link or reference to an external source with more information is shown. Alvium IP Housing Kits User Guide V1.0.0...
Intended use and safety This chapter includes: Intended use ................. 17 Your safety................17 Product safety ............... 17 Copyright and trademarks ............ 18 Alvium IP Housing Kits User Guide V1.0.0...
We are offering standard products as well as customized solutions. Intended use of Allied Vision product is the integration into Vision systems by professionals. All Allied Vision product is sold in a B2B setting.
Specifications This chapter includes technical data for two IP housings: Applied standards ..............20 Alvium IP Housing D55 Kit ............ 22 Alvium IP Housing D80 Kit ............ 24 Alvium IP Housing Kits User Guide V1.0.0...
Specifications Applied standards IP class Alvium IP Housing Kits comply with IP66 and IP67 classes according to IEC 60529. Shock and vibration Alvium IP Housing Kits were tested according to the following standards: • IEC 60068-2-6, sinusoidal vibration testing • IEC 60068-2-27, shock testing.
Page 21
IEC 60068-2-27: Shock Parameter Value Axis x, y, z Acceleration 40 g Number of shocks per axis 5000 Duration per axis 6 ms Waveform Half sine Table 7: Parameters for IEC 60068-2-27 tests Alvium IP Housing Kits User Guide V1.0.0...
Cable Entry Split M25 × 1.5 For Ø3.5 mm or for Ø5 mm and Ø6 mm cables Cable Entry Integrated M25 × 1.5 Excluding the length of the mounting thread. Table 8: Alvium IP Housing D55 specifications Alvium IP Housing Kits User Guide V1.0.0...
Cable Entry Split M25 × 1.5 For Ø3.5 mm or for Ø5 mm and Ø6 mm cables Cable Entry Integrated M25 × 1.5 Excluding the length of the mounting thread. Table 9: Alvium IP Housing D80 specifications Alvium IP Housing Kits User Guide V1.0.0...
Camera orientation ............... 31 Connecting and mounting the camera......... 32 Mounting the Back Plate............33 Assembling the Cable Entry ..........34 Mounting the Camera Tube and the lens......36 Mounting the Lens Tube ............38 Alvium IP Housing Kits User Guide V1.0.0...
Always protect the sensor from dust. Keep the circular protection foil on the lens mount until you start the assembly. After removing the circular protection foil, attach a lens or a lens mount cap. Circular protection foil Figure 3: Alvium G1 camera with circular protection foil Alvium IP Housing Kits User Guide V1.0.0...
Alvium IP Housing D80 | For 1 cable ø 5.0 mm and 1 cable ø 6.0 mm | For 1 cable ø 3.5 mm | For Cable Entry Split Table 10: Alvium IP Housing parts list Alvium IP Housing Kits User Guide V1.0.0...
- Torque wrench 35 mm × 38.5 mm for mounting - Thin flat head screwdriver to disassemble • To connect the housing tubes: Strap wrench Cable Entries For details on Cable Entries and for assembly tools, see www.pflitsch.de. Alvium IP Housing Kits User Guide V1.0.0...
8. Holding the Camera Tube (b) with one hand, rotate the Lens Tube (a) counterclockwise until the tubes disengage. See Figure 9. Store both tubes in a clean and dry place until you continue the assembly. Figure 4: Separating the housing tubes from each other Alvium IP Housing Kits User Guide V1.0.0...
Vision engraving on the right side (C). Figure 5: Camera Mounting Ring (f) oriented for an upright camera image To start the assembly To start the assembly, follow the instructions in Connecting and mounting the camera on page 32. Alvium IP Housing Kits User Guide V1.0.0...
18. Feed the 4 M2 × 4 mounting screws (k) through the mounting holes (F) into the camera’s mounting threads (H) and tighten at 0.18 Nm maximum torque. Figure 6: Connecting and mounting the camera Alvium IP Housing Kits User Guide V1.0.0...
Back Plate (g) and the mounting threads of the Camera Tube (b) match. 23. Insert the 8 M3 × 8 screws (l) into the mounting threads and tighten at 0.8 Nm maximum torque. Figure 8: Mounting the Back Plate (g) to the Camera Tube (b) Alvium IP Housing Kits User Guide V1.0.0...
27. Slide the Double Nipple (L) to the thread of the Back Plate (g) and rotate the Double Nipple (L) clockwise. 28. Tighten the Double Nipple (L) with an SW35 mm wrench at 6 Nm maximum torque. Alvium IP Housing Kits User Guide V1.0.0...
Page 35
Removing the Cable Entry To remove the Cable Entry, follow the steps from in reverse order. Use a thin flat screwdriver to disengage the sides of Pressure Screws (M) and Double Nipples (L). Alvium IP Housing Kits User Guide V1.0.0...
44. At smallest f-stop, focus the lens (P) to object distance. 45. Select the f-stop value required for your application.. Figure 13: Adjusting the lens after the camera tube assembly has been completed Alvium IP Housing Kits User Guide V1.0.0...
Mounting cameras in IP housings Thread holes and maximum torque values NOTICE Damage to cameras and Alvium IP Housing Kits Values for maximum torque apply to screw threads and mounting threads in dry state, without thread locking agents. • Adjust values to your setup.
Mounting the Lens Tube Lubricant on the Seal Ring (c) At Allied Vision manufacturing, the Seal Ring (c) is equipped with Uniflor 8512 lubricant. This keeps the housing tight for a long time. 46. Engage the thread of the Lens Tube (a) to the thread of the Camera Tube (b).
