Summary of Contents for HyQuest Solutions DH59
- Page 1 DH59 User Manual 04-2023 – 01-01-000...
-
Page 2: Table Of Contents
Part I Operation Part II Example ................................7 Diagram ................................9 Repair Part III Technical Data Part IV Obligations of the Operator and Disposal Part V Obligations of the Operator ........................12 Dismantling / Disposal ..........................12 © 2023 HyQuest Solutions... -
Page 3: I Disclaimer
HyQuest Solutions or KISTERS AG. Other product documentation and the information contained in it, names used may or may not be the trademarks of even if HyQuest Solutions has been advised of the their respective owners. possibility of such damages. -
Page 4: Scope Of Delivery
Scope of Delivery § Sampler with three nozzles: 3.2, 4.8 and 6.3 mm diameter § Sampler bottle: 0.5 litres, nylon, screw cap for DH48, DH59 and D49 units (additional bottles available as spare parts) § Carry case © 2023 HyQuest Solutions... -
Page 5: Safety Instructions
Before starting to work, you have to check the functioning and integrity of the system. § Check for visible defects on the DH59, this may or may not include any or all of the following mounting facilities, connectors and connections, mechanical parts, internal or external communication devices, power supplies or power supply lines, etc. -
Page 6: Part I Introduction
Thank you for choosing our product. We hope you will enjoy using the device. HyQuest Solutions manufactures, sells, installs and operates quality instrumentation, data loggers and communication technology. Products are designed with passion for environmental monitoring and with a deep understanding of the quality, accuracy and robustness needed to fulfil the requirements of measurement practitioners in the field. -
Page 7: Part Ii Operation
The filling time in seconds represents the total time of submergence of the instrument and includes the time involved in traversing the stream vertical in both the downward and upward direction. Example (Refer Diagram 1 Mean Velocity 1.2 metres/sec. Nozzle 1/4" Filling Time 10 seconds © 2023 HyQuest Solutions... - Page 8 Identification of personnel § Sampling time § Water temperature § Coordination with sample groups § Serial number of sample Before the bottle are reused they should be washed clean inside and outside to avoid contamination of future samples. © 2023 HyQuest Solutions...
-
Page 9: Diagram
Operation Diagram © 2023 HyQuest Solutions... -
Page 10: Part Iii Repair
In rare cases, a product may not be delivered in accordance with your order. In such cases HyQuest Solutions’ return and repair policy applies. For you as a customer, this means the following: 1. Contact HyQuest Solutions using the Repair Request Form made available online: https://cdn.hyquestsolutions.eu/fileadmin/Services/Downloads/HS-RepairRequestForm_EU.pdf... -
Page 11: Part Iv Technical Data
Technical Data Technical Data Type Suspended sampler using a winch, depth integrating Material Epoxy-coated cast, marine bronze body Net Weight 10 kg (22 lb) Length 380 mm Packing Details 16 kg, 0.01 m © 2023 HyQuest Solutions... -
Page 12: Part V Obligations Of The Operator And Disposal
Electrical waste and electronic equipment must not be disposed of as household waste! Instead, these old appliances must be collected separately and disposed of via the local collection and return systems. Integrated or provided batteries and accumulators must be separated from the appliances and disposed of at the © 2023 HyQuest Solutions... - Page 13 At the end of its service life, the lithium-ion battery must be disposed of according to legal provisions. EU WEEE Directive As players in the environmental market, KISTERS AG and HyQuest Solutions are committed to supporting efforts to avoid and recycle waste. Please consider: §...
- Page 14 Contact Data Europe | HyQuest Solutions (KISTERS AG) +49 2408 9385 0 info@hyquestsolutions.eu www.hyquestsolutions.eu Australia | HyQuest Solutions Pty Ltd +612 9601 2022 sales@hyquestsolutions.com.au www.hyquestsolutions.com.au New Zealand | HyQuest Solutions NZ Ltd +64 7 857 0810 sales@hyquestsolutions.co.nz www.hyquestsolutions.com.au Latin America...
- Page 15 © 2023 HyQuest Solutions 04/04/2023...
