Summary of Contents for LEDDOO CYLINDRA TL-1
- Page 1 CYLINDRA TL-1 USER MANUAL...
- Page 2 CYLINDRA TL-1 Download Smart Garden App Smart Garden App allows you to control and customize your controls for Smart Solar Table Lamp via your smart device. Search for the latest version on Apple App store or Google Play...
- Page 3 CYLINDRA TL-1 CONTENTS IMPORTANT SAFETY INSTRUCTIONS GETTING TO KNOW SMART SOLAR LAMP USING YOUR SMART SOLAR LAMP TROUBLESHOOTING...
- Page 4 CYLINDRA TL-1 IMPORTANT SAFETY INSTRUCTIONS Read All Instructions Before Use And Save For Future Reference This is an electric lamp-not a toy! To avoid risk of fire, burns,personal injury and electric shock,it should not be played with or placed where small children can reach it.
- Page 5 CYLINDRA TL-1 USER MANUAL Getting to Know Smart Solar Lamp In The Box Smart Solar Lamp x 1 I I n n s s t t r r u u c c t t i i o o n n M M a a n n u u a a l l x x 1 1...
- Page 6 CYLINDRA TL-1 USER MANUAL Specifications Model Cylindra TL-1 Power Supply 1 x 3.7V 2200mAh Li-Ion Battery Power Max. 3W Input Power 5V 1A Solar Panel 6V Monocrystalline Body Material Aluminum die casting IP Grade IP44 Supported OS Android 5.0 or iOS 9.0 and above 4.0 and above...
- Page 7 CYLINDRA TL-1 970 g Before first use min . 8h...
- Page 8 CYLINDRA TL-1 How to Charge USB Type C, input 5V 1A Method 1 Method 2 ≥ Lift the silicone seal ring Put Lamp in Sunlight for Plug-in USB Type C Charge Cable and connect to the main power via an adaptor...
- Page 9 CYLINDRA TL-1 Using Your Smart Solar Lamp Connecting with Smart Device 1. Download “Smart Garden” from Google Play 2. Make sure your smart device’s bluetooth, cellular or Apple App Store and install. Register as and location have turned on before pairing...
- Page 10 CYLINDRA TL-1 Controlling with APP Always make sure your smart device’s bluetooth have turned on to control the lamp About Information about the device or other Static Color Settings Customize the color or brightness Dynamic Scene Settings Select a preset Scene(6 Scene available),...
- Page 11 CYLINDRA TL-1 Using Your Smart Table Lamp Controlling without Smart Device ON OFF The lamp can also been controlled without Smart device: Press the power button once to switch mode between: 1. Mode A: Lamp breathe twice, then turn to Photosensitive* mode 2.
- Page 12 CYLINDRA TL-1 Switch to a new device/Reset the lamp 3sec 1. Hold power button for 3 seconds, the lamp 2. Make sure your new device’s bluetooth, cellular will flash in blue, lamp has now been reset and and location have turned on...
- Page 13 CYLINDRA TL-1 Using Your Smart Table Lamp Create Group with other Lamps 1. Make sure all lamps have connected to your 2. Enter any lamp’s control panel, touch the ‘Pencil’ device and controlable before create group logo on right top side of screen 3.
- Page 14 CYLINDRA TL-1 Troubleshooting Reason Reason Problem Make sure Bluetooth, Cannot find Smart Lamp Cellular and Location have on App when adding lamp turned on and Smart Garden App is authorized to use above function. Connecting Failure When lamp is connected and...
- Page 15 CYLINDRA TL-1 Instructions: This unit contains rechargeable batteries. Switch the ON/OFF switch to “ON”. The unit is ready to be used now. Place the solar panel in a way that it will collect as much daylight as possible (not right under a tree, in the shade). When it starts to get dark, a light/dark sensor will switch the unit on automatically.
- Page 16 CYLINDRA TL-1 IMPORTER: B&K LUMITEC 2 rue Alfred Kastler Zone Industrielle 67850 Herrlisheim - France OFFICE FRANCE +33 (0) 3.88.96.80.90 info@bklumitec.com OFFICE EXPORT +49 (0) 7248 94790 30 export@bklumitec.com...
