ENGLISH
• PJSFM2 Rechargeable Jobsite Fan
• 42" (106.7 cm) USB-C Cable
• Instruction Manual
• Cell Type: 18650 Lithium-ion
• Capacity: 6400mAh (46.08 Wh)
• Operating/Storage Altitude: 6562' (2000 m)
• Operating Temperature: 14° to 104°F (-10° to 40°C)
• Storage Temperature: -4° to 113°F (-20° to 45°C)
• Storage Humidity: <75% Relative humidity
• Charging Temperature: 32° to 104°F (0° to 40°C)
(For optimum charging, ambient temperature should be
below 86°F (30°C))
• Operating/Charging Humidity: <85% non-condensing
• Runtime (minimum): High 5 hours, Low 12 Hour
• Charging Time: Full charge in 6 hours under optimum
• Life Expectancy: Up to 500 charging cycles typical
• Charging Requirements: Max 5V DC, 0.5A-2.4A (12W Max)
• Dimensions: 12.9" × 10.4" × 5.4" (327.7 × 264.2 × 137.2 mm)
• Weight: 3.93 lb (1782 g)
• Drop Protection: 6.6' (2.0 m)
• Ingress Protection Rating: IP54
• Standards: UL 507, CSA C22.2 #60335-1, #60335-2-80,
UL2054, IEC62133, CE, UKCA, DOE/CEC, NRCan
Specifications subject to change.
1.800.561.8187
CONTENTS
GENERAL SPECIFICATIONS
(up to 3 months)
charging conditions
(depending on use & care)
www.
Rechargeable Jobsite Fan – Instructions
information@itm.com
.com
PJSFM2
Advertisement
Table of Contents
Related Manuals for Klein Tools PJSFM2
Summary of Contents for Klein Tools PJSFM2
- Page 1 ENGLISH CONTENTS PJSFM2 • PJSFM2 Rechargeable Jobsite Fan • 42" (106.7 cm) USB-C Cable • Instruction Manual Rechargeable Jobsite Fan – Instructions GENERAL SPECIFICATIONS • Cell Type: 18650 Lithium-ion • Capacity: 6400mAh (46.08 Wh) • Operating/Storage Altitude: 6562' (2000 m) • Operating Temperature: 14° to 104°F (-10° to 40°C) •...
- Page 2 WARNINGS Read, understand, and follow these instructions to ensure safe operation. Failure to observe these warnings can result in risk of fire, electric shock, serious injury and/or property damage. • DO NOT use the product if it is damaged or modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion, or injury.
- Page 3 ENGLISH FIG. A FEATURE DETAILS (FIG.A) 1 Fan blades 7 Battery status indicator 2 Fan cage 8 Charging port cover 3 Fan cage arms 9 USB-C input 4 Clamp 10 #10D Nail Hole (with rubberized grip) 5 Handle 11 Magnets (x4) 6 Power button SYMBOLS ON PRODUCT (FIG.B) Warning or Caution...
- Page 4 • Nail hole – place the hole over the nail head and slide into the slot for secure mounting. TROUBLESHOOTING PJSFM2 will NOT recharge IF: • The cable is not properly connected to charger output or battery input. Check connection.
