SuperHandy Cordless 1.0 Gal. Backpack Fogger
With Blowing Function
WARNING:
Before application, customer must read this instruction manual
carefully.
If any doubt, please contact our company directly (1-866-493-0524).
We are free from any accident due to improper operation.
When using this product. Failure to observe these instructions could
lead to serious injury or death.
Advertisement
Table of Contents
Related Manuals for Super Handy SuperHandy GUO058
Summary of Contents for Super Handy SuperHandy GUO058
- Page 1 SuperHandy Cordless 1.0 Gal. Backpack Fogger With Blowing Function WARNING: Before application, customer must read this instruction manual carefully. If any doubt, please contact our company directly (1-866-493-0524). We are free from any accident due to improper operation. When using this product. Failure to observe these instructions could lead to serious injury or death.
-
Page 2: Charger Use
WARNING: CHEMICAL AND FIRE HAZARD Always Know Your fogger. Take time to fully read the Installation and Operator's Guide, in order to understand your fogger and its operations. Always wear gloves, eye and ear protection. Never store battery pack in a tool box or pocket with nails, screws, keys, etc. Shorting of battery terminal may cause fire. -
Page 3: Electrical Hazard
ELECTRICAL HAZARD Never operate charger if it has received a sharp blow, been dropped or otherwise damaged in any way. Never charge battery in damp or wet environment. Always charge battery at temperatures between 0°C-49°C (32°F-120°F). Always store battery at temperatures between 0°C-30°C (32°F-86°F). Always disconnect charger when battery is fully charged. -
Page 4: Structure Of Product
Structure of product: 10 11 12 13 14 25 24... - Page 5 Part No. Description Quantity Part No. Description Quantity Fan blade Fogger components connector Air duct Right case connecting tube Pipe Screw Diameter Battery connector Duct nozzle Barrel Holder Micro Switch Plug Switch paddle Barrel cover Switch Barrel body Micro Switch Rubber plug Strap Fan cover...
-
Page 6: Operation
Warning: NO direct fogging highly toxic pesticides, undiluted pesticides, banned pesticides and special chemicals. It should comply with the safety instructions provided by the pesticide manufacturers when treating of pesticides. On security grounds, the chemical tank cannot be added into inflammable and explosive, highly volatile special chemicals, such as gasoline, alcohol, phenylacetone etc. - Page 7 Screw the blowpipe (NO.30) or fogger components (NO. 1) STEP1 STEP2 Description of switch gear Shut down Blowing Fogging Instructions for the use of blowing STEP1 Install the battery STEP2 Screw the blowpipe STEP3 Turn on the blowing switch...
- Page 8 Instructions for the use of fogging STEP 1 Install the battery STEP 2 Hose assembly STEP 4 Turn on the blowing switch STEP 3 Screw the fogger components STEP 5 Turn on the fogging switch (Running on 2 seconds) Note: Add the chemical after filtered with the filter funnel, tighten screw the tank lid.
-
Page 9: Technical Specification
Use Direction The supply voltage should match the machine’ s requirements. Do not make the pipe folded and extruded, avoid the metal or other sharp objects puncture the pipe. Do not turn on and off power switch frequently, avoid damage the switch and motor. When there is abnormal sound or smell during working, shut down immediately, cut off... -
Page 10: Problem And Solution
Problem and Solution Problem Reason Solution Fan not running Power supply is not connected. 1. Check battery whether there is electricity. 2. Make sure the power switch is on. Machine run, no fogging 1. The fogging switch is not 1. Turn on the fogging switch. turned on. - Page 11 Size: 145x210mm 157克铜版纸 REV 24/09/20 2.09.05.01.614...
