EVERCROSS XP9 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

HELMETS
SAVE LIVES!
Always wear a properly fitted helmet that complies with safety
standards when you ride your hoverboard.
CORRECT FITTING:
Make sure your helmet
covers your forehead.
INCORRECT FITTING:
Forehead is exposed and
vulnerable to serious injury.
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XP9 and is the answer not in the manual?

Questions and answers

Related Manuals for EVERCROSS XP9

Summary of Contents for EVERCROSS XP9

  • Page 1 HELMETS SAVE LIVES! Always wear a properly fitted helmet that complies with safety standards when you ride your hoverboard. CORRECT FITTING: Make sure your helmet covers your forehead. INCORRECT FITTING: Forehead is exposed and vulnerable to serious injury.
  • Page 2 Thank you for choosing and buying our EVERCROSS Hoverboard.It is important to us that our customers are safe in driving with our Hoverboard.

  • Page 3: Operating Principals

    OPERATING PRINCIPALS The device uses digital electronic gyroscopes and acceleration sensors to control balance and motion, depending on the user's center of gravity. The device also uses a control system to drive the motors that are located within the wheels. The device has a built-in inertia dynamic stabilization system that can help assist with balance when moving forward and backwards, but not while turning.

  • Page 4: Package Contents

    PACKAGE CONTENTS • 1 x EVERCROSS Hoverboard • 1 x Hoverboard Seat Attachment • 1 x Charge Adapter • 1 x Instruction Manual FEATURES/PARTS 1 - Charge Port 2 - Power Button 3 - Non-Pneumatic Solid Tires 4 - Foot Mat...

  • Page 5: Box Content

    HOVERBOARD SEAT ATTACHMENT 1. Seat 2. Handle Bar (R) 3. Pedal Mounts ① ⑤ 4. Adjustable Strap 5. Handle Bar (L) 6. Frame Base ② ⑥ ⑦ 7. Twist Knob ③ ⑧ 8. Frame Extension ④ 9. Foot Rests 10. Swivel Wheel ⑨...

  • Page 6: Safety Guide

    HOVERBOARD SEAT ATTACHMENT MANUAL SAFETY GUIDE 1. This product is based on the self-balancing scooter. And the speed limit is 12KM/H. Please slow down before hearing the alarm sound. 2. For yours and others’ safety, please don’t either accelerate the kart kit to high speed suddenly or stop suddenly.
  • Page 7 ASSEMBLING SEAT ATTACHMENT If you have questions or concerns about any of these steps, please feel free to contact our Customer Service Team at support@evercross.eu. A representative will be in touch to walk you through these steps. Carefully follow the steps shown on the following pages for assembling the Hoverboard Seat Attachment.
  • Page 8 Carefully follow the steps shown on the following pages for assembling the Hoverboard with Seat. Your Hoverboard Seat Attachment must be completely assembled before installing it onto your XP9 Hoverboard. Please refer to the ‘ ASSEMBLING YOUR XP9 HOVERBOARD SEAT ATTACHMENT’ section for assembling procedures.
  • Page 9 1. As shown in the figure below, install 4 sensor foam pads under the pedal bracket. Place the pedal mounts onto the foot pedals of your self-balancing scooter with the front wheel facing forward. Ensure the pedal mounts are centered on the foot pedals of your scooter as much as possible.
  • Page 10 Ensure that the seat attachment is securely attached to the hoverboard. See below diagram for correct fitting. Small foam pad 5. Your Hoverboard Seat Attachment should be properly installed onto your EVERCROSS XP9 as shown below.

  • Page 11: Operating The Device

    BEFORE RIDING & RIDING YOUR HOVERBOARD OPERATING THE DEVICE What you need to know for the optimal operation of our device, you can read here. You will get important information about how to best and easiest handle our device. Please note: For your safety and a long service life of your device, it is important that you observe these instructions at all times.
  • Page 12 Do not connect the charger (8, 9) if you detect signs of moisture on the charger port (1). • The charger port (1) is next to the on / off button (2). • Please connect the charger cable (8) to the mains cable (9). •...
  • Page 13 DRIVING WITH THE EVERCROSS HOVERBOARD If you use our device, this may also be hazardous. Therefore: Learn more about our device little by little. Allow yourself enough time to exercise. Practice getting on and getting off our device together with an acquaintance or the parents, until you are able to master this with ease.
  • Page 14 Our Hoverboard does not have a brake mechanism. If you wish to reduce speed, you must slowly move your body‘s centre of gravity / your weight backwards. Please only get off the device in backwards direction. Should you get off in forward direction, your body‘s centre of gravity / weight will be moved forward.

  • Page 15: Controls And Display

    Do not step or stand on any other area of your hoverboard. Do not put items on the foot mats. Doing so will make the XP9 turn on, and increase the probability of collision and cause injury to people, riders, or damage the device. BATTERY INDICATOR WHILE CHARGING: (Hoverboard) Yellow LED light flashing indicates battery is charging.
  • Page 16 • Always charge the battery immediately after riding. Failure to recharge battery periodically may result in a battery that will not accept a charge. • The charger supplied with the XP9 should be regularly examined for damage to the cord, plug, enclosure and other parts. In the event of such damage, the Hoverboard must not be charged until it has been repaired or replaced.

  • Page 17: Storage And Transport

    CLEANING & MAINTAIN THE HOVERBOARD Please deactivate the device. If you wish to clean the device, remove the plug of the charger from the power socket. Now let all parts cool down completely. • When cleaning the appliance, do not use solvents or abrasive cleaners.

  • Page 18: Bluetooth Speaker

    PAIRING THE SPEAKER 1. Ensure your XP9 Hoverboard is turned off. If it is not, please turn it off first before pairing. 2. Turn on your XP9 and the speakers will announce that it’s waiting for a Bluetooth connection.
  • Page 19 CALIBRATE YOUR HOVERBOARD Many problems that surfaces are due to misconfigurations on the gyro board. Most often they are off balance and in that state your hoverboard does not know if you’re on a flat surface, going up/downhill or even if you are standing on it or not.

  • Page 20: Safety Precautions

    XP9 Hoverboard is not liable for tickets or violations given to riders who do not follow these regulations. • For your safety, always wear a helmet that meets safety standards.

  • Page 21: Safety Alerts

    SAFETY ALERTS While riding your XP9 Hoverboard, if there is a system error or improper operation performed, the device will prompt the user in a variety of ways. You will notice the Running Indicator Light will turn RED and you will hear a beep sound alerting you to take precaution and cease operation, which may make the hoverboard stop suddenly.

  • Page 22: Safety Checklist

    Do not step on if the Running Indicator is red. • Do not operate the device in crowded areas. If you and your friend(s) are riding XP9 Hoverboard together, be sure to keep a safe distance between each other to prevent collisions, property damage, serious injuries or even death.
  • Page 23 TROUBLESHOOTING & BATTERIES RECYCLING Problem Cause and correction of the defects Device is not Hoverboard is not activated. responding. Please activate our device with the on / off button (2). Battery is not fully charged. Please charge the battery. A violent shock (caused by a rollover, for example) has shaken our unit.
  • Page 24 EUROPEAN DISPOSAL DIRECTIVE 2002/96/EG Never dispose your training device in your regular household waste. Dispose the device only at a local or approved disposal. Take care of the currently ap- plicable regulations. If you have doubts contact your local authorities for information about a correct and environment friendly disposal option.

  • Page 25: Warranty

    2)The warranty will be performed in such a way that we shall decide whether to repair the defective parts or to replace them with working parts free of charge. EVERCROSS reserves the right to exchange the product for a replacement product of equal value if the product sent in cannot be repaired within a reasonable time or at a reasonable cost.
