Summary of Contents for Weldex WDAC-4288WD
- Page 1 WDAC-4288WD...
- Page 4 The camera delivers clear high quality pictures, even when backlit, by increasing exposure in dark areas while decreasing it in bright areas; a coreected image clear results. The video drive lens and the DC drive lens can be selected by the touch of a switch.
-
Page 7: Side View
Overview Side View Bottom View Tripod Mounting Bracket Screw Hole Used to fix the camera onto a bracket or tripod. The screw sizes for this hole are as follows: “1/4-20 thread, 1/8” length... -
Page 8: Installation Procedures
Overview Installation Procedures Lens Rear View The lens is not supplied with this camera. Purchase a lens suitable for the environment. This camera accepts an auto iris lens, and both C-and CS-mount lenses. Note • It is recommended to use the DC type Auto Iris Lens to effectively enjoy the major functions of this camera. - Page 9 Installation Procedures Using a C/CS mount lens 3. Remove the cover of the Auto IRIS Lens connector plug and solder the lens Before installing a lens, identify whether the lens to be installed is a C-Mount cable to the connector pins of the plug or CS-Mount.
- Page 10 AC24V / DC12V...
