ASSEMBLY INSTRUCTIONS
ITEM: WF300331 - LOVE SEAT
WARNING
*This product has been designed for seating one (1) average adult. To prevent injury and damage to this unit, PROHIBIT jumping on it.
*This product is designed for home use and not intended for commercial use.
*Children under the age of 5, small infants and babies should not sleep alone on this product for safety reasons.
*Recommended # of people needed for handling: 2 (however it is always better to have an extra hand.)
*THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1/8
Advertisement
Table of Contents
Related Manuals for Modern Living WF300331
Summary of Contents for Modern Living WF300331
- Page 1 ASSEMBLY INSTRUCTIONS ITEM: WF300331 - LOVE SEAT WARNING *This product has been designed for seating one (1) average adult. To prevent injury and damage to this unit, PROHIBIT jumping on it. *This product is designed for home use and not intended for commercial use.
- Page 2 PARTS LIST SEAT BODY 1 BACK REST 2 ARMS 3 QTY: 1PC QTY: 1PC QTY: 1PAIR (In the storage underneath of seat body) METAL SUPPORT 5 PLASTIC LEGS 4 QTY: 1PC QTY: 4PCS HARDWARE FLAT WASHER 8 BOLT Ø ALLEN KEY 6 '' x20MM 7 QTY: 2PCS QTY: 1PC...
- Page 3 Step 1: Carefully unpack parts/hardware from box and storage of seat body, place on a clean flat surface. HARDWARE METAL SUPPORT QTY: 1PC Storage, underneath of seat body. Allen Key Plastic Legs Bolt Flat Washer 4 "x20mm 7 x 2pcs 6 x1pc 4 x 4pcs 8 x 2pcs...
- Page 4 Step 2: Place both arms as shown below, secure two legs into pre-drilled holes on the bottom of arms. Please avoid overtightening. x 4pcs...
- Page 5 Step 3: Carefully lift and turn assembled arms onto its legs. Insert seat body metal plates to both arms as shown below. Ensure it is correctly in place.
- Page 6 Step 4: Insert backrest with ear piece metal plates to both arms as shown below. Ensuring is correctly in place.
- Page 7 Step 5: Insert backrest metal plates to both arms as shown below. Ensuring it is correctly in place. After that, turn to back rest and assembly part (5) by using hardware (6) , (7) , (8). METAL SUPPORT QTY: 1PC...
- Page 8 Step 6: Finally, stretch and pull down rear cover evenly before securing velcro strip to seat base. Repeat if necessary for better fit. Cover...
