Please read the manual before using the product. The manual and carton contain
important information, please keep them properly for later references. If failure to
following the instruction in the manual, it might be dangerous for your child.
In order to improve the product and quality, we may change the parts of structure,
appearance, packing method, assembly method and function of the product
without any notice. When there is any difference between the manual and the
product, please subject to the actual product. We are sorry for any inconvenience.
The assembly manual of
battery operated car
Products should be assembled by an adult. Protective equipment should be worn. Not
to be used in traffic. Not suitable for children under 3 years. Choking hazard- small
parts. In unassembled state, contains potentially hazardous small parts. Please keep
out of the reach of small children. Pay attention to the potential hazards of using the toy
in areas other than private grounds.
Model:SX1628
Executive standard：
EN71-1
EN71-2
EN71-3
EN62115
ASTM F963
WARNING
Advertisement
Summary of Contents for HOLLICY SX1628
- Page 1 When there is any difference between the manual and the product, please subject to the actual product. We are sorry for any inconvenience. Model:SX1628 Executive standard： EN71-1...
-
Page 2: Parts List
PARTS LIST PARTS NAME PICTURE QTY PARTS NAME PICTURE Main body Training wheel Rear mirror Battery charger Front wheel LED light wheel Tool bag PRODUCT SPECIFICATIONS Battery 12V-7AH Main material Suitable age 36-95 Months Weight limit 30kg Product size 102x64x45.5cm Speed 3-5KM/Hour Runtime... -
Page 3: Assembly Instruction
ASSEMBLY INSTRUCTION The car should be assembled by the adults. Choking hazard, keep children away while assembling. Children under 3 years are prohibited to use. Please count all the parts carefully before assembling. And dispose the plastic bag properly. 1.Front wheel assembling Front axle Connect the front wheel and the front fork, (first, press... - Page 4 4: Connect the power The power supply is under the oil tank, take out the screw on the battery box panel with the tool, open the battery box panel from one end, expose the battery box, connect with the red plug, you can connect the power.
-
Page 5: Security Warning
SECURITY WARNING 1.The installation and charging of vehicle should be under adult supervision at all times. 2.This product is limited to the children from 3 to 8 years, 66 pounds weight limit, please do not overload. 3.This product is ideal for driving on a hard flat surface. 4.It is strictly prohibited in the streets or the road, pot holes, and slopes. - Page 6 USAGE DIRECTION 1. Before using it, make sure that all the following works are done. ● Step described in accordance with the instructions to complete the installation of the car, the battery plug-in has been connected, the power supply has been switched on. ●...
- Page 7 2. Operating(function reference diagram) Forward/Backward Fast/Slow:speed Lamp on/ off Horn Horn One-start Button MP3 Screen Horn Mode Short press : music / Short press : story / Long press: volume up Long press: Volume down Big memory Battery indicator light Pedal Audio input...
- Page 8 MP3（optional） Mode Horn Short press : story / Long press: Volume Short press : music / down Long press: volume up Battery indicator light Big memory Audio input CHARGING WAY ·For Safety purpose, battery charging by adults only. ·Fully charged is necessary for first time to use. .Power OFF before charging,then put the charger into the rear charging hole.
- Page 9 1.First insert the plug of the charger into the charging port. 2.Then insert the charger to the power socket. (The car cannot be started when it is being charged) Attention: ·Do not use incorrect battery or charger. ·Do not mix old and new or different types of batteries. ·The battery terminal should not be short circuit.
- Page 10 MAINTENANCE AND SERVICE 1.Parents should check whether all the parts are perfect before using, like battery, charger, wire, plug, out body and other parts are broken ,whether the screw is loose. whether there is potential safety hazard, if found then it has to repair. 2.Use a small amount of lubricating oil for moving parts, to prevent wear and tear of rust after using the toys for some time.
- Page 11 10.Don't put toys for other purposes. Put the battery in the right polarity. 11.It is forbidden to battery is negative short circuit. Non rechargeable batteries, can't charge. 12.Chargeable batteries can only be charged adult the guardianship of adults. 13.Don’t mix the old or new batteries or different type of batteries.
- Page 12 After-sales service :planetsales6@gmail.com PINGHU SHUANGXI BABY CARRIER MANUFACTURE CO.,LTD. PINGHU BABY CARRIER INDUSTRY CITY, ZHEJIANG, CHINA...
