- Page 1 CD100A Combustible Gas Leak Detector 99 Washington Street Melrose, MA 02176 INSTRUCTION MANUAL Phone 781-665-1400 Toll Free 1-800-517-8431 ENGLISH Visit us at www.TestEquipmentDepot.com...
-
Page 2: Table Of Contents
TABLE OF CONTENT Safety Tips Introduction International Symbol Functions Features Operating Instructions Specifications Sensor Filter and Sensor Replacement Battery Replacement Replacement Parts Optional Accessories Electromagnetic Compatibility Warranty Disposal Cleaning Storage SAFETY TIPS One year limited warranty Using this detector, read all safety information carefully. “WARNING”... -
Page 3: Introduction
INTRODUCTION The CD100A Combustible Gas Leak Detector is capable of sensing many combustible, non-combustible and toxic gases that include but are not limited to the following: Acetone Industrial Solvents Alcohol Jet Fuel Ammonia Lacquer Thinners Benzene Methane Butane Naphtha Ethylene Oxide Natural Gas Gasoline-Petrol Propane... -
Page 4: International Symbol
INTERNATIONAL SYMBOLS Dangerous Voltage Ground AC Alternating Current Warning or Caution Double Insulation DC Direct Current (Protection Class ll) Either AC or DC Fuse Not Applicable to Battery Identified Model FUNCTIONS • Senses leading combustible, non-combustible, and toxic gases • Minimum detection: 50 ppm methane FEATURES •... -
Page 5: Operating Instructions
OPERATING INSTRUCTIONS Turn the instrument on by rotating the thumbwheel downward in a non-contaminated environment (fresh air). The green power LED will be illuminated when the unit is turned on. If the battery level is low, the red LED will be steady and the tic will not be adjustable. -
Page 6: Specifications
SPECIFICATIONS Power supply: 1 x 9V battery Sensor: Solid state semi conductor Sensitivity: < 50 ppm methane Indicators: Audible: Adjustable tic rate Visual: Flashing LED Warm-up: 10 seconds Response Time: Instantaneous Duty Cycle: Continuous Battery Life: 5 hrs. typical use Dimensions: 8”... -
Page 7: Battery Replacement
BATTERY REPLACEMENT Turn off the power and remove the battery case cover. Remove and dispose of old 9V alkaline battery promptly in a manner consistent with disposal regulations. Always use a 9V alkaline battery. Ensure the polarity of the battery matches that shown in the compartment. -
Page 8: Warranty
If within the warranty period your instrument should become inoperative from such defects, the unit will be repaired or replaced at UEi’s option. This warranty covers normal use and does not cover damage which occurs in shipment or failure which results from alteration, tampering, accident, misuse, abuse, neglect or improper maintenance.
