Bulldog Security Magnum BD4055L Manual

Led digital top load vault
Hide thumbs
1
2
3
Table of Contents

Advertisement

Quick Links

Download this manual

1. Locking Mechanism

2. Programming Button

3. Battery Compartment

4. Silent Mode Switch

Thank you for purchasing the Magnum Digital Vault. To get started you will need 4 AA Alkaline batteries (not
included), the instructions and the emergency key. The vault has been shipped in the locked position. To install
the batteries and begin programming your new vault please read the entire instruction manual and then
proceed to the "Opening the vault using the emergency key" section below.
Opening the Quick Vault using the emergency key: The Quick Vault is supplied with an emergency key to open
it manually. You will need this key to open the vault so that the batteries may be installed or replaced in the
event of a loss of power or an electrical malfunction. To open the vault using the emergency insert the key into
the "Emergency Key Lock" (8 on diagram). Turn it counter clockwise or to the left to open the lid. Do not store
your key inside of the vault! The key will override the vaults electronic system allowing you to access the vault
at any time regardless of the battery condition so always store your keys in a secure location. Your emergency
key has a key code printed on the key. Please record your key code below and on the included warranty card.
You will need this number to reorder any lost keys in the future.
KEY CODE
Magnum
LED Digital Top Load Vault (BD4055L)
Instruction Manual

6. LED Access Buttons

7. Power on Button

8. Emergency Key Lock

9. Security Cable Slot

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Magnum BD4055L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bulldog Security Magnum BD4055L

  • Page 1 Magnum LED Digital Top Load Vault (BD4055L) Instruction Manual 1. Locking Mechanism 5. Interior Light 9. Security Cable Slot 2. Programming Button 6. LED Access Buttons 3. Battery Compartment 7. Power on Button 4. Silent Mode Switch 8. Emergency Key Lock Thank you for purchasing the Magnum Digital Vault.
  • Page 2 Installing the Batteries: For this step you will need 4 AA Alkaline batteries (not included). With the lid open locate the “Battery Compartment” (3 on diagram). Open the compartment cover by releasing the plastic tab. Remove the battery holder from inside of the "Battery Compartment". The battery holder is attached to the inside of the vault with electrical wires, please use caution not to pull on the wires.
  • Page 3 Interior Light: The vault is equipped with a LED interior light (5 on diagram). The light will automatically illuminate for 15 seconds when the door is opened using the personal code. After 15 seconds the light will automatically turn off. Low Battery Warning: If the 4 AA batteries go below the required voltage you will hear six audible beeps when opening the vault.
