Summary of Contents for Solflex HT
- Page 1 Installation - Manual HT - Acoustic Housing...
- Page 2 T: +43 2238 20 33 6 T: +359 2 906 64 26 E: office@solflex.eu www.solflex.eu Always observe all relevant standards and statutory regulations Subject to change without prior notice. All business transactions based on our Terms and Conditions, available at www.solflex.eu Manual HT Acoustic housing...
-
Page 3: Table Of Contents
3.3.1. Fire fighting ....................5 Product delivery ..............6 Installation of unit ............. 7 HT with rear intake ..............9 HT with lateral intake ............11 Connection for refrigerant pipes and power supply ....14 Foundation ................. 15 . 16 Installation of Heat Pump, Air Conditioning and Refrigeration outdoor unit Maintenance and Service .......... -
Page 4: Technical Data
Technical data https://solflex.eu/en/htschalldaemmgehaeuse10db/ Warranty 24 months from delivery. Manual HT Acoustic Housing... -
Page 5: Safety
The insulation foam has a fire behaviour according norm. Risk of serious injury from dislodged loads. Do not stand under suspended loads. Risks from electric power. Risk of electric shock from electrostatic charge of housing: Earth the device. Manual HT Acoustic Housing... -
Page 6: Product Delivery
Keep the period of storage outdoors as short as possible, especially during the summer months, the rusting process is greatly accelerated by the higher temperatures. Manual HT Acoustic Housing... -
Page 7: Installation Of Unit
“The warranty applies to all buildings exposed to normal atmospheric corrosion factors, in other words excluding those subject to permanent spraying with fresh water or salt water; in the case of buildings situated in coastal areas, excluding those exposed to sea spray.” Manual HT Acoustic Housing... - Page 8 Alu-Zinc paint (which is common available) from aesthetic point of view. 2. The tightening torque of the screw must be 5 to 15 Nm, so that the screw does not cut into the housing and damages the Magnelis coating. Manual HT Acoustic Housing...
-
Page 9: Ht With Rear Intake
HT with rear intake Place the two baseplate pieces and fix the heat pump mounts with the M8 screws, nuts Baseplate and washers provided. Fix the heat pump to the supports mouts via the silentblocks, using nuts and washers. Heat Pump... - Page 10 HT with rear intake Place the acoustic grids on the baseplate, matching the holes in the base with the heads of the screws (detail E). Acoutic Grids (Detail E). Then fix the grids with the lateral panels with the M8 screws provided (detail F).
-
Page 11: Ht With Lateral Intake
HT with lateral intake Place the two base frame pieces and fix the heat pump mounts with the M8 screws, Frame Pieces nuts and washers provided Fix the outdoor unit to the ouotdoor unit brackets via the silentblocks Outdoor Unit 3.) Fix the lateral panel on the four drilled... - Page 12 HT with lateral intake Air Seperation 6.) The air separation panel has to be cut into the shape of the frontal fan of the heat pump Place the panel on the heat pump and keep it in place via the two L-shaped profiles, fixed with self-tapping screws provided (see details Fand G) 7.) Place the acoustic grids on...
-
Page 13: Connection For Refrigerant Pipes And Power Supply
There is a possibility to enter with refrigerant pipes and power supply in the sound insulation housing, both on the left and on the right side, in case the entry is not foreseen through the bottom. Manual HT Acoustic housing... -
Page 14: Foundation
(Heat Pump, Air Conditioning and Refrigeration system). An uneven foundation might cause malfunction or jammed panels. Liability is excluded for damage caused by installation on an uneven surface. Manual HT Acoustic Housing... -
Page 15: Installation Of Heat Pump, Air Conditioning And Refrigeration Outdoor Unit
Cleaning and maintenance of the acoustic housing • Remove other dirt with a dampcloth; if necessary, use grease- or oil-dissolving detergents(concentrated neutral detergentwith pH between 8 and 9). Manual HT Acoustic Housing... -
Page 16: Silencers
After working on the acoustic housing, the person responsible must ensure that no person is in the acoustic housing before it is put into operation again. Removal and disposal Metal parts and plastic parts are to be recycled, per applicable regulations. Manual HT Acoustic Housing... - Page 17 Notes Manual HT Acoustic housing...
- Page 18 Vitosha Blvd. 48, ground floor Am Feuerstein 282 BG-1000 Sofia A-2392 Wienerwald, Austria Bulgarien +43 2238 203 36, office@solflex.eu +35929066426 IM-HT-04/2023-ENG office@solflex.eu All business transactions based on our Terms and Conditions, available at www.solflex.eu. Subject to change without prior notice.
