FBS SC-APC Installation Manual

Universal Field connector SM for flat cables
Conector de Campo Universal SM para cabos flat
Conector de Campo Universal SM para cables flat
General Information/ Informações Gerais/
Información General
• Quick and easy connection of compact flat cables 3x2 mm and 2x1.6 mm
type;
• Available in connector type SC with UPC or APC polishing;
• Designed for indoor application in controlled areas or in termination
boxes.
• Conexão rápida e fácil de cabos compactos tipo flat 3x2 mm e 2x1,6 mm;
• Disponível no tipo de conector SC com polimento UPC ou APC;
• Aplicação interna em áreas controladas ou caixas de terminação.
• Conexión rápida y fácil de cables campactos tipo flat 3x2 mm y 2x1,6 mm;
• Disponible en el tipo de conector SC con pulido UPC o APC;
• Diseñado para aplicación interna en áreas controladas o cajas de
terminación.
Care and Safety/ Cuidados e Segurança/
Cuidado y Seguridad
• Use protective glasses to handle optical fibers.
• Do not look directly to connector ferrule or to the fiber; they can be connected
to a light source.
• Do not disassemble the pieces; the small particles can cause injuries.
• Be careful not to wet the pieces.
• Do not handle the pieces at high humidity or dusty places, to avoid failures.
• Do not drop the pieces, to avoid failures.
• Put the pieces in a plastic bag for storage.
• Do not remove the dust cover before the assembling.
• Attach the connector into the adapter after the assembling or keep the dust
cover in case you do not attach into the adapter at the moment.
• Do not use organic solvent (ex: acetone); the use of organic solvent can damage
the pieces.
SC-APC (3x2 mm | 2x1,6 mm)
INSTALLATION GUIDE
MANUAL DE INSTALAÇÃO
MANUAL DE INSTALACIÓN MANUAL DE INSTALACIÓN
