- Page 1 THRUSTERS DIGITAL STABILIZERS INTEGRATED HYDRAULICS • • Hydraulic Thruster Installation & Operation 35989...
- Page 2 Arcturus Marine / American Bow Thruster Standard Installation and Operating Instructions Version 6.99.1_c Hydraulic TRAC Table of Contents Prefix: Gearbox Installation Drawings (all TRAC sizes): List of Graphics & Tables: Section 1 – Before Starting Installation; ………………………………………. Technical Assistance Section 2 – Basic Component Installation: ……………………………………….
- Page 3 SIZE FSCM N O . D W G . N O . REV. INM8TRACHYD REPRODUCTION IN WHOLE OR PART WITHOUT THE CONSENT OF ARCTURUS MARINE SYSTEMS IS EXPRESSLY FORBIDDEN. ALL APPLICABLE COPYRIGHT LAWS APPLY. FINISH: SCALE: SHEET ISSUED 1 of 1...
- Page 4 EXCLUSIVE PROPERTY OF ARCTURUS MARINE SYSTEMS. SIZE FSCM N O . DWG. N O . REV. INM1012TRACHYD REPRODUCTION IN WHOLE OR PART WITHOUT THE CONSENT OF ARCTURUS MARINE SYSTEMS IS EXPRESSLY FORBIDDEN. ALL APPLICABLE COPYRIGHT LAWS APPLY. FINISH: SCALE: SHEET ISSUED 1 of 1...
- Page 5 SIZE FSCM N O . D W G . N O . REV. INM16TRACHYD REPRODUCTION IN WHOLE OR PART WITHOUT THE CONSENT OF ARCTURUS MARINE SYSTEMS IS EXPRESSLY FORBIDDEN. ALL APPLICABLE COPYRIGHT LAWS APPLY. FINISH: SCALE: SHEET ISSUED 1 of 1...
- Page 6 SIZE F S C M NO. D W G . NO. REV. INM20TRACHYD REPRODUCTION IN WHOLE OR PART WITHOUT THE CONSENT OF ARCTURUS MARINE SYSTEMS IS EXPRESSLY FORBIDDEN. ALL APPLICABLE COPYRIGHT LAWS APPLY. FINISH: SCALE: SHEET ISSUED 1 : 5...
- Page 7 SIZE FSCM N O . D W G . N O . REV. INM2428TRACHYD REPRODUCTION IN WHOLE OR PART WITHOUT THE CONSENT OF ARCTURUS MARINE SYSTEMS IS EXPRESSLY FORBIDDEN. ALL APPLICABLE COPYRIGHT LAWS APPLY. FINISH: SCALE: SHEET ISSUED 1 of 1...
- Page 8 Graphics, Pictures, Diagrams and Tables: Figure 1: Tunnel Positioning Figure 2: Marking The Tunnel Cutout Figure 3: Marking The Tunnel Cutout Figure 4: Tunnel / Hull Joint Radius Figure 5: The “Eyebrow” Figure 6: The “Scallop” Figure 7: Tunnel Gratings Figure 8: Thruster Mounting Figure 9:...
-
Page 9: Section 1 - Before Starting Installation
Section 1 - Before Starting Installation: Please read this manual in its entirety before starting installation! It will save you money! Technical Assistance: Listed below are several numbers you can call in case you have any questions about your system, or if you need technical assistance. -
Page 10: Section 2 - Basic Component Installation
Section 2 - Basic Component Installation Tunnel Installation: WARNING! Thruster tunnel becomes an integral part of the hull. Installation of thruster tunnel should be undertaken only by professionals with certified competency in the fabrica- tion and repair of the hull material in question. Proper mechanical bonding of the tunnel to the hull and support of the tunnel must be confirmed and certified with your naval architect. - Page 11 Tunnel/Hull Joint Radius: To minimize inlet turbulence, which can reduce thrust, it is best if the tunnel/hull joint radius be not more or less than 1/10 the tunnel diameter. It is recognized that fabrication of such a radius can be quite time con- suming and expensive.
- Page 12 The "scallop": A few builders have gone to the expense of scalloping out the trailing edge of the tunnel so as to soften or eliminate the corner of the trailing edge of the tunnel. The theory behind this approach is that, if left un- treated, the trailing edge corner will cause turbulence and hull drag.
-
Page 13: Thruster Installation
Thruster Installation: • The thruster is held in the tunnel by 6 socket head cap screws. The diameter of the screws vary with thruster size and material. Use only screws supplied by American Bow Thruster. A gasket is usually used between the strut (thruster mounting surface) and the inside of the tunnel. - Page 14 Final Thruster Mounting: • Carefully clean the mounting surfaces on the thruster strut and the inside of the tunnel. • Apply RTV silicone to both sides of the gasket. (If a gasket is not being used, coat the thruster mounting surface with an underwater gasket material such as Sikaflex.) •...
- Page 15 Propeller Mounting: • Clean the propeller shaft and the inside of the propeller hub. Fit key into shaft key way and test fit the propeller. Propeller should make up on the shaft cleanly. If propeller does not fit snug and clean, remove propeller and correct problem.
- Page 16 Motor Bell Housing Mounting (Splined Shaft): • The bell housing is designed to slide onto a boss on the pinion shaft seal housing. This aligns the bell housing perfectly with the pinion shaft. The bell housing fastens through the seal housing into the top of the thruster strut.
- Page 17 Hydraulic Motor Mounting (Splined Shaft): • Apply heavy grease to pinion shaft spline and install spline coupling. • Where applicable, install Spline Sizing adapter. • Apply heavy grease to hydraulic motor shaft spline and fit onto bell housing. Note: Bell housing heights vary. Be sure that your bell housing is not too short. There should be .100" - .350"...
- Page 18 Header Tank Mounting/Lubrication Requirements: WARNING! On some systems, the header tank fitting and plumbing must be connected before the driveline or motor are installed, or they cannot be reached. The header tank maintains positive fluid pressure inside the thruster gearbox to prevent water intrusion in the unlikely event of a leak.
- Page 19 Electrical Component Installation: Thruster Control Station (TCS): Thruster Control Stations (TCS's) should be located at steering stations near main engine throttle and shift controls. A console cutout template and gasket is provided with each TCS. Make the console cutout as shown and drill the four mounting holes.
-
Page 20: Hydraulic Pump Installation
Hydraulic Pump Installation: WARNING! Operation of a hydraulic pump having the wrong rotation will cause serious damage to the pump. Confirmation of proper pump rotation is the responsibility of the installer! WARNING! Operation of a hydraulic pump having inlet and outlet plumbing accidently reversed will cause serious damage to the pump. - Page 21 Engine PTO Location: Where an SAE pump PTO is provided on the front of the engine: • Ensure that the PTO mounting and shaft connection match the hydraulic pump being used. • Check to be sure that pump rotation is correct. Important! •...
- Page 22 CENTAFLEX Coupling Installation: CENTAFLEX Coupling Information: Radial Fastener Element Flange Adapter Axial Fastener Apply grease to shoulder of bolts. DO NOT grease threads Hub Adapter Figure 20 WARNING! Improperly installed couplings are a frequent area of trouble with the system. They can cause excessive wear on the coupling and can even cause the attached clutch to break.
- Page 23 CENTAFLEX Alignment Suggestions: • Remove rubber element. • Check for angular misalignment with a small square. Check through 360 degrees. • Maximum allowable misalignment is 1 degree. 1 degree max. 1 DEGREE MAX. • With element removed, measure distance from outside diameter of hub to outside diameter of flange.
- Page 24 Centaflex couplings are always supplied with Centaflex, Lovejoy fasteners that are coated with a special locking compound. Use only these fasteners! These fasteners should be assembled and torqued only once if possible. However, the locking compound on these fasteners is rated for up to three tightenings. Be sure to read the installation notes on Centaflex Couplings (pg.
- Page 25 SPICER Coupling Installation: Where American Bow Thruster supplies clutch, bracket, and SPICER SHORT COUPLED DRIVE LINE coupling: If a Spicer short coupled drive line is used the pump platform may be fastened to the engine stringers. How- ever, the face of the clutch input hub must be parallel with the face of the engine drive shaft pulley! This is very important! See diagram.
- Page 26 Miscellaneous Pump Information: Adapters: Adapters that allow for direct bolt up of the pump coupling to the engine are usually provided. It is important that all fasteners associated with the pump coupling be given close attention. All required fasteners are usually provided by the factory.
-
Page 27: Reservoir Installation
Reservoir Installation: FILTER HEAD FILLER/BREATHER The reservoir assembly should be SWITCH ASSEMBLY 9.5” CLEARANCE mounted close to, and above the hydraulic pump. Plan reservoir location so that there will be no more than two HEAT EXCHANGER 90 degree elbows in the pump suction hose. Suction hose is large in diameter, is very stiff, and has a very large minimum RETURN PORT bend radius. - Page 28 Directional Control Valve Installation: DANGER! If the pressure line from the pump is accidentally connected to the T port on the DCV instead of the P port there will be no path for oil flow and the relief valve cannot protect the system.
-
Page 29: Section 3 - Plumbing
Section 3 - Plumbing Plumbing: The system must be plumbed according to the plumbing diagram that accompanies these standard instruc- tions. Pressure ratings on the diagram are minimum working pressure, not burst pressure. DANGER! Use of hydraulic hose or pipe not having sufficient working pressure ratings may result in hose or pipe failure which can cause serious personal injury. - Page 30 Generic Hydraulic System Diagram: .75" 200 PSI 11 GALLON RESERVOIR 1.5" SUCTION HYDRAULIC PUMP .75" .75" 3000 THRUSTER DIRECTIONAL CONTROL VALVE .375" .75" 200 PSI .50" .75" .75" 3000 3000 HEADER TANK .375" 200 PSI THRUSTER MOTOR Figure 31...
-
Page 31: Section 4 - Wiring
Section 4 - Wiring Note! The system must be wired according to the wiring diagram that accompanies these standard instructions. Wire sizes on the diagram are minimums. DANGER! Use of wire of insufficient size can cause system malfunction and equipment damage. It may also result in fire which can cause significant material damage and serious personal injury. -
Page 32: Section 5 - Miscellaneous Pre-Start-Up Notes
Section 5 - Miscellaneous pre-start-up notes Corrosion Control: All seagoing vessels must be protected from corrosion from galvanic and electrolytic potential. American Bow Thruster encourages all boat owners to enlist the services of a corrosion control expert to evaluate your vessel's corrosion control system and how your thruster should be made a part of that system. -
Page 33: Section 6 - Final Check List
Section 6 - Final Check List: Did You?..- be sure to call American Bow Thruster to answer your questions so that expensive mistakes could be avoided down the road? - install the tunnel at least 1/2 diameter (and preferably deeper) from the waterline to the top of the tunnel? - have a professional, certified craftsman install the tunnel to the architects standards? - ensure that thruster does not protrude from tunnel? - Page 34 START-UP WARNING Before any system hydraulic pump is turned, three preparatory steps must be taken: 1) The pump case for every system hydraulic pump must be filled with hydraulic oil. 2) The motor case for every hydraulic thruster motor must be filled with hydraulic oil.
-
Page 35: Section 7 - Start-Up And Tuning
Section 7 - Start-up and Tuning Hydraulic Check: • Double check all plumbing to be sure that all hoses have been run and are connected to the right ports. • Check to see that all fittings and connections are tight. •... - Page 36 • If system has a clutch , turn system ON by pushing any TCS START switch. Note: You must hold START or STOP switch down for at least 2/10's of a second before the system will acknowledge your command. Listen for clutch to engage. If it does, oil will rapidly drain from reservoir.
- Page 37 Tuning: There are 2 ways to tune the Thruster Control Station (TCS), by pressure reading or by electrical reading. Both ways are described below. The speed sensor is mounted on the input flange of the clutch. At the top of the sensor where the wires protrude there is an LED which, at first glance, is hard to see.
- Page 38 Tuning electrically: • Enable the first TCS. • If main engine driven system, increase main engine rpm to 800. • Move the jog lever to the minimum thrust position. • Set the Voltmeter to DC voltage and place the voltage lead on terminal (A), (Signal to throttle) and the common lead on terminal (-).
