- Page 1 CARDIO BAR RACK Model 851CR Owner’s Manual V2.0—06.2012 www.tko.com...
- Page 2 THIS PAGE INTENTIONALLY LEFT BLANK...
- Page 3 Hours: Monday-Friday 8:30am to 4:30pm CT © Copyright 2011, TKO Sports Group USA Limited. All rights reserved. TKO Sports Group USA Limited. 4660 Pine Timbers, Suite 198, Houston, TX 77041 Phone + 713-895-9270 Fax + 713-934-8495 www.tko.com...
- Page 4 Product Diagram...
- Page 5 Exploded Diagram Part ...
- Page 6 Parts List Part Description Q’ty Upright Frame – L&R Bar Support Cross Fame Bar Holder Rear Support Frame Rear Base Frame End Cap 60 End Cap End Cap EVA Padding EVA Padding Round EVA Padding Name Plate Flat Washer for M10 Bolt Spring Washer for M10 Bolt Allen Bolt M10 x 30mm Rivet 4mm x 12 mm...
- Page 7 • Always wear suitable clothing and footwear during exercise. Do NOT wear loose fitting clothing that could become entangled with the moving parts of your exercise machine Assembly tightened. Step 1 uld not use Connect the Rear Support Frame 4 to the Rear Base Frame (5), Using 4 Allen Bolts (15), 4 Spring Washers (14) and 4 Flat Washers (13).
- Page 8 End Cap Step 2 Assembly Connect the upright Frames (1) to the Rear Base Frame Assembly, Using 4 Allen Bolts EVA Padding (15), 4 Spring Washers (14) and 4 Flat Washers (13). EVA Padding Step 3 Round EVA Padding Connect the Bar Holder (3) to the Upright Frame Assembly, using 4 Allen Bolts (15), Name Plate 4 Spring Washers (14) and 4 Flat Washers (13).
