Summary of Contents for Uniks EVSE X7
- Page 1 EVSE X7 Adapter EV Charger Tester...
- Page 3 REGISTER YOUR PRODUCT www.uniks.it The registration of your products will allow you to stay informed about news, take advantage of advantageous discounts dedicated to you for the purchase of accessories and products for your daily work. Registration is free...
-
Page 4: Table Of Contents
Operation Elements And Connectors………..…5 References……………………………………………6 References marked on instrument or in instruction manual…6 Safety References………………………………………..7 Testing…………………………………………… …8 Purpose of the EVSE X7 accessory……...……….8 Test procedure:……………………………………..9 Proximity Pilot (PP) State (Cable Simulation)…..10 Control Pilot (CP) State (Vehicle Simulation)….10 CP Signal output terminals……………………….11 CP Error “E”... -
Page 5: Operation Elements And Connectors
Operation Elements And Connectors Type-2 plug Slider switch for CP Mode selection Test leads with 4mm safety plugs for L1, L2, L3, N, PE, CP and PP Adapter is equipped with 0,5 m test leads... -
Page 6: References
References References marked on instrument or in instruction manual Warning of a potential danger, follow with instruction manual. Reference! Please use utmost attention. Caution! Dangerous voltage. Danger of electrical shock. Ground terminal Continuous double or reinforced insulation category II IEC 536 / DIN EN 61140. Conformity symbol, instrument complies with the... -
Page 7: Safety References
Safety references Safety References respective accident prevention regulations established professional associations for electrical systems equipment must be strictly met at all times. In order to avoid electrical shock, the valid safety and regulations regarding excessive contact voltages must receive utmost attention, when working with voltages exceeding... -
Page 8: Testing
When modifying or changing the instrument, the operational safety is no longer ensured. Testing Purpose of the EVSE X7 accessory The UNIKS EVSE X7is an accessory support relevant measurements of a Multifunction Tester (MFT) simply wire... -
Page 9: Test Procedure
..Typical connection between EVSE X7 and NOVA or NOVA PRO (Multifunction Installation Testers). Test procedure: connect the needed 4 mm test • plugs of the UNIKS EVSE X7to your MFT, select CP Mode “A”... -
Page 10: Proximity Pilot (Pp) State (Cable Simulation)
“A” with the slider switch to stop • charging, unplug UNIKS EVSE X7from the • charging point. Proximity Pilot (PP) State (Cable Simulation) The UNIKS EVSE X7is configured internally to setup 32 A current capability. Control Pilot (CP) State (Vehicle... -
Page 11: Cp Signal Output Terminals
Vehicle State CP-PE State Description Open Electric ±12V @ (∞) vehicle not 1KHz connected Vehicle +9V/-12V 2.74K connecte @ 1KHz Ω d, not ready to charge Electric +6V/-12V 882Ω vehicle @ 1KHz connected ready charge, ventilation required CP Error „E“ 0Ω... -
Page 12: Cp Error "E" Simulation
For details of communication protocol please refer to IEC/EN 61851-1 and the documentation manufacturer charging station. Important note: In the case of wrong wiring of the charging station, signal test terminals can get high, live hazard voltage. CP Error “E” simulation “E”... - Page 13 any other instruments connect- (such UUT, control instruments, etc.). Never use acid detergents or dissolvent for cleaning. Input Voltage: 230 / 400 V 3~ 50 / 60 Hz Measurement CAT II 300V Category: Main socket max. 10A rating: PP simulation: configurazione interna a 32 A CP simulation:...
-
Page 14: Assistance
ASSISTANCE WARRANTY CONDITIONS This instrument is warranted against defects materials workmanship, in accordance with the general terms and conditions. During warranty period, defective parts can be replaced, but the manufacturer reserves the right to repair or replace the product. If the instrument is to be returned to the after - sales service or to a dealer transportation is borne... -
Page 15: Assistance
The content of this manual may not be reproduced in any form without permission manufacturer. Our products are patented and their trademarks. The manufacturer reserves right change specifications and prices if this is technological improvements. ASSISTANCE If the instrument does not operate properly, before contacting the Customer Service, check the status of the battery and wear of the... - Page 16 Uniks Srl https://www.uniks.it info@uniks.it Via Vittori 57 48018 Faenza (RA), Italy 0546.623002 0546.623691...
